PLUS+1® Controller Family
•
Current outputs for MC050-010, MC050-020, MC088-015, and OX024-010 module
•
DOUT and DOUT/PVG Pwr pins are pair limited and a function of temperature.
Output per pair is: 6 A maximum at 25 C [77 F]. Output per pair is 4 A maximum at 70° C [158˚ F]
•
MC050-010 pairs are: C1p31 and C1p32, C1p33 and C1p34, C1p35 and C1p36
•
MC050-020 pairs are: C1p33 and C1p34, C1p35 and C1p36, C1p37 and C1p38, C1p39 and C1p40
•
MC088-015 pairs are:
Power plane C2p35: C1p31 and C1p32, C1p33 and C1p34
Power plane C2p36: C1p35 and C1p36
Power plane C2p37: C2p1 and C2p7, C2p2 and C2p3, C2p4 and C2p5, C2p30 and C2p33
Power plane C2p38: C2p6 and C2p12
•
OX024-010 pairs are: C1p6 and C1p7, C1p8 and C1p9, C1p10 and C1p11
•
Example: at a module temperature of 70˚ C [158˚ F], if C1p31 is sourcing 2.5 A, the most current that
can be sourced on its paired pin C1p32 is 1.5 A
General
Description
Configuration
Type
Short circuit to ground protection
Open circuit detection
Parallel operation
Shut off
Specifications
Description
Allowed voltage at pin
Output voltage, energized state
Output voltage, off state
Output current range for a status bit
to read OK
Do not connect a digital output to battery+ (back drive) without a series diode.

High Current Digital (HDOUT)

High current digital outputs can source up to 6 A.
General
Description
Configuration
520L0719 • Rev PB • Feb 2014
Comment
Sourcing only.
Linear switching.
Non-damage, current/thermal limit with status indication;
automatic latch off /resume.
Fault indication provided. The GUIDE Pin Status requires a load
of 500 mA to be connected or an open fault will be declared.
Digital outputs from the same module are capable of being
connected together such that the net current rating is the sum
of the individual ratings; timing is resolved by the operating
system; diagnostic capability is maintained.
Processor control with hardware WatchDog override.
Units Minimum Maximum
Vdc 0 36
Vdc Vbatt-1.0 Vbatt
Vdc 0 0.1
A 0.5 3
Comment
Sourcing only.
Comment
See caution statement, page 17.
Over all load conditions.
At Rload=200 Ω
See note regarding pair, above.
