Product Installation; Mounting - Danfoss PLUS+1 Series Technical Information

Technical Information
Product Installation and Start-up

Product Installation

28
PLUS+1® Controller Family
Danfoss Mating Connector Part Information
Description 12 pin
module
Mating 10100944
connector bag
assembly (20
to 24 AWG)
Mating 10102025
connector bag
assembly (16
to 20 AWG)
Danfoss Crimp Extraction Tool Part Information
Description
Crimp tool for 20 to 24 AWG
Crimp tool for 16 to 20 AWG
Extraction tool Deutsch 114010; 12 AWG
Extraction tool Deutsch 0144-240-2005; 16 to 20, 20 to 24 AWG
PLUS+1 module mating connectors may be mated 10 times.
Recommended torque for the Deutsch® mating connector retaining fastener on 38 and 50 pin connectors
is 20 lb•in (2.26 N•m).

Mounting

PLUS+1 12, 24, 38, and 50 pin modules can be mounted in one of three ways:
•
End (bulkhead) installation
•
Up to 3 units stacked on one another
•
Individually side mounted
MC018-XXX modules are designed for panel mounting only.
MC088-XXX modules are designed for bulkhead mounting only.
In each case, care must be taken to insure that the module connector is positioned so that moisture
drains away from the connector. If the module is side or stack mounted, provide a drip loop in the
harness. If the module is mounted vertically, the connector should be on the bottom of the module.
Provide strain relief for mating connector wires.
C
Caution
Module damage may occur. Use caution when installing MC050-XXX modules. Due to the size of the
mating connector wire bundle, it is possible to twist off the end cap of the module if excessive pressure is
applied during the installation of harness strain relief.
Suggested Fasteners and Recommended Installation Torque
Mounting method
Bulkhead mount; multiple units stacked; single
520L0719 • Rev PB • Feb 2014
18 pin 24 pin
module module
— — 10100945
10102025 10102023
Recommended OD
6.0 mm (.25 in)
38 pin 50 pin
module module
— — 10100946
11027919 10102024
Part number
10100745
10102028
11068808
10100744
Recommended torque
9.49 N•m (7 ft•lb)
88 pin
module
10105649
11071844
