Danfoss PLUS+1 Series Technical Information page 18

Technical Information
Inputs/Outputs Types and Specifications
18
PLUS+1® Controller Family
Refer to individual module data sheets for the maximum allowable output current for each PLUS+1
module.
General
Description
Configuration
Type (Linear vs. PWM)
Operating modes
Dual coil PCPs
Short circuit to ground
Mode selection (current or voltage) and full scale
current ranges
Do not connect a digital output to battery+ (back drive) without a series diode.
PLUS+1 PWM output circuits are not designed to be used as inputs. Output current feedback readings
should be used for fault checking only.
W
Warning
Unintended movement of the machine or mechanism may cause injury to the technician or bystanders.
The module will be powered up if battery voltage is applied to the module's output pin. To protect
against unintended movement, secure the machine.
C
Caution
Warranty will be voided if module is damaged by significant current driven back through an output pin.
Specifications
Description
Full scale proportional current
output
Output voltage, 100% duty cycle
Output resolution of 3 A
Repeatability of full range
Absolute accuracy of full range
Output settling time
PWM frequency
Dither frequency
Dither amplitude
Over-current trip point
520L0719 • Rev PB • Feb 2014
Comment
Sourcing or sinking.
PWM
Programmable: closed loop current or open loop voltage (duty
cycle).
Compensated for induced currents in a non-driven coil (closed
loop mode).
Output fully protected against damage and fault detected.
Programmable.
Units Minimum Maximum
mA 10 3000
Vdc 0 Vbatt-1
mA 0.25
% of full 0.5
scale
% of full 0.5
scale
ms 100
Hz 33 4000
Hz 33 250
A 0 0.5
A 5 5.25
Comment
The current may accidently be
exceeded in open loop mode. If the
current exceeds the trip point, the
output will be latched off.
Depends on load characteristics.
Some pins have a fixed frequency,
consult module application program
interface (API).
Increased in steps, see module API.
Increased in steps, see module API.
There is over-current protection built
into each output driver. If the
instantaneous current exceeds the
trip point, the driver is latched off.
GUIDE application software can reset
