3.8 PROGRAMMING THE P.C.B.
The boiler is prepared for possible programming
of several operation parameters. By modifying
these parameters as described below, the boiler
can be adapted according to specific needs.
To access the programming phase, position the
DHW selector (5) (Fig. 2-1) on position "6", the
CH selector (6) on position "9" and press the
"Reset" (3) and "Summer/Winter" buttons for
about 8 seconds (2).
Once the menu has been accessed, it is possible
to scroll through the three sub-menus present
(s, p, t) by pressing the "Summer/Winter" (2)
button for 1 second.
Use the "DHW regulator" selector (5), to select
the parameter (inside the same sub-menu) and
rotate the "CH regulator" selector (6) to modify
the value according to the range available.
Press the "Reset" button (3) for 1 second to
memorise the variation of the parameters.
Memorisation is represented via "88" on the
indicator (14) for 2 seconds.
Exit the programming mode by waiting for
15 minutes or by pressing the, "Reset" (3) and
"Summer/Winter" (2) buttons simultaneously.
Id
Parameter
Parameter
Minimum DHW
S0
The boiler also has electronic modulation that adapts the boiler potentiality to the ef-
output
fective heating demand of the house. Therefore the boiler works normally in a variable
Maximum DHW
gas pressure field between minimum and maximum power depending on the system
S1
output
heat load, setting fan speed (in rpm, hundreds of revs are represented on the display).
Minimum CH
N.B.:the boiler is produced and calibrated in the central heating phase at nominal
S2
output
output. Approximately 10 minutes are needed to reach the nominal heat output, which
Maximum CH
can be changed using the parameter (S3).
S3
output
N.B.: selection of parameters in the presence of requests, allows boiler functioning with
Power
current equal to the respective value.
S4
block
Central heating
S5
set point mini-
Defines the minimum flow temperature.
mum temperature
Central heating
S6
set point maxi-
Defines the maximum flow temperature.
mum temperature
If the reading of the external probe is not correct it is possible to correct it in order to
External probe
compensate any environmental factors.
S7
correction
(Over the value of +9 the display shows "CE", which enables an external control function
of the boiler for coupling of the same with a system supervisor)
Identifies the boiler's power
S8
Boiler power
(only useful with a coupled storage tank and parameter P0=1).
Description
18
Range
Default
12 =1300 (NG/LPG)
900 ÷ 1500
30 =1300 (NG/LPG)
12 =4750 (NG/LPG)
3500 ÷ 6100
30 =5100 (NG/LPG)
12 =1300 (NG/LPG)
S0 ÷ S3
30 =1300 (NG/LPG)
12 =4750 (NG/LPG)
S2 ÷ S1
30 =5100 (NG/LPG)
12 =2900 (NG/LPG)
1500 ÷ 3500
30 =2900 (NG/LPG)
20 ÷ 50 °C
25
(S5+5) ÷
85
85 °C
-9 ÷ 9 K
0
0 = 12 kW
1 = 26 kW
1
2 = 28 kW
3 = 32 kW
