Page 3: Table Of Contents
MAN Diesel & Turbo Index Table of contents Page 1 (5) Table of contents L27/38S powerplant I 00 Introduction Introduction to project guide I 00 00 0 1643483-5.5 Key for engine designation I 00 05 0 1609526-0.8 Designation of cylinders I 00 15 0 1607568-0.2...
Page 4 Crude oil specification B 11 00 0 3700246-2.0 Viscosity-temperature diagram (VT diagram) 010.000.023-06 Guidelines regarding MAN Diesel & Turbo GenSets operating on low sulphur B 11 00 0 1699177-5.1 fuel oil Calculation of specific fuel oil consumption (SFOC) B 11 01 0 3700405-6.2...
Page 5 MAN Diesel & Turbo Index Table of contents Page 3 (5) Treatment and maintenance of lubricating oil B12150, 1643494-3.11 Criteria for cleaning/exchange of lubricating oil B 12 15 0 1609533-1.7 B 13 Cooling water system Specification of engine coolant 010.000.023-13 Coolants inspecting 010.000.002-03...
Page 6 MAN Diesel & Turbo Index Table of contents Page 4 (5) Pressure droop in exhaust gas system B 16 00 0 1624460-4.2 SCR (Selective Catalytic Reduction) B 16 00 0 3700467-8.1 Equipment to optimize performance B 16 00 0 3700546-9.0...
Page 7 MAN Diesel & Turbo Index Table of contents Page 5 (5) Standard tools (normal maintenance) P 24 01 1, 3700125-2.4 Additional tools P 24 03 9, 3700126-4.11 Hand tools P 24 05 1, 3700414-0.0 B 50 Alternator Alternators for GenSets B 50 00 0 1699895-2.1...
Page 9: I 00 Introduction
MAN Diesel & Turbo I 00 Introduction I 00 Introduction Page 1 (1) 2018-04-13 - en...
Page 11 MAN Diesel & Turbo will issue an Installation Manual with all project related drawings and installation instruc- tions when the contract documentation has been completed.
Page 12: Introduction To Project Guide
Notice: When refering to a document, please state both Drawing No including revision No and Release date. Copyright 2011 © MAN Diesel & Turbo, branch of MAN Diesel & Turbo SE, Germany, registered with the Danish Commerce and Companies Agency under CVR Nr.: 31611792, (herein referred to as “MAN Diesel & Turbo”).
Page 13: Key For Engine Designation
MAN Diesel & Turbo 1609526-0.8 Key for engine designation I 00 05 0 Page 1 (1) L27/38S, L16/24S, L21/31S, L23/30S, L28/32S, L23/30DF, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Key for engine designation 2015.11.27...
Page 15: Designation Of Cylinders
MAN Diesel & Turbo 1607568-0.2 Designation of cylinders I 00 15 0 Page 1 (1) L16/24S, L21/31S, L23/30S, L23/30DF, L28/32S, L27/38S, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H General 2016.08.24...
Page 17: Code Identification For Instruments
MAN Diesel & Turbo 1687100-5.6 Code identification for instruments I 00 20 0 Page 1 (3) L16/24S, L27/38S, L21/31S, L23/30S, L23/30DF, L28/32S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Explanation of symbols Specification of letter code for measuring devices 1st letter...
Page 18 MAN Diesel & Turbo 1687100-5.6 Code identification for instruments I 00 20 0 Page 2 (3) L16/24S, L27/38S, L21/31S, L23/30S, L23/30DF, L28/32S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Standard text for instruments Diesel engine/alternator LT water system inlet to air cooler inlet to alternator inlet to lub.
Page 19 MAN Diesel & Turbo 1687100-5.6 Code identification for instruments I 00 20 0 Page 3 (3) L16/24S, L27/38S, L21/31S, L23/30S, L23/30DF, L28/32S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Compressed air system inlet to engine inlet to reduction valve...
Page 21: Symbols For Piping
MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 1 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF General Symbol Symbol designation Symbol Symbol designation 1. GENERAL CONVENTIONAL SYMBOLS 2.13...
Page 22 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 2 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF Symbol Symbol designation Symbol Symbol designation 3.15 Butterfly valve 3.37 3/2 spring return valve contr. by sol- enoid 3.16...
Page 23 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 3 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF Symbol Symbol designation Symbol Symbol designation Magnetic filter 6. FITTINGS Separator...
Page 24 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 4 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF List of Symbols General Pipe dimensions and piping signature Pipe dimenesions A : Welded or seamless steel pipes.
Page 25 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 5 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF Heating coil DIN 8972 Suction bell Non-return valve Air vent Butterfly valve Sight glass DIN 28.004...
Page 26 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 6 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF 1st letter Following letters D : Density A : Alarm E : Electric...
Page 27 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 7 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF Basic symbols for piping 2237 Spring operated safety valve 2238 Mass operated Safety...
Page 28 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 8 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF T - bored 2237 Spring operated safety valve 2238 Mass operated...
Page 29 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 9 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF Air venting Tank with domed ends 6.25 Air venting to the outside...
Page 30 MAN Diesel & Turbo 1655279-1.1 Symbols for piping I 00 25 0 Page 10 (10) L27/38S, L16/24, L16/24S, L21/31, L21/31S, L23/30H, L23/30S, L23/30DF, L28/32H, L28/32S, V28/32H, V28/32S, L27/38, L28/32DF 4.1.1.1 Loop expansion joint Gear pump 4.1.1.2 Lyra expansion joint Screw pump 4.1.1.3...
Page 31: D 10 General Information
MAN Diesel & Turbo D 10 General D 10 General information information Page 1 (1) 2018-04-13 - en...
Page 33 MAN Diesel & Turbo 1689471-7.4 List of capacities D 10 05 0 Page 1 (2) L27/38S, L27/38 Capacities 5L27/38: 300 kW/cyl., 720 rpm, 6-9L27/38: 330 kW/cyl., 720 rpm Engine output 1500 1980 2310 2640 2970 Speed Heat to be dissipated Cooling water cylinder Charge air cooler;...
Page 34 MAN Diesel & Turbo 1689471-7.4 List of capacities D 10 05 0 Page 2 (2) L27/38S, L27/38 Conditions Reference condition : Tropic Air temperature °C LT water temperature inlet engine (from system) °C Air pressure Relative humidity Temperature basis: Set point HT cooling water engine outlet °C...
Page 35 MAN Diesel & Turbo 1689472-9.4 List of capacities D 10 05 0 Page 1 (2) L27/38S, L27/38 Capacities 5L27/38: 320 kW/cyl., 750 rpm, 6-9L27/38: 330 kW/cyl., 750 rpm Engine output 1600 1980 2310 2640 2970 Speed Heat to be dissipated Cooling water cylinder Charge air cooler;...
Page 36 MAN Diesel & Turbo 1689472-9.4 List of capacities D 10 05 0 Page 2 (2) L27/38S, L27/38 Conditions Reference condition : Tropic Air temperature °C LT water temperature inlet engine (from system) °C Air pressure Relative humidity Temperature basis: Set point HT cooling water engine outlet °C...
Page 37: Vibration Limits And Measurements
MAN Diesel & Turbo 3700395-8.3 Vibration limits and measurements D 10 24 0 Page 1 (2) L23/30DF, L28/32S-DF, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H GenSet Measure- Description Limit Measure- Description Limit Measure- Description...
Page 38 3700395-8.3 Vibration limits and measurements D 10 24 0 Page 2 (2) L23/30DF, L28/32S-DF, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Turbocharger Vibration acceleration measuring point, see the project guide for turbocharger. Turbocharger type...
Page 39: Description Of Sound Measurements
1609510-3.5 Description of sound measurements D 10 25 0 Page 1 (1) L28/32S, L23/30DF, L28/32S-DF, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H General Sound measuring "on-site" The Sound Power Level can be directly applied to Purpose on-site conditions.
Page 41: Description Of Structure-Borne Noise
1671754-6.2 Description of structure-borne noise D 10 25 0 Page 1 (1) L28/32S, L23/30DF, L28/32S-DF, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Introduction This paper describes typical structure-borne noise levels from standard resiliently mounted MAN Gen- Sets.
Page 43 Due to the efficient combustion process, the HC air, the fuel and lube oil used or which are chemical content of exhaust gas of MAN Diesel & Turbo four- reaction products formed during the combustion stroke diesel engines is at a very low level.
Page 44: Exhaust Gas Components
MAN Diesel & Turbo 1655210-7.3 Exhaust gas components D 10 28 0 Page 2 (2) L23/30DF, L28/32S-DF, V28/32S, V28/32H, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H Main exhaust gas constituents approx. [% by volume] approx. [g/kWh] Nitrogen N 74.0 - 76.0...
Page 45: Emission Limits Worldbank Ii
Please contact MAN Diesel & Turbo at an early stage for project specific emission calculations (contact your sales representative). Needed adaptions of the engine parameters to fulfil project specific emission limits may in minor extent affect the fuel oil consumption.
Page 47: Moment Of Inertia
MAN Diesel & Turbo 1687148-5.2 Moment of inertia D 10 30 0 Page 1 (1) L27/38S, L27/38 GenSet Eng. type Moments of inertia Flywheel Number of Continuous Moments Engine + Moments of Mass Required cylinders rating required total damper inertia...
Page 49: Green Passport
2003) apply. This resolution has been imple- mented by some classification societies as “Green Passport”. MAN Diesel & Turbo is able to provide a list of haz- ardous materials complying with the requirements of the IMO Convention. This list is accepted by clas- sification societies as a material declaration for “Green Passport”.
Page 51: Overhaul Recommendation, Maintenance And Expected Life Time
MAN Diesel & Turbo Overhaul recommendation, Maintenance and Expected 3700340-7.1 D 10 35 0 Page 1 (2) life time L27/38S, L27/38 * After starting up and before loading engine. ** Time between overhauls: It is a precondition for the validity of the values stated above, that the engine is oper- ated in accordance with our instructions and recommendations for cleaning of fuel and lub.
Page 52: Overhaul Recommendation, Maintenance And Expected Life Time
MAN Diesel & Turbo Overhaul recommendation, Maintenance and Expected 3700340-7.1 D 10 35 0 Page 2 (2) life time L27/38S, L27/38 1) Island mode, max. 75 % average load. 2) Parallel running with public grid, up to 100 % load.
Page 53: Overhaul Recommendation, Maintenance And Expected Life Time
MAN Diesel & Turbo Overhaul recommendation, Maintenance and Expected 3700341-9.1 D 10 35 0 Page 1 (2) life time L27/38S, L27/38 * After starting up and before loading engine. ** Time between overhauls: It is a precondition for the validity of the values stated above, that the engine is oper- ated in accordance with our instructions and recommendations for cleaning of fuel and lub.
Page 54: Overhaul Recommendation, Maintenance And Expected Life Time
MAN Diesel & Turbo Overhaul recommendation, Maintenance and Expected 3700341-9.1 D 10 35 0 Page 2 (2) life time L27/38S, L27/38 2) Parallel running with public grid, up to 100 % load. 3) See working card for fuel injection valve in the instruction manual, section 514/614 for GenSet and section 1.20.
Page 55 MAN Diesel & Turbo Overhaul recommendation, Maintenance and Expected 3700342-0.1 D 10 35 0 Page 1 (2) life time L27/38S * After starting up and before loading engine. ** Time between overhauls: It is a precondition for the validity of the values stated above, that the engine is oper- ated in accordance with our instructions and recommendations for cleaning of fuel and lub.
Page 56 MAN Diesel & Turbo Overhaul recommendation, Maintenance and Expected 3700342-0.1 D 10 35 0 Page 2 (2) life time L27/38S 2) Parallel running with public grid, up to 100 % load. 3) See working card for fuel injection valve in the instruction manual, section 514/614 for GenSet and section 1.20.
Page 57 MAN Diesel & Turbo Overhaul recommendation, Maintenance and Expected 3700343-2.1 D 10 35 0 Page 1 (2) life time L27/38S * After starting up and before loading engine. ** Time between overhauls: It is a precondition for the validity of the values stated above, that the engine is oper- ated in accordance with our instructions and recommendations for cleaning of fuel and lub.
Page 58 MAN Diesel & Turbo Overhaul recommendation, Maintenance and Expected 3700343-2.1 D 10 35 0 Page 2 (2) life time L27/38S 2) Parallel running with public grid, up to 100 % load. 3) See working card for fuel injection valve in the instruction manual, section 514/614 for GenSet and section 1.20.
Page 59: B 10 Basic Diesel Engine
MAN Diesel & Turbo B 10 Basic diesel B 10 Basic diesel engine engine Page 1 (1) 2018-04-13 - en...
Page 61 MAN Diesel & Turbo 1689477-8.1 General description B 10 01 1 Page 1 (7) L27/38S, L27/38 General Engine frame The engine is a turbocharged, single-acting four- The monobloc cast iron engine frame is designed to stroke diesel engine of the trunk piston type with a be very rigid.
Page 62: General Description
MAN Diesel & Turbo 1689477-8.1 General description B 10 01 1 Page 2 (7) L27/38S, L27/38 The cylinder head is tightened by means of 4 nuts and 4 studs which are screwed into the engine frame. The nuts are tightened by means of hydraulic jacks.
Page 63 MAN Diesel & Turbo 1689477-8.1 General description B 10 01 1 Page 3 (7) L27/38S, L27/38 Valve actuating gear Drive of the push rod for the inlet and exhaust valves is from the camshaft via inlet and exhaust rocking levers supported on a joint pillow, with the cam movements being transmitted via a follower.
Page 64 MAN Diesel & Turbo 1689477-8.1 General description B 10 01 1 Page 4 (7) L27/38S, L27/38 The bearing caps and bearing blocks are bolted Camshaft and camshaft drive together by waisted bolts. The inlet and exhaust valves as well as the fuel pumps of the engine are actuated by two cam- shafts.
Page 65 MAN Diesel & Turbo 1689477-8.1 General description B 10 01 1 Page 5 (7) L27/38S, L27/38 The camshafts are located in bearing bushes which are fitted in bores in the engine frame; each bearing is replaceable and locked in position in the engine frame by means of a locking screw.
Page 66 Safety and control system gas receiver is insulated. The engine is equipped with MAN Diesel & Turbo’s own design of safety and control system called Compressed air system See “B 19 00 0 Safety, control and moni-...
Page 67 MAN Diesel & Turbo 1689477-8.1 General description B 10 01 1 Page 7 (7) L27/38S, L27/38 The high temperature cooling water system passes Turning through the high temperature circulating pump and The engine is equipped with a manual turning then through the first stage of the charge air cooler device.
Page 69: Cross Section
MAN Diesel & Turbo 1665740-7.3 Cross section B 10 01 1 Page 1 (1) L27/38S, L27/38 Cross section 2014.11.18...
Page 71: Main Particulars
MAN Diesel & Turbo 3700157-5.1 Main particulars B 10 01 1 Page 1 (1) L27/38S Main Particulars Cycle 4-stroke Configuration In-line Cyl. nos available 5 - 6 - 7 - 8 - 9 Power range 1500 - 2970 kW (HFO/MDO)
Page 73: Dimensions And Weights
MAN Diesel & Turbo 1689493-3.1 Dimensions and weights B 10 01 1 Page 1 (1) L27/38S, L27/38 General Cyl. no A (mm) * B (mm) * C (mm) H (mm) ** Dry weight GenSet (t) 5 (720 mm) 4346 2486...
Page 75: Centre Of Gravity
MAN Diesel & Turbo 1679708-8.2 Centre of gravity B 10 01 1 Page 1 (1) L27/38S, L27/38 Description Engine type X - mm Y - mm Z - mm 5L27/38 1520 1475 6L27/38 1805 1480 7L27/38 2050 1485 8L27/38 2390...
Page 77: Overhaul Areas
MAN Diesel & Turbo 1665770-6.6 Overhaul areas B 10 01 1 Page 1 (4) L27/38S, L27/38 Dismantling height Figure 1: Dismantling height. Description H1 (mm) H2 (mm) Normal dismantling: Cylinder unit 4201 4791 Low dismantlig: Cover and liner separate 3891 –...
Page 78 MAN Diesel & Turbo 1665770-6.6 Overhaul areas B 10 01 1 Page 2 (4) L27/38S, L27/38 * Overhaul with dismantled fuel injection pump/piping. 2015.11.27...
Page 79 MAN Diesel & Turbo 1665770-6.6 Overhaul areas B 10 01 1 Page 3 (4) L27/38S, L27/38 Low dismantling height Important! Extra dismantling height is required in the areas directly above the main bearing studs. 1) Remove the cylinder head separately by unscrewing the 4 connecting screws between cylinder head and the cooling water jacket.
Page 80 MAN Diesel & Turbo 1665770-6.6 Overhaul areas B 10 01 1 Page 4 (4) L27/38S, L27/38 Dismantling space It must be taken into consideration that there is suf- ficient space for pulling the charge air cooler ele- ment, lubricating oil cooler, lubricating oil filter car- tridge, lubricating pump and water pumps.
Page 81: Firing Pressure Comparison
MAN Diesel & Turbo 3700366-0.0 Firing pressure comparison B 10 01 1 Page 1 (1) L27/38S, L27/38 Firing pressure comparison 2014.08.14...
Page 83: Engine Rotation Clockwise
MAN Diesel & Turbo 1607566-7.2 Engine rotation clockwise B 10 11 1 Page 1 (1) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, V28/32S-DF, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Engine rotation clockwise 2014.05.19...
Page 85: B 11 Fuel Oil System
MAN Diesel & Turbo B 11 Fuel oil system B 11 Fuel oil system Page 1 (1) 2018-04-13 - en...
Page 87: Internal Fuel Oil System
MAN Diesel & Turbo 3700163-4.1 Internal fuel oil system B 11 00 0 Page 1 (2) L27/38S, L27/38 Internal fuel oil system Figure 1: Diagram for fuel oil system (for guidance only, please see plant specific engine diagram) Running-in filter...
Page 88 MAN Diesel & Turbo 3700163-4.1 Internal fuel oil system B 11 00 0 Page 2 (2) L27/38S, L27/38 reached the standby filter chamber is brought on through the leakage alarm unit in order to keep this line simultaneously as the dirty one is isolated by heated up, thereby ensuring free drainage passage means of the change-over valve.
Page 89: Part-Load Optimisation - Plo
Page 1 (2) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Description MAN Diesel & Turbo is continuously adapting our engine programme to the changing market condi- tions. At the request of various shipowners, we have developed and introduced a new IMO Tier II/III com- pliant tuning method for GenSets which mostly operate below the normal 75% MCR.
Page 90 MAN Diesel & Turbo 3700499-0.1 Part-load optimisation - PLO B1100 0 Page 2 (2) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 However, a fuel oil penalty will rarely occur, since it is unusual that GenSets operate beyond 75% load,...
Page 91: Heavy Fuel Oil (Hfo) Specification
To use any fuels, which do not comply with these specifications (e.g. crude oil), consultation with Technical Service of MAN Diesel & Turbo in Augsburg is required. Heavy fuel oils with a maximum density of 1,010 kg/m3 may only be used if up-to- date separators are installed.
Page 92 010.000.023-05 MAN Diesel & Turbo are as follows: abrasive and corrosive effects, unfavourable combustion characteristics, poor compatibility with mineral oils and, last but not least, adverse effects on the environment. The order for the fuel must expressly state what is not permitted as the fuel specifications that generally apply do not include this limitation.
Page 93 MAN Diesel & Turbo 010.000.023-05 Asphalt content weight % 2/3 of coke residue (acc. to Combustion properties This Conradson) requirement applies accord- ingly. Sodium content mg/kg Sodium < 1/3 vanadium, Heavy fuel oil preparation sodium <100 The fuel must be free of admixtures that have not been obtained from petroleum such as vegetable or coal tar oils, free of tar oil and lube oil (used oil), and free of chemical wastes, solvents or polymers.
Page 94 Specification of heavy fuel oil (HFO) D010.000.023-05-0001 General ISO 8217-2012 HFO specification Characteristic Unit Limit Category ISO-F- Test method Kinematic Max. 10.00 30.00 80.00 180.0 180.0 380.0 500.0 700.0 380.0 500.0 700.0 ISO 3104 viscosity at 50 °C Density at 15 °C kg/m Max.
Page 95 2017-07-11 - de Characteristic Unit Limit Category ISO-F- Test method Pour point (upper) Winter quality °C Max. ISO 3016 Summer quality °C Max. ISO 3016 Water % (V/V) Max. 0.30 0.50 0.50 0.50 0.50 0.50 ISO 3733 % (m/m) Max. 0.040 0.070 0.070...
Page 96 Specification of heavy fuel oil (HFO) D010.000.023-05-0001 General 2017-07-11 - de...
Page 97 MAN Diesel & Turbo 010.000.023-05 Additional information The purpose of the following information is to show the relationship between the quality of heavy fuel oil, heavy fuel oil processing, the engine operation and operating results more clearly. Selection of heavy fuel oil...
Page 98 If separators by other manufacturers are used, MAN Diesel & Turbo should be consulted. If the treatment is in accordance with the MAN Diesel & Turbo specifications and the correct separators are chosen, it may be assumed that the results...
Page 99 MAN Diesel & Turbo 010.000.023-05 Water-containing sludge must be removed from the settling tank before the separation process starts, and must also be removed from the service tank at regular intervals. The tank's ventilation system must be designed in such a way that condensate cannot flow back into the tank.
Page 100 However, a more effective solution is a high com- pression ratio and operational adjustment of the injection system to the igni- tion characteristics of the fuel used, as is the case with MAN Diesel & Turbo piston engines.
Page 101 MAN Diesel & Turbo 010.000.023-05 V Viscosity in mm /s (cSt) at A Normal operating conditions 50° C D Density [in kg/m ] at 15° C B The ignition characteristics can be poor and require adapting the engine or the operating conditions.
Page 102 ASTM D7060 is necessary. Additives for heavy fuel oils MAN Diesel & Turbo SE engines can be operated economically without addi- tives. It is up to the customer to decide whether or not the use of additives is beneficial. The supplier of the additive must guarantee that the engine opera- tion will not be impaired by using the product.
Page 103 To ensure sufficient cleaning of the fuel via the separator, perform regular functional check by sampling up- and downstream of the separator. Analysis of HFO samples is very important for safe engine operation. We can analyse fuel for customers at MAN Diesel & Turbo laboratory PrimeServLab. D010.000.023-05-0001 EN 13 (13)
Page 105 MAN Diesel & Turbo 010.000.023-04 Specification of diesel oil (MDO) Marine diesel oil Other designations Marine diesel oil, marine diesel fuel. Origin Marine diesel oil (MDO) is supplied as heavy distillate (designation ISO-F- DMB) exclusively for marine applications. MDO is manufactured from crude oil and must be free of organic acids and non-mineral oil products.
Page 106 Observe safety data sheets of the operating fluid supplier. Analyses Analysis of fuel oil samples is very important for safe engine operation. We can analyse fuel for customers at MAN Diesel & Turbo laboratory PrimeServ- Lab. 2 (2) D010.000.023-04-0001 EN...
Page 107 MAN Diesel & Turbo 010.000.023-01 Specification of gas oil/diesel oil (MGO) Diesel oil Other designations Gas oil, marine gas oil (MGO), diesel oil Gas oil is a crude oil medium distillate and therefore must not contain any residual materials. Military specification Diesel fuels that satisfy the NATO F-75 or F-76 specifications may be used if they adhere to the minimum viscosity requirements.
Page 108 Observe safety data sheets of the operating fluid supplier. Analyses Analysis of fuel oil samples is very important for safe engine operation. We can analyse fuel for customers at MAN Diesel & Turbo laboratory PrimeServ- Lab. 2 (2) D010.000.023-01-0001 EN...
Page 109: Bio Fuel Specification
MAN Diesel & Turbo 010.000.023-02 Specification of bio fuel Biofuel Other designations Biodiesel, FAME, vegetable oil, rapeseed oil, palm oil, frying fat. Origin Biofuel is derived from oil plants or old cooking oil. Provision Transesterified and non-transesterified vegetable oils can be used.
Page 110 Observe safety data sheets of the operating fluid supplier. Analyses Analysis of fuel oil samples is very important for safe engine operation. We can analyse fuel for customers at MAN Diesel & Turbo laboratory PrimeServ- Lab. 2 (2) D010.000.023-02-0001 EN...
Page 111: Explanatory Notes For Biofuel
▪ Fuel cooler for circulation fuel oil feeding part => Operation with biofuel to be modified. Please contact MAN Diesel & Turbo at an early In this circuit a temperature above pour point of stage of project. the biofuel is needed without overheating of the supply pumps.
Page 112 MAN Diesel & Turbo 3700063-9.0 Explanatory notes for biofuel B 11 00 0 Page 2 (2) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Requirements on engine ▪ Injection pumps with special coating and with sealing oil system.
Page 113: Crude Oil Specification
MAN Diesel & Turbo 3700246-2.0 Crude oil specification B 11 00 0 Page 1 (1) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Crude oil Crude oil is a naturally occurring flammable liquid consisting of a complex mixture of hydrocarbons of various molecular weights and other liquid organic compounds, that are found in geologic formations beneath the Earth's surface.
Page 115: Viscosity-Temperature Diagram (Vt Diagram)
MAN Diesel & Turbo 010.000.023-06 Viscosity-temperature diagram (VT diagram) Explanations of viscosity-temperature diagram Figure 1: Viscosity-temperature diagram (VT diagram) In the diagram, the fuel temperatures are shown on the horizontal axis and the viscosity is shown on the vertical axis.
Page 116 45 °C at the most with MGO (DMA) and MDO (DMB) A fuel cooler must therefore be installed. If the viscosity of the fuel is < 2 cSt at 40 °C, consult the technical service of MAN Diesel & Turbo in Augsburg. 2 (2) D010.000.023-06-0001 EN...
Page 117: Guidelines Regarding Man Diesel & Turbo Gensets Operating On Low Sulphur
1699177-5.1 B 11 00 0 Page 1 (1) operating on low sulphur fuel oil L23/30DF, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, V28/32S-DF, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H When operating on MDO/MGO a larger leak oil General amount from fuel oil injection pumps and fuel oil...
Page 119: Calculation Of Specific Fuel Oil Consumption (Sfoc
3700405-6.2 Calculation of specific fuel oil consumption (SFOC) B1101 0 Page 1 (4) V28/32S-DF, L28/32S-DF, L28/32DF, L23/30S-DF, L23/30DF, V28/32S, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L16/24, L21/31, L23/30H, L27/38, L28/32H General Figure describes the standardized calculation order for conversion of SFOC from Reference condition (ISO) to Site/FAT condition, and from Site/FAT con- dition to Reference condition (ISO).
Page 120 3700405-6.2 Calculation of specific fuel oil consumption (SFOC) B1101 0 Page 2 (4) V28/32S-DF, L28/32S-DF, L28/32DF, L23/30S-DF, L23/30DF, V28/32S, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L16/24, L21/31, L23/30H, L27/38, L28/32H Fuel consumption (kg/h): Fuel oil consumption is measured by a measuring tank.
Page 121 = 200 g/kWh, tr = 25°C, tbar = 40°C, pr = 1.0 lubricating oil consumptions, and test methods – Additional requirements for engines for general use” At site: MAN Diesel & Turbo specifies the method for recal- culation of fuel consumption dependent on ambient = 45°C, t = 50°C, p = 0.9 bar...
Page 122 MAN Diesel & Turbo 3700405-6.2 Calculation of specific fuel oil consumption (SFOC) B1101 0 Page 4 (4) V28/32S-DF, L28/32S-DF, L28/32DF, L23/30S-DF, L23/30DF, V28/32S, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L16/24, L21/31, L23/30H, L27/38, L28/32H Correction exhaust back pressure Increased negative intake pressure before com-...
Page 123: Fuel Oil Consumption For Emissions Standard
MAN Diesel & Turbo 1693568-5.3 Fuel oil consumption for emissions standard B 11 01 0 Page 1 (2) L27/38S, L27/38 5L27/38: 300 kW/cyl., 6-9L27/38 330 kW/ cyl. at 720 rpm Fuel consumption (g/kWh) with HFO/MDO and without attached pumps % Load...
Page 124 MAN Diesel & Turbo 1693568-5.3 Fuel oil consumption for emissions standard B 11 01 0 Page 2 (2) L27/38S, L27/38 Reference conditions ISO reference conditions (according to ISO 3046-1: 2002; ISO 15550: 2002) Intake air temperature T °C Barometric pressure p Relative humidity Φr...
Page 125: Fuel Injection Valve
MAN Diesel & Turbo 3700222-2.0 Fuel injection valve B 11 00 0 Page 1 (1) L27/38S, L21/31S, L16/24S, L16/24, L21/31, L27/38 Fuel injection valve The fuel valve is uncooled and placed in a sleeve in the centre of the cylinder head.
Page 127: Fuel Injection Pump
MAN Diesel & Turbo 1683324-8.1 Fuel injection pump B 11 02 1 Page 1 (1) L27/38S, L21/31S, L16/24S, L16/24, L21/31, L27/38 Fuel injection pump The fuel pump and the roller guide are one unit, placed over the fuel cam. A pipe supplies lubricat- ing oil from the camshaft bearing to the roller guide.
Page 129: Fuel Oil Filter Duplex
MAN Diesel & Turbo 1679744-6.7 Fuel oil filter duplex E 11 08 1 Page 1 (1) L27/38S, L21/31S, L16/24S, V28/32S, L16/24, L21/31, L27/38 Fuel oil filter duplex Fuel oil filter duplex - Star-pleated element 25 microns (400/40) (sphere passing mesh) 12-18 cSt 2.5-14 cSt...
Page 131: Mdo / Mgo Cooler
1689458-7.3 MDO / MGO cooler E 11 06 1 Page 1 (3) L28/32S, L27/38S, L23/30DF, L23/30S, L16/24S, L21/31S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H General Figure 1: Fuel temperature versus viscosity. In order to ensure a satisfactory hydrodynamic oil...
Page 132 MAN Diesel & Turbo 1689458-7.3 MDO / MGO cooler E 11 06 1 Page 2 (3) L28/32S, L27/38S, L23/30DF, L23/30S, L16/24S, L21/31S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H led after the service tank, the supply pumps will Engine type kW/cyl.
Page 133 MAN Diesel & Turbo 1689458-7.3 MDO / MGO cooler E 11 06 1 Page 3 (3) L28/32S, L27/38S, L23/30DF, L23/30S, L16/24S, L21/31S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Figure 2: Chiller. 2016.03.03...
Page 135: Hfo/Mdo Changing Valves (V1 And V2)
1624467-7.3 HFO/MDO changing valves (V1 and V2) E 11 10 1 Page 1 (2) L27/38S, L16/24S, L21/31S, L23/30S, L23/30DF, L28/32S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Description Figure 1: Pneumatic diagram for 3-way changing valves V1 & V2.
Page 136 HFO/MDO changing valves (V1 and V2) E 11 10 1 Page 2 (2) L27/38S, L16/24S, L21/31S, L23/30S, L23/30DF, L28/32S, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H In the event of a black-out, or other situations resulting in dead voltage potential, will the remote...
Page 137: B 12 Lubricating Oil System
MAN Diesel & Turbo B 12 Lubricating oil B 12 Lubricating oil system system Page 1 (1) 2018-04-13 - en...
Page 139 MAN Diesel & Turbo 1693562-4.4 Internal lubricating oil system B 12 00 0 Page 1 (3) L27/38S, L27/38 Internal lubricating oil system Figure 1: Diagram for internal lubricating oil system ▪ Lubricating oil thermostatic valve ▪ Duplex full-flow depth filter Pipe description ▪...
Page 140: Internal Lubricating Oil System
MAN Diesel & Turbo 1693562-4.4 Internal lubricating oil system B 12 00 0 Page 2 (3) L27/38S, L27/38 It should, however, be observed that during the run- From the front main bearings channels are ning in period the lubricating oil consumption may bored in the crankshaft for lubricating of the exceed the values stated.
Page 141 MAN Diesel & Turbo 1693562-4.4 Internal lubricating oil system B 12 00 0 Page 3 (3) L27/38S, L27/38 Planned The cleaning intervals is according to " maintenance programme, see D 10 36 0 / 500.25/500.26 ". The sludge amount must be measured either by means of weight or thickness and noted for reference.
Page 143 1699270-8.7 Crankcase ventilation B 12 00 0 Page 1 (2) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, V28/32S-DF, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H of the vent outlet is not less than the aggregate Crankcase ventilation area of the individual crankcase vent pipes The crankcase ventilation is not to be directly con- entering the manifold.
Page 144: Crankcase Ventilation
Crankcase ventilation B 12 00 0 Page 2 (2) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, V28/32S-DF, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H If the combustion air flow rate at 100 % engine load is stated in [kg/h] this can be converted to [m³/h]...
Page 145: Prelubricating Pump
The automatic control of prelubricating must be made by the customer or can be ordered fra MAN Diesel & Turbo. The voltage for the automatic control must be sup-...
Page 146 MAN Diesel & Turbo 1655289-8.10 Prelubricating pump B 12 07 0 Page 2 (2) L27/38S, L21/31S, L16/24S, L16/24, L21/31, L27/38 Electric motor 230/460 V, 60 Hz Engine No. of cyl. Pump type Start cur- Full-load type rent Amp. current Amp.
Page 147 A test operation is therefore necessary for a corresponding long period in accordance with the manufacturer's instructions. Only lubricating oils that have been approved by MAN Diesel & Turbo may be used. See table Approved lubricating oils for HFO-operated MAN Diesel &...
Page 148 010.000.023-11 MAN Diesel & Turbo The ash must be soft. If this prerequisite is not met, it is likely the rate of dep- osition in the combustion chamber will be higher, particularly at the outlet valves and at the turbocharger inlet housing. Hard additive ash promotes pit- ting of the valve seats, and causes valve burn-out, it also increases mechani- cal wear of the cylinder liners.
Page 149 MAN Diesel & Turbo 010.000.023-11 Approx. BN Engines/Operating conditions of fresh oil (mg KOH/g oil) Under unfavourable operating conditions 23/30A, 28/32A and 28/32S, and where the corre- sponding requirements for the oil service life and washing ability exist. In general 16/24, 21/31, 27/38, 32/40, 32/44CR, 32/44K, 40/54, 48/60 as well as 58/64 and 51/60DF for exclusively HFO operation providing the sulphur content is over 1.5 %.
Page 150 Table 4: Limit values for used lubricating oil Tests A monthly analysis of lube oil samples is mandatory for safe engine opera- tion. We can analyse fuel for customers in the MAN Diesel & Turbo Prime- ServLab. 4 (5) D010.000.023-11-0001 EN...
Page 151 Aurelia TI 4030 Aurelia TI 4040 Aurelia TI 4055 Table 5: Approved lube oils for heavy fuel oil-operated MAN Diesel & Turbo four-stroke engines The current releases are available at http://dieselturbo.man.eu/lubrication. No liability assumed if these oils are used MAN Diesel & Turbo SE does not assume liability for problems that occur when using these oils.
Page 152 Only lubricating oils that have been approved by MAN Diesel & Turbo may be used. These are listed in the tables below. Specifications...
Page 153 Lube oils of military specification O-278 may be used if they are listed in the table Lube oils approved for use in MAN Diesel & Turbo four-stroke engines that run on gas oil and diesel fuel. Lube oils not listed here may only be used after consultation with MAN Diesel &...
Page 154 2 weeks prior to resuming HFO operation. Tests A monthly analysis of lube oil samples is mandatory for safe engine opera- tion. We can analyse fuel for customers in the MAN Diesel & Turbo Prime- ServLab. D010.000.023-07-0001 EN...
Page 155 Disola M4015 With sulphur content in the fuel of less than 1% Table 3: Lube oils approved for use in MAN Diesel & Turbo four-stroke engines that run on gas oil and diesel fuel The current releases are available at http://dieselturbo.man.eu/lubrication.
Page 156 MAN Diesel & Turbo 010.000.023-07 Limit value Procedure Guide value only max. 50 ppm max. 10 ppm max. 15 ppm – max. 20 ppm max. 10 ppm max. 20 ppm When operating with biofuels: max. 12 % FT-IR biofuel fraction Table 4: Limit values for used lubricating oil D010.000.023-07-0001 EN...
Page 157 The lubricating oil density, ρ @ 15°C must be known in order to convert ρ to the present lubricating oil temperature in the base frame. The following for- mula is used to calculate ρ: 1 (3) L28/32H; L27/38; L23/30H; L21/31; L16/24; V28/32S; V28/32H; L28/32DF; L23/30DF; L16/24S; L21/31S; L27/38S; L28/32S; L23/30S EN...
Page 158 *) A deviation of ± 1 mm with the dipstick measurement must be expected, which corresponds uptill ± 0.1 g/kWh, depending on the engine type. 2 (3) L28/32H; L27/38; L23/30H; L21/31; L16/24; V28/32S; V28/32H; L28/32DF; L23/30DF; L16/24S; L21/31S; L27/38S; L28/32S; L23/30S EN...
Page 159 B 12 15 0 MAN Diesel & Turbo 3 (3) L28/32H; L27/38; L23/30H; L21/31; L16/24; V28/32S; V28/32H; L28/32DF; L23/30DF; L16/24S; L21/31S; L27/38S; L28/32S; L23/30S EN...
Page 160 Therefore it is mandatory to clean the lubricating oil with a bypass separator unit, so that the wear rates are reduced and the life- time of the engine is extended. 1 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 161 ▪ Decanter unit ▪ Self cleaning automatic bypass mesh filter ▪ Built-on centrifugal bypass filter (standard on MAN Diesel & Turbo, Holeby GenSets) ▪ Bypass depth filter The decanter unit, the self-cleaning automatic bypass mesh filter and the bypass depth filter capacity must be adjusted according to maker’s recom- mendations.
Page 162 Practical experience has revealed that the content of insolubles, before and after the centrifuge, is related to the flow rate as shown in Fig. 1. 3 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 163 25% of the maximum centrifuge capacity. Operation flow In order to calculate the required operation flow through the separator unit, MDT recommends to apply the following formula: 4 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 164 23.5 hours, the calculation is as follows: Figure 3: One separator per engine plant 5 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 165 100% of the GenSet power installed. 1 Interconnected valves Figure 4: One common separator unit for multi-engine plant 6 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 166 Centrifugal force enables the efficient separation of par- ticles which are only a few microns in size. The separation efficiency is a function of: 7 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 167 It is often seen that the lubricating oil pre-heaters are undersized, have very poor temperature control, the steam supply to the pre-heater is limited or the temperature set point is too low. 8 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 168 Speed control of the pump motor with a frequency converter or a 2- speed motor. This is a relatively cheap solution today and is a good alternative for flow control. 9 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 169 ▪ Paint in the crankcase peels off or blisters ▪ Excessive carbon is formed in the piston cooling chamber 10 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 170 Either by sucking up sediment water from the bottom, or by replacing the oil in the sump. An oil sample must be analysed immediately for chloride ions. 11 (11) L28/32S; L27/38S; L23/30S; L21/31S; L16/24S; L23/30DF; V28/32S-DF; L28/32DF; V28/32H; V28/32S; L16/24; L21/31; L23/30H; L27/38; L28/32H EN...
Page 171: Criteria For Cleaning/Exchange Of Lubricating Oil
1609533-1.7 Criteria for cleaning/exchange of lubricating oil B 12 15 0 Page 1 (2) L23/30S, L28/32S, L27/38S, L21/31S, L16/24S, L23/30DF, V28/32S-DF, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Replacement of lubricating oil 2. Flash point The expected lubricating oil lifetime in operation is Min.
Page 172 1609533-1.7 Criteria for cleaning/exchange of lubricating oil B 12 15 0 Page 2 (2) L23/30S, L28/32S, L27/38S, L21/31S, L16/24S, L23/30DF, V28/32S-DF, L28/32DF, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H 6. Insolubles content Max. value : 1.5 % generally, depending upon...
Page 173: B 13 Cooling Water System
MAN Diesel & Turbo B 13 Cooling water B 13 Cooling water system system Page 1 (1) 2018-04-13 - en...
Page 174: Specification Of Engine Coolant
≙ 0.357 mval/l ≙ 0.179 mmol/l 1 mg/l ≙ 1 ppm Testing equipment The MAN Diesel & Turbo water testing equipment incorporates devices that determine the water properties directly related to the above. The manufactur- ers of anticorrosive agents also supply user-friendly testing equipment.
Page 175 010.000.023-13 MAN Diesel & Turbo Hardness The total hardness of the water is the combined effect of the temporary and permanent hardness. The proportion of calcium and magnesium salts is of overriding importance. The temporary hardness is determined by the carbo- nate content of the calcium and magnesium salts.
Page 176 MAN Diesel & Turbo 010.000.023-13 Additives for coolants Only the additives approved by MAN Diesel & Turbo and listed in the tables under the paragraph entitled Permissible cooling water additives may be used. Required release A coolant additive may only be permitted for use if tested and approved as per the latest directives of the ICE Research Association (FVV) “Suitability test...
Page 177 Antifreeze may only be added after approval by MAN Diesel & Turbo. Before an antifreeze agent is used, the cooling system must be thoroughly cleaned.
Page 178 MAN Diesel & Turbo 010.000.023-13 been done, the engine coolant must be immediately treated with anticorro- sive agent. Once the engine has been brought back into operation, the cleaned system must be checked for leaks. Regular checks of the coolant condition and coolant system Treated coolant may become contaminated when the engine is in operation, which causes the additive to loose some of its effectiveness.
Page 179 Auxiliary engines If the coolant system used in a MAN Diesel & Turbo two-stroke main engine is used in a marine engine of type 16/24, 21/ 31, 23/30H, 27/38 or 28/32H, the coolant recommendations for the main engine must be observed.
Page 180 MAN Diesel & Turbo 010.000.023-13 Nitrite-free additives (chemical additives) Manufacturer Product designation Concentration range [Vol. %] Chevron, Arteco Havoline XLI 7.5 – 11 Total WT Supra 7.5 – 11 Q8 Oils Q8 Corrosion Inhibitor 7.5 – 11 Long-Life Table 3: Nitrite-free chemical additives...
Page 181: Coolants Inspecting
The following equipment can be used: fresh water quality ▪ The MAN Diesel & Turbo water testing kit, or similar testing kit, with all necessary instruments and chemicals that determine the water hardness, pH value and chloride content (obtainable from MAN Diesel & Turbo or Mar-Tec Marine, Hamburg).
Page 182 Chemical slushing oils can only provide effective protection if the right con- centration is precisely maintained. This is why the concentrations recommen- ded by MAN Diesel & Turbo (quality specifications in Volume 010.005 Engine – operating manual 010.000.023-14) must be complied with in all cases.
Page 183 Products that remove limescale deposits are generally suitable for removing rust. Suitable cleaning agents are listed alphabetically in the table entitled Cleaning agents for removing limescale and rust deposits. Products by other manufacturers can be used providing they have similar properties. The man- M010.000.002-04-0001 EN 1 (3)
Page 184 010.000.002-04 MAN Diesel & Turbo ufacturer's instructions for use must be strictly observed. Prior to cleaning, check whether the cleaning agent is suitable for the materials to be cleaned. The products listed in the table entitled Cleaning agents for removing lime- scale and rust deposits are also suitable for stainless steel.
Page 185 MAN Diesel & Turbo 010.000.002-04 Danger of chemical burns From cleaning agents poisonous gases and fumes can develop, which may cause light to severe person injuries. • Wear protective clothing • Provide adequate ventilation • Do not inhale developed gases and fumes •...
Page 187: Quality Of Raw-Water In Cooling Tower Operation
MAN Diesel & Turbo Quality of raw-water in cooling tower operation 1699250-5.0 B 13 00 0 Page 1 (2) (additive and circulating water) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Description Additive water This guideline specifies the basic demands made The system water losses caused by blowing down, on cooling water for cooling tower operation.
Page 188 MAN Diesel & Turbo Quality of raw-water in cooling tower operation 1699250-5.0 B 13 00 0 Page 2 (2) (additive and circulating water) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Growth by algeas, shells and bacteria colonies...
Page 189: Quality Of Water Used In Exhaust Gas Boiler Plants
MAN Diesel & Turbo 1699251-7.0 Quality of water used in exhaust gas boiler plants B 13 00 0 Page 1 (2) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Conditions Saltless Low-salt or circulating water salt-laden Like fuel, lube oil and engine cooling water, water...
Page 190 • Hardness, daily already exist in the boiler system). • Iron content MAN Diesel & Turbo recommends using combina- • Acid capacity of up to pH 8.2 (pH value). tion products. This simplifies the treatment and • Additive concentration (according to manufacturer...
Page 191 1 litre of water ≙ 0.357 mval/l ≙ 0.179 mmol/l Testing instruments The MAN Diesel water testing kit contains instruments that allow the water characteristics referred to above (and others) to be easily determined. Additional information Distillate If distillate (e.g. from the fresh water generator) or fully desalinated water (ion exchanger) is available, this should ideally be used for the fuel-water emul- sion.
Page 193 MAN Diesel & Turbo 3700201-8.0 Internal cooling water system B 13 00 3 Page 1 (2) L27/38S, L27/38 Internal cooling water system Figure 1: Diagram for internal cooling water system (for guidance only, please see the plant specific engine diagram)
Page 194 MAN Diesel & Turbo 3700201-8.0 Internal cooling water system B 13 00 3 Page 2 (2) L27/38S, L27/38 with ø3 mm hole. This is for the internal connections of the engine to improve preheating of the engine at stand-by. High temperature circuit...
Page 195: Internal Cooling Water System
MAN Diesel & Turbo 3700203-1.0 Internal cooling water system B 13 00 6 Page 1 (2) L27/38S, L27/38 Internal cooling water system Figure 1: Diagram for internal cooling water system (for guidance only, please see the plant specific engine diagram) The engine is equipped with a self-controlling tem- perature water circuit.
Page 196: Internal Cooling Water System
MAN Diesel & Turbo 3700203-1.0 Internal cooling water system B 13 00 6 Page 2 (2) L27/38S, L27/38 High temperature circuit The built-on engine-driven HT-circulating pump of the centrifugal type pumps water through the first stage of the charge air cooler and then through the distributing bore to the bottom of the cooling water guide jacket.
Page 197: Design Data For The External Cooling Water System
MAN Diesel & Turbo 1665774-3.7 Design data for the external cooling water system B 13 00 0 Page 1 (1) L27/38S, L27/38 The venting pipe must be connected to the expan- General sion tank below the minimum water level; this pre-...
Page 199: Two String Central Cooling Water System
MAN Diesel & Turbo 1699122-4.1 Two string central cooling water system B 13 00 6 Page 1 (2) V28/32S, L28/32S, L23/30S, L21/31S, L16/24S, L27/38S Two string central cooling water system Figure 1: Central cooling water system. The LT cooling water is used for the cooling of 2.
Page 200 MAN Diesel & Turbo 1699122-4.1 Two string central cooling water system B 13 00 6 Page 2 (2) V28/32S, L28/32S, L23/30S, L21/31S, L16/24S, L27/38S Pressurized expansion tank(s) is installed in the HT cooling water system(s), to accomodate the differ- ences in the water volume due to the changes in the temperatures.
Page 201: Expansion Tank
Expansion tank B 13 00 0 Page 1 (1) L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, V28/32S-DF, V28/32H, L28/32S, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H General To provide for changes in volume in the closed jacket water cooling system caused by changes in temperature or leakage, an expansion tank must be installed.
Page 203: Preheater Arrangement In High Temperature System
MAN Diesel & Turbo 3700160-9.0 Preheater arrangement in high temperature system B 13 23 1 Page 1 (1) L27/38S, L27/38 General The built-on cooling water preheating unit consists of a thermostat-controlled el-preheating element built onto the outlet connection on the thermostat housing on the engine's front end box.
Page 205 MAN Diesel & Turbo 1671771-3.5 Expansion tank pressurized T 13 01 1 Page 1 (2) L28/32S, L27/38S, L21/31S, L16/24S, L23/30DF, V28/32S-DF, V28/32H, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Description Engine type Expansion volume Recommended tank volume litre* 5L23/30H, 5L23/30H Mk2, 5L23/30S, 5L23/30DF...
Page 206: Expansion Tank Pressurized
1671771-3.5 Expansion tank pressurized T 13 01 1 Page 2 (2) L28/32S, L27/38S, L21/31S, L16/24S, L23/30DF, V28/32S-DF, V28/32H, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Figure 1: Function of expansion tank. ▪ Water connection in the top ensures easy and simple installation and control under operation.
Page 207: B 14 Compressed Air System
MAN Diesel & Turbo B 14 Compressed B 14 Compressed air system air system Page 1 (1) 2018-04-13 - en...
Page 208 MAN Diesel & Turbo 010.000.023-21 Specification of compressed air General For compressed air quality observe the ISO 8573-1:2010. Compressed air must be free of solid particles and oil (acc. to the specification). Requirements Compressed air quality of The starting air must fulfil at least the following quality requirements accord- ing to ISO 8573-1:2010.
Page 209 010.000.023-21 MAN Diesel & Turbo ▪ Purity regarding solid particles Quality class 3 ▪ Purity regarding moisture Quality class 4 ▪ Purity regarding oil Quality class 2 Clogging of catalysts To prevent clogging of catalysts and catalyst lifetime shortening, the compressed air specification must always be observed.
Page 211: Compressed Air System
MAN Diesel & Turbo 3700205-5.1 Compressed air system B 14 00 0 Page 1 (2) L27/38S, L27/38 Compressed air system Figure 1: Diagram for 10 bar compressed air system (for guidance only, please see the plant specific engine diagram) injection pump. On 8 and 9 cylinder engines air is...
Page 212: Compressed Air System
MAN Diesel & Turbo 3700205-5.1 Compressed air system B 14 00 0 Page 2 (2) L27/38S, L27/38 For remote activation the starting coil is connected so that every starting signal to the starting coil goes through the safe start function which is connected to the safety system mounted on the engine.
Page 213 MAN Diesel & Turbo 3700206-7.1 Compressed air system B 14 00 0 Page 1 (2) L27/38S, L27/38 Compressed air system Figure 1: Diagram for 30 bar compressed air system (for guidance only, please see the plant specific engine diagram). General...
Page 214 MAN Diesel & Turbo 3700206-7.1 Compressed air system B 14 00 0 Page 2 (2) L27/38S, L27/38 Control system The air starter is activated electrically with a pneu- matic 3/2-way solenoid valve. The valve can be activated manually from the starting box on the engine, and it can be arranged for remote control, manual or automatic.
Page 215 MAN Diesel & Turbo 1655207-3.2 Compressed air system B 14 00 0 Page 1 (1) L27/38S, L21/31S, L16/24S, L16/24, L21/31, L27/38 Diagram Figure 1: Diagram for compressed air system ▪ The starting air pipes should be mounted with a slope towards the receivers, preventing possi-...
Page 217: B 15 Combustion Air System
MAN Diesel & Turbo B 15 Combustion air B 15 Combustion air system system Page 1 (1) 2018-04-13 - en...
Page 219: Combustion Air System
The engine is as standard equipped with a high-effi- with quick coupling - inlet cient MAN Diesel & Turbo TCR turbocharger of the radial type, which is located on the top of the front Table 1: P2 flange connections are standard according to DIN end box.
Page 220 MAN Diesel & Turbo 1665736-1.7 Combustion air system B 15 00 0 Page 2 (2) L27/38S, L27/38 Lambda controller The purpose of the lambda controller is to prevent injection of more fuel in the combustion chamber than can be burned during a momentary load in- crease.
Page 221: Specifications For Intake Air (Combustion Air)
MAN Diesel & Turbo 010.000.023-17 Specifications of intake air (combustion air) General The quality and condition of intake air (combustion air) have a significant effect on the engine output, wear and emissions of the engine. In this regard, not only are the atmospheric conditions extremely important, but also con- tamination by solid and gaseous foreign matter.
Page 222 010.000.023-17 MAN Diesel & Turbo Properties Limit Unit Dust (sand, cement, CaO, Al etc.) max. 5 mg/Nm Chlorine max. 1.5 Sulphur dioxide (SO max. 1.25 Hydrogen sulphide (H max. 5 Salt (NaCl) max. 1 One Nm corresponds to one cubic meter of gas at 0 °C and 101.32 kPa.
Page 223: Engine Room Ventilation And Combustion Air
MAN Diesel & Turbo 1699110-4.1 Engine room ventilation and combustion air B 15 00 0 Page 1 (1) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H, L32/40 Combustion air requirements ▪ The combustion air must be free from water spray, dust, oil mist and exhaust gases.
Page 225: Water Washing Of Turbocharger - Compressor
1639499-6.0 Water washing of turbocharger - compressor B 15 05 1 Page 1 (1) L23/30DF, L28/32S, L27/38S, L23/30S, L21/31S, L28/32DF, V28/32S, L21/31, L23/30H, L27/38, L28/32H Description During operation the compressor will gradually be fouled due to the presence of oil mist and dust in the inlet air.
Page 227: B 16 Exhaust Gas System
MAN Diesel & Turbo B 16 Exhaust gas B 16 Exhaust gas system system Page 1 (1) 2018-04-13 - en...
Page 229 Position of gas outlet on turbocharger MAN Diesel & Turbo will be pleased to assist in B 16 02 0 shows turning alternatives positions of making a calculation of the exhaust back-pressure.
Page 230 1655213-2.6 Exhaust gas system B 16 00 0 Page 2 (4) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H Exhaust gas boiler To utilize the thermal energy from the exhaust, an exhaust gas boiler producing steam or hot water can be installed.
Page 231 MAN Diesel & Turbo 1655213-2.6 Exhaust gas system B 16 00 0 Page 3 (4) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H 2015.01.14...
Page 232: Exhaust Gas System
1655213-2.6 Exhaust gas system B 16 00 0 Page 4 (4) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H Resulting installation demands If the recommended exhaust gas back pressure cannot be kept due to exhaust gas after treatment installations.
Page 233: Pressure Droop In Exhaust Gas System
Pressure droop in exhaust gas system B 16 00 0 Page 1 (2) L28/32S, L23/30S, L27/38S, L21/31S, L16/24S, V28/32S-DF, V28/32H, L23/30DF, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H General Figure 1: Nomogram for pressure drop in exhaust gas piping system.
Page 234 Pressure droop in exhaust gas system B 16 00 0 Page 2 (2) L28/32S, L23/30S, L27/38S, L21/31S, L16/24S, V28/32S-DF, V28/32H, L23/30DF, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H The exhaust system is correctly designed since the permissible total resistance of 30 mbar is not exceeded.
Page 235: Scr (Selective Catalytic Reduction
SCR technology MAN Diesel & Turbo decided to develop it's own SCR technology to be able to optimise the emis- sions technology and the engine performance in addition with the MAN Diesel & Turbo own SCR control programme to the utmost customer benefit.
Page 236 ▪ Exhaust gas temperature informations are continuously and currently availa- ble. This is one of the important benefits of the MAN ▪ Catalyst modules (AV, SV or LV value) Diesel & Turbo SCR system.
Page 237 Standard operation Common SCR systems provided by third parties require constantly high exhaust gas temperatures. The MAN Diesel & Turbo SCR system on the other hand is an integrated engine + SCR system that allows operation on lower exhaust gas temperature levels.
Page 238 IMO II, even if the SCR system is still out of service. MAN Diesel & Turbo can only deliver an IMO Tier III certificate and act as “Applicant” (within the ▪ Differential pressure Δp SCR (normal operation): meaning of the IMO) if the engine plus SCR sys- –...
Page 239 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 5 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24...
Page 240 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 6 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Engine Maxi- Serv power (Tot (Wit (Wit (Wit Main dimensions, weights and views of approxi...
Page 241 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 7 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Figure 3: Mixing unit with urea lance...
Page 242 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 8 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Mixing unit with urea lance Pump module Mix- Engine power Mixing pipe Length Pump Height...
Page 243 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 9 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Specification for engine supplies Specification of urea solution Use of good quality urea solution is essential for the operation of a SCR catalyst.
Page 244 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 10 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Urea solution ISO 22241-2 concentration Annex C 39 - 41 Sodium [mg/kg] max. 0.5 ISO 22241-2...
Page 245 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 11 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Urea solution ISO 22241-2 concentration Annex C 31.8 - 33.2 Zinc [mg/kg] max. 0.2 ISO 22241-2...
Page 246 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 12 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Engine supply systems SCR system The metal eyelets are designed to carry only the The SCR system uses aqueous urea solution and a...
Page 247 The urea injection and the mixing unit have to be pressure relief valve to ensure the required urea positioned according to MAN Diesel & Turbo flow. requirements. In general, the mixing section is between 3.0 –...
Page 248 V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 vertical and consists of several layers of catalysts. For horizontal installation, please contact MAN Die- sel & Turbo. The reactor is equipped with differential pressure and temperature monitoring, openings for inspection, a maintenance door for service and the soot blowing system for each layer.
Page 249 Use of good quality urea is essential for the opera- All parts mentioned in this paragraph are not MAN tion of an SCR catalyst. Using urea not complying Diesel & Turbo scope of supply.
Page 250 MAN Diesel & Turbo 3700467-8.1 SCR (Selective Catalytic Reduction) B1600 0 Page 16 (17) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Water entry into the reactor housing must be avoi- ded, as this can cause damage and clogging of the catalyst.
Page 251 Catalyst elements could reach a weight of 25 kg, the reactor openings could reach a total weight of about 70 kg, MAN Diesel & Turbo strongly recom- mends a lifting capability above the reactors. A very important point is the transportation way and...
Page 253: Equipment To Optimize Performance
When operating engines under full load at a low Overview intake temperature (≤ 5°C) there is a danger, due to MAN Diesel & Turbo four-stroke Diesel engines and the high air density, that the charge pressure, and turbochargers are designed in accordance with therefore the ignition pressure, increases exces- specifications so that optimum results, e.g.
Page 254 MAN Diesel & Turbo 3700546-9.0 Equipment to optimize performance B1600 0 Page 2 (3) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 ▪ Control of exhaust gas temperature for SCR Charge air preheating – via LT (low temperature) cut-out is used in the partial load range from 0 % to operation.
Page 255 MAN Diesel & Turbo 3700546-9.0 Equipment to optimize performance B1600 0 Page 3 (3) V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Figure 1: Overview of flaps...
Page 257: Exhaust Gas Velocity
MAN Diesel & Turbo 3700152-6.2 Exhaust gas velocity B 16 01 0 Page 1 (4) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H Velocities Exhaust gas Engine type Exhaust gas flow Exhaust gas temp. Nominal diameter velocity kg/h °C...
Page 258 MAN Diesel & Turbo 3700152-6.2 Exhaust gas velocity B 16 01 0 Page 2 (4) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H Exhaust gas Engine type Exhaust gas flow Exhaust gas temp. Nominal diameter velocity kg/h °C...
Page 259 MAN Diesel & Turbo 3700152-6.2 Exhaust gas velocity B 16 01 0 Page 3 (4) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H Exhaust gas Engine type Exhaust gas flow Exhaust gas temp. Nominal diameter velocity kg/h °C...
Page 260 MAN Diesel & Turbo 3700152-6.2 Exhaust gas velocity B 16 01 0 Page 4 (4) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L28/32DF, L16/24, L21/31, L23/30H, L27/38, L28/32H The exhaust gas velocities are based on the pipe dimensions in the table below...
Page 261: Cleaning The Turbocharger In Service - Turbine Side
3700418-8.1 Cleaning the turbocharger in service - turbine side B 16 01 3 Page 1 (6) L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30DF, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Description High exhaust gas temperatures are often observed and claimed in service. High exhaust gas tempera-...
Page 262 3700418-8.1 Cleaning the turbocharger in service - turbine side B 16 01 3 Page 2 (6) L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30DF, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Cleaning system The cleaning system consists of a cleaning agent container (2) with a capacity of approx. 0.5 liters and a removable cover.
Page 263 MAN Diesel & Turbo 3700418-8.1 Cleaning the turbocharger in service - turbine side B 16 01 3 Page 3 (6) L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30DF, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 2017.01.24...
Page 264 MAN Diesel & Turbo 3700418-8.1 Cleaning the turbocharger in service - turbine side B 16 01 3 Page 4 (6) L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30DF, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 2017.01.24...
Page 265 3700418-8.1 Cleaning the turbocharger in service - turbine side B 16 01 3 Page 5 (6) L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30DF, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Water washing of turbine side Heavily contaminated turbines, which where not...
Page 266 Cleaning the turbocharger in service - turbine side B 16 01 3 Page 6 (6) L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30DF, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Water washing arrangement / tool Some customized engines are delivered with water...
Page 267: Position Of Gas Outlet On Turbocharger
MAN Diesel & Turbo 1689481-3.2 Position of gas outlet on turbocharger B 16 02 0 Page 1 (2) L27/38S, L27/38 Dimensions Dimensions Engine type 5L27/38 (TCR18) 775.5 880.2 2532 6L27/38 (TCR18) 775.5 880.2 2532 7L27/38 (TCR20) 775.5 939.8 2719 8L27/38 (TCR20) 775.5...
Page 268 MAN Diesel & Turbo 1689481-3.2 Position of gas outlet on turbocharger B 16 02 0 Page 2 (2) L27/38S, L27/38 Exhaust flange D. mating dimensions Engine type Hole size No of (mm) (mm) (mm) (mm) (mm) holes 5L27/38, 720/750 rpm (300/320 kW) (TCR18)
Page 269: B 17 Speed Control System
MAN Diesel & Turbo B 17 Speed control B 17 Speed control system system Page 1 (1) 2018-04-13 - en...
Page 271: Starting Of Engine
MAN Diesel & Turbo 1655204-8.8 Starting of engine B 17 00 0 Page 1 (1) L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38 General The engine can be loaded according to the follow- Starting on MDO ing procedure: For starting on MDO there are no restrictions A) Normal start without preheated cooling water.
Page 273: Power Management - Alternator Protection
3700383-8.2 Power Management - Alternator protection B 17 00 0 Page 1 (6) L23/30DF, L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 It is protecting of the generator against abnormally Description high net voltage, works with phase to phase and...
Page 274 Power Management - Alternator protection B 17 00 0 Page 2 (6) L23/30DF, L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Application: To control the power flow, between to Ground faults and faults between phases outside two more power producing plants.
Page 275 Power Management - Alternator protection B 17 00 0 Page 3 (6) L23/30DF, L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 tion of the surge arrestors is not allowed to use the This system can be used in ships or smaller power...
Page 276 The alternator supplier can be requested from the Excitation Current Rated IeN ( amp ) customer or MAN Diesel & Turbo to put other set- Excitation Resistance Re ( ohms ) tings in the AVR. Such customize settings must be informed to MAN Diesel &...
Page 277 Power Management - Alternator protection B 17 00 0 Page 5 (6) L23/30DF, L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 The length of the U shall min. be 1 meter the cable Classification Cooling air Temp.
Page 278 MAN Diesel & Turbo 3700383-8.2 Power Management - Alternator protection B 17 00 0 Page 6 (6) L23/30DF, L28/32DF, V28/32S, L28/32S, L28/32H, L27/38S, L27/38, L23/30S, L23/30H, L21/31S, L21/31, L16/24S, L16/24 Alternator protection settings Required by MAN Diesel Nice to have Short Circuit phase L1 –...
Page 279: Engine Operation Under Arctic Conditions
▪ If a concentration of anti-freezing agents of > 50 SaCoS/SaCoS % is needed, please contact MAN Diesel & SaCoS/SaCoS equipment is suitable to be stored Turbo for approval.
Page 280 MAN Diesel & Turbo 1689459-9.0 Engine operation under arctic conditions B 17 00 0 Page 2 (2) L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38 below temperatures of +5°C additional special measures are needed – in this case please contact MAN Diesel & Turbo.
Page 281: Actuators
MAN Diesel & Turbo 1689484-9.0 Actuators B 17 01 2 Page 1 (1) L27/38S, L21/31S, L16/24S, L16/24, L21/31, L27/38 Actuator types As standard, the engines are equipped with an electro-hydraulic actuator, make Regulateurs Europa, type 2800; or make Woodward, type UG25+.
Page 283: Actuators
3700319-4.1 Actuators B 17 01 6 Page 1 (1) L27/38S, L27/38, L21/31S, L21/31, L16/24S, L16/24, L23/30DF, L28/32DF Actuator types The engines can be equipped with an electro- hydraulic actuator, make Regulateurs Europa, type 2800. Speed Control is carried out via SaCoS GENSET.
Page 285: Actuators
MAN Diesel & Turbo 3700320-4.1 Actuators B 17 01 7 Page 1 (1) L27/38S, L21/31S, L16/24S, L16/24, L27/38, L21/31 Actuator type As optional, the engines are equipped with an elec- tro-hydraulic actuator, make Woodward, type UG25+. Speed Control is carried out via SaCoS GENSET.
Page 287: B 19 Safety And Control System
MAN Diesel & Turbo B 19 Safety and B 19 Safety and control system control system Page 1 (1) 2018-04-13 - en...
Page 288 B 19 00 0 MAN Diesel & Turbo Operation data and set points Engine load @ MCR Description Normal value at full Acc. Alarm set point Delay Auto stop of engine load at value * 100 % load sec. ISO conditions...
Page 289 B 19 00 0 MAN Diesel & Turbo Description Normal value at full Acc. Alarm set point Delay Auto stop of engine load at value * 100 % load sec. ISO conditions Exhaust gas and charge air Exhaust gas temperature °C...
Page 290 B 19 00 0 MAN Diesel & Turbo Description Normal value at full Acc. Alarm set point Delay Auto stop of engine load at value * 100 % load sec. ISO conditions Engine run SI 90 SS 90A 720/750 rpm...
Page 291 B 19 00 0 MAN Diesel & Turbo D. Software created signal Software created signal from PI 22, TI 12, SI 90. SAH 81 is always activated together with SSH 81. E. Set points depending on fuel temperature Figure 1: Set point curve F.
Page 292 B 19 00 0 MAN Diesel & Turbo J. Limits for turbocharger overspeed alarm (SAH 89) TC overspeed alarm Matching 41XXX 42XXX TCR12 65300 68800 TCR14 54100 57000 TCR16 45000 47400 TCR18 37100 39000 TCR20 30800 32400 K. Exhaust gas temperatures The exhaust gas temperature deviation alarm is normally ±50°...
Page 293 SaCoS GENSET MAN Diesel &Turbo SE System description Revision 1.5...
Page 294 Chapter “2.3 Speed control system” and power supply 14.06.2010 Karger modified 16.08.2010 Karger Chapter 3.8.: corrected power supply for safety system This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 2 of 13 to whom it has been handed over.
Page 295 Remote control ......................12 Ethernet interface ......................12 Serial interface......................12 Power supply ....................... 12 Crankcase Monitoring Unit (optional) ................ 13 This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 3 of 13 to whom it has been handed over.
Page 296: General Information
PLC for the safety system. The Display Module also acts as safety system for over speed, low lubrication oil pressure and high cooling water temperature. This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009...
Page 297: Connection Box
The Connection Box is the central connecting and distribution point for the 24 VDC power supply of the whole system. Furthermore it connects the Control Unit with the GenSet, the ship alarm system and the optional crankcase monitoring. This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 5 of 13 to whom it has been handed over.
Page 298: System Bus
Ethernet system operation configuration safety system safety system This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 6 of 13 to whom it has been handed over. Copying and communicating to third Last change: 16.08.2010...
Page 299: Technical Data
1356 mm Weight 60 kg 60 kg 65 kg This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 7 of 13 to whom it has been handed over. Copying and communicating to third Last change: 16.08.2010...
Page 300: System Description
High oilmist concentration in crankcase. (optional) Remote Shutdown. (optional) o Differential protection (optional) o Earth connector closed (optional) o Gas leakage (optional) This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 8 of 13 to whom it has been handed over.
Page 301: Alarm/Monitoring System
The engine electronic speed control is realized by the Control Module. As standard, the engine is equipped with an electro-hydraulic actuator. Speed adjustment Local, manual speed setting is possible at the Control Unit with a turn switch. This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 9 of 13 to whom it has been handed over.
Page 302 By droop setting. Engine stop Engine stop can be initiated local at the display module and remote via a hardware channel or the bus interface. This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 10 of 13 to whom it has been handed over.
Page 303: Interfaces To External Systems
= CAN connection * = option ** = only 32/40 external systems GenSet This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009 Karger Page 11 of 13 to whom it has been handed over. Copying and communicating to third Last change: 16.08.2010...
Page 304: Data Machinery Interface
The alarm system requires a 24V DC, 12,5 A uninterrupted power supply with a 16 A pre-fuse. The safety system requires a 24V DC, 8,5 A uninterrupted power supply with a 10 A pre-fuse. This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009...
Page 305: Crankcase Monitoring Unit (Optional)
SaCoS GENSET and is not scope of supply. If applied, it is delivered as stand- alone system in an extra control cabinet. This document is property of MAN Diesel & Turbo SE and is entrusted Created: 03.08.2009...
Page 306 MAN Diesel & Turbo SaCoS GENSET Communication from GenSet Revision ..........1.7...
Page 307 ESPP ESPP ESPP ESPP ESPP ESPP ESPP EESPD MAN Diesel & Turbo 86224 Augsburg, Germany Phone +49 821 322-0 +49 821 322-3382 info-de@mandieselturbo.com www.mandieselturbo.com Copyright © 2012 MAN Diesel & Turbo All rights reserved, including reprinting, copying (Xerox/microfiche) and translation.
Page 308 MAN Diesel & Turbo Table of Contents Data Bus Interface (Machinery Alarm System) ..............1 Modbus RTU protocol ......................2 Settings ............................. 2 Function Codes ......................... 2 Message Frame Separation ....................... 3 Provided Data ........................... 3 2.4.1 Contents of List of Signals ......................3 2.4.2...
Page 309 MAN Diesel & Turbo...
Page 310: Data Bus Interface (Machinery Alarm System)
MAN Diesel & Turbo 1 Data Bus Interface (Machinery Alarm System) This interface serves for data exchange to ship alarm systems or integrated automation systems (IAS). The status messages, alarms and safety actions, which are generated in the system, can be transferred. All measuring values and alarms acquired by SaCoS GENSET are available for transfer.
Page 311: Modbus Rtu Protocol
MAN Diesel & Turbo 2 Modbus RTU protocol The Modbus RTU protocol is the standard protocol used for the communica- tion from the GenSet. The bus interface provides a serial connection. The protocol is implemented according to the following definitions:...
Page 312: Message Frame Separation
MAN Diesel & Turbo Function Function Code Description Code (hexadecimal) 0x16 mask write register 0x17 read write multiple registers 2.3 Message Frame Separation Message frames shall be separated by a silent interval of at least 4 character times. 2.4 Provided Data Provided data includes measured values and alarm or state information of the engine.
Page 313: Modbus Ascii Protocol
MAN Diesel & Turbo 3 Modbus ASCII protocol 3.1 General The communication setup is: 9600 baud, 8 databits, 1 stopbit, no parity. The Modbus protocol accepts one command (Function Code 03) for reading analogue and digital input values one at a time, or as a block of up to 32 in- puts.
Page 314 MAN Diesel & Turbo FCT = 03H: Read n words The master transmits an inquiry to the slave (CMS) to read a number (n) of datawords from a given address. The slave (CMS) replies with the required number (n) of datawords. To read a single register (n) must be set to 1. To read block type register (n) must be in the range 1...32.
Page 315: Data Format
MAN Diesel & Turbo 3.3 Data Format Example for Modbus ASCII Data Format: Extract from Modbus ASCII list MW 113 71 0 Signal fault ZS82 : Emergency stop SF=1 binary (pushbutton) Signal fault ZS75 : Turning gear SF=1 binary disengaged...
Page 316 MAN Diesel & Turbo In the next step these Hexadecimal values are interpreted as ASCII-signs (ex- tract from ASCII table): Hexadecimal ASCII In this example the letter (ASCII letter) 1 will be translated hexadecimal value 31 and so on: 1 --> 31 5 -->...
Page 317: Extended Operating Hour Counters Via Modbus
MAN Diesel & Turbo 4 Extended operating hour counters via MODBUS The operating hour counter and the overload hour counter are available via the Modbus Interface. The maximum range was extended to 1,193,046 hours in CM-Software version 1.2.1. At the Modbus register addresses MW124 and MW125 the existing operat- ing hour counters are still available to ensure compatibility.
Page 318 MAN Diesel & Turbo 5 Modbus list The Modbus list is valid for Modbus ASCII and Modbus RTU. The list can be found in the document “SaCoS- one.GENSET_SignListMan_MP_EN_xx.xx.pdf” where “xx.xx” means the ac- tual revision.
Page 319: Modbus List
MAN Diesel & Turbo 3700054-4.0 Modbus list B 19 00 0 Page 1 (5) L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38 The Modbus list is valid for Modbus ASCII and Modbus RTU Adress Hex Bit Meas. Description Unit Origin Signal Point...
Page 320 MAN Diesel & Turbo 3700054-4.0 Modbus list B 19 00 0 Page 2 (5) L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38 Adress Hex Bit Meas. Description Unit Origin Signal Point range MW 32 TE12 HT cooling water temperature engine outlet 0 - 200...
Page 321 MAN Diesel & Turbo 3700054-4.0 Modbus list B 19 00 0 Page 3 (5) L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38 Adress Hex Bit Meas. Description Unit Origin Signal Point range MW 96 SE90 Engine speed 0..2000 MW 97 SE89 TC speed 0..70000...
Page 322 MAN Diesel & Turbo 3700054-4.0 Modbus list B 19 00 0 Page 4 (5) L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38 Adress Hex Bit Meas. Description Unit Origin Signal Point range MW 118 CAN-1 error binary CAN-2 error binary CAN-3 error...
Page 323 MAN Diesel & Turbo 3700054-4.0 Modbus list B 19 00 0 Page 5 (5) L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38 Adress Hex Bit Meas. Description Unit Origin Signal Point range MW 122 Alarm TAH21 : Lube oil temperature filter inlet high...
Page 325 MAN Diesel & Turbo 1699190-5.0 Oil mist detector B 19 22 1 Page 1 (1) L28/32S, L23/30S, L27/38S, L21/31S, L16/24S, V28/32H, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Description The oil mist detector type Tufmon from company Dr. Horn is standard on the 7, 8 and 9L27/38 engine types and option for all other engine types.
Page 327 MAN Diesel & Turbo B 20 Foundation B 20 Foundation Page 1 (1) 2018-04-13 - en...
Page 329 MAN Diesel & Turbo. Mark the positions of the foundation bolts through the holes in the base plates. Remove the base plates and drill the holes Resilient support for the foundation bolts with conventional tools.
Page 330 This method of fixing the Generating Sets to the base plates is suitable for earthquake conditions up to 7 on the Richter scale (If higher conditions is required, please contact MAN Diesel & Turbo). Instructions for maintenance Generally speaking the mountings will not require maintenance or reconditioning in service unless mis-used or accidently damaged.
Page 331 MAN Diesel & Turbo Resilient mounting system for landbased generating 1699989-9.5 B 20 00 0 Page 3 (5) sets L27/38S, L21/31S, L16/24S Earthquake scales and intensity values Measured at 5 Hz Richter scale Ground acceleration Ground velocity [mm/s] Ground shift [mm]...
Page 332 MAN Diesel & Turbo Resilient mounting system for landbased generating 1699989-9.5 B 20 00 0 Page 4 (5) sets L27/38S, L21/31S, L16/24S 2015.05.11...
Page 333 MAN Diesel & Turbo Resilient mounting system for landbased generating 1699989-9.5 B 20 00 0 Page 5 (5) sets L27/38S, L21/31S, L16/24S 2015.05.11...
Page 335 MAN Diesel & Turbo B 21 Test running B 21 Test running Page 1 (1) 2018-04-13 - en...
Page 337 B 21 01 1 Page 1 (4) V28/32H, V28/32S, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S Shop test programme Operating points MAN Diesel & Turbo programme Test of safety and monitoring system Starting attempts Load acceptance test (value in minutes) Engines driving alternator...
Page 338 MAN Diesel & Turbo 1699986-3.2 Shop test programme for power plants B 21 01 1 Page 2 (4) V28/32H, V28/32S, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S For applications from 0 % to 100 % continuous rating, according to IACS and ISO 8528-5, the following dia- gram is applied: Fig.
Page 339 Regulating test and load responce performance Load step on MAN Diesel & Turbo GenSets is to be tested according to following procedure. Momentum speed variation (m) must not vary more than 10% max. deviation from steady speed 1 %. Perma- nent speed variation (p) must not be higher than 5%.
Page 340 MAN Diesel & Turbo 1699986-3.2 Shop test programme for power plants B 21 01 1 Page 4 (4) V28/32H, V28/32S, L28/32S, L27/38S, L23/30S, L21/31S, L16/24S Fig. 4 Minimum requirements of the classification societies plus ISO rule. bmep: Must be found in product guide. For most classification sociaties 3 x 33% load application will be accepted.
Page 341 MAN Diesel & Turbo E 23 Spare parts E 23 Spare parts Page 1 (1) 2018-04-13 - en...
Page 343 MAN Diesel & Turbo 1689476-6.4 Weight and dimensions of principal parts E 23 00 0 Page 1 (5) L27/38S, L27/38 Cylinder head incl. rocker arms approx. 400 kg Piston approx. 66 kg Cylinder liner approx. 140 kg Charge air cooler approx. 490 kg Please note: 5 cyl.
Page 344 MAN Diesel & Turbo 1689476-6.4 Weight and dimensions of principal parts E 23 00 0 Page 2 (5) L27/38S, L27/38 Cylinder unit approx. 700 kg Connecting rod approx. 120 kg Front end box for GenSet approx. 2420 kg Front end box for propulsion approx. 2170 kg...
Page 345 MAN Diesel & Turbo 1689476-6.4 Weight and dimensions of principal parts E 23 00 0 Page 3 (5) L27/38S, L27/38 Please note: 5 cyl. only for GenSet Base frame Length (L)* [mm] Weight [kg] for GenSet one/two bearing one/two bearing 5 cyl.
Page 346 MAN Diesel & Turbo 1689476-6.4 Weight and dimensions of principal parts E 23 00 0 Page 4 (5) L27/38S, L27/38 Valve camshaft Length (L) [mm] Weight [kg] 5 cyl. 2378 6 cyl. 2823 7 cyl. 3268 8 cyl. 3713 9 cyl.
Page 347 MAN Diesel & Turbo 1689476-6.4 Weight and dimensions of principal parts E 23 00 0 Page 5 (5) L27/38S, L27/38 Frame Length (L) [mm] Weight (kg) 5 cyl. 2658 8503 6 cyl. 3103 9886 7 cyl. 3548 11268 8 cyl.
Page 349 Scope of this list are subject to change and therefore the latest version of this document should always be used, please see MAN Diesel & Turbo homepage or Extranet. Spare parts listed may also vary if optional com- ponents are selected.
Page 351 MAN Diesel & Turbo P 24 Tools P 24 Tools Page 1 (1) 2018-04-13 - en...
Page 352 The tool package consists of ordinary hand tools needed in addition to the delivered standard tool for normal maintenance, in connection with the daily maintenance as well as major overhauls. 1 (1) L16/24; L16/24S; L21/31; L21/31S; L23/30H; L23/30S; L23/30DF; L27/38; L27/38S; L28/32S; V28/32S; L28/32DF; L28/32H EN...
Page 353 P 24 01 1 MAN Diesel & Turbo Standard tools for normal maintenance Cylinder head Name Sketch Supply per ship Drawing Remarks Working Spare Item no Valve spring tightening device Lifting tool for cylinder unit Broad chissel Tier II + Stationary 1 (10) L27/38;...
Page 354 P 24 01 1 MAN Diesel & Turbo Piston, connecting rod and cylinder liner Name Sketch Supply per ship Drawing Remarks Working Spare Item no Removing device for flame ring Guide bush for piston Tool for fixing of marine head for counterweight...
Page 355 P 24 01 1 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Lifting device for cylinder liner Lifting device for piston and connecting rod Piston ring opener Supporting device for con- necting rod and piston in...
Page 356 P 24 01 1 MAN Diesel & Turbo Operating gear for inlet and exhaust valves Name Sketch Supply per ship Drawing Remarks Working Spare Item no Feeler gauge Socket wrench Socket wrench and torque spanner 4 (10) Tier II + Stationary...
Page 357 P 24 01 1 MAN Diesel & Turbo Crankshaft and main bearings Name Sketch Supply per ship Drawing Remarks Working Spare Item no Dismantling tool for main bearing upper shell Tier II + Stationary 5 (10) L27/38; L27/38S EN...
Page 358 P 24 01 1 MAN Diesel & Turbo Turbocharger system Name Sketch Supply per ship Drawing Remarks Working Spare Item no Eye screw for lifting Container complete for water washing of compres- sor side Blowgun for dry cleaning of turbocharger...
Page 359 P 24 01 1 MAN Diesel & Turbo Fuel oil system Name Sketch Supply per ship Drawing Remarks Working Spare Item no Pressure testing tool, incl item 051, 053, 054 Clamping bracket for fuel injector Fuel pipe Pressure pump Grinding device for...
Page 360 P 24 01 1 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Combination spanner, 36 Crow foot, 36 mm Long socket spanner 3/4" 41 mm Adapter for torque spanner 1/2" - 3/4" Torque spanner 1/2"...
Page 361 P 24 01 1 MAN Diesel & Turbo Hydraulic tools Name Sketch Supply per ship Drawing Remarks Working Spare Item no Hydraulic tools complete consisting of the following 3 boxes: Pressure pump box 1, consisting of: Pressure pump, complete Manometer...
Page 362 P 24 01 1 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Hydraulic tools box 3 consisting of: Pressure part M24/27 x 2 Tension screw M24/27 x 2 Distribution piece, cylinder head Distribution piece,...
Page 363 P 24 03 9 MAN Diesel & Turbo Additional tools Cylinder head Name Sketch Supply per ship Drawing Remarks Working Spare Item no Grinding tool for cylinder head/liner Max. pressure indicator, 0-250 bar Handle for indicator valve Turning device for...
Page 364 P 24 03 9 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Grinding machine for valve seat ring Supporting spider Mandrel Cutting tool Carbide cutting insert Grinding tool for valves Grinding machine for...
Page 365 P 24 03 9 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Grinding machine for valve spindle, complete Grinding wheel hub Balancing apparatus Grinding wheel dresser Grinding wheel, grain size 46 Grinding wheel,...
Page 366 P 24 03 9 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Reamer for valve guide Touching up device Electronic indicator, HLV 2000 4 (13) L27/38; L27/38S EN...
Page 367 P 24 03 9 MAN Diesel & Turbo Piston, connecting rod and cylinder liner Name Sketch Supply per ship Drawing Remarks Working Spare Item no Tool for fixing of marine head for counterweight Fit and removal device for connecting rod bearing, incl...
Page 368 P 24 03 9 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Piston ring opener Supporting device for con- necting rod and piston in the cylinder liner, incl. fork Testing mandrel for piston ring grooves, 7.43 mm...
Page 369 P 24 03 9 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Support for connecting rod Micrometer screw 250-270 mm 7 (13) L27/38; L27/38S EN...
Page 370 P 24 03 9 MAN Diesel & Turbo Crankshaft and main bearings Name Sketch Supply per ship Drawing Remarks Working Spare Item no Dismantling tool for main bearing upper shell Crankshaft alignment gauge (autolog) Lifting straps for main bear- ing cap...
Page 371 P 24 03 9 MAN Diesel & Turbo Turbocharger system Name Sketch Supply per ship Drawing Remarks Working Spare Item no Eye screw for lifting Fit and removing device for cooler insert Closing cover, TCR20 Closing cover, TCR18 (standard with only one...
Page 372 P 24 03 9 MAN Diesel & Turbo Compressed air system Name Sketch Supply per ship Drawing Remarks Working Spare Item no Set of tools, TDI air starter T100 Fuel oil system Name Sketch Supply per ship Drawing Remarks Working...
Page 373 P 24 03 9 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Fit and removing device for fuel injection pump Setting device for fuel injec- tion pump Assembly device for sealing ring, complete...
Page 374 P 24 03 9 MAN Diesel & Turbo Lubricating oil system Name Sketch Supply per ship Drawing Remarks Working Spare Item no Eye screw for lifting lubri- cating oil cooler Mandrel for lubricating oil cooler Fitting device for lubricating oil cooler 12 (13) L27/38;...
Page 375 P 24 03 9 MAN Diesel & Turbo Hydraulic tools Name Sketch Supply per ship Drawing Remarks Working Spare Item no Resetting device for hydraulic cylinder Air driven high pressure pump for hydraulic valve Remote controlled unit for hydraulic bolt tensioning 13 (13) L27/38;...
Page 376 P 24 05 1 MAN Diesel & Turbo Hand tools Hand tools Name Sketch Supply per ship Drawing Remarks Working Spare Item no Set of tools, consists of: Item 01 Ratchet Item 02 Extension, 125 mm Item 03 Extension, 250 mm...
Page 377 P 24 05 1 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Ratchet, 20 mm Extension bar Socket spanner, square drive, size 24 Socket spanner, square drive, size 30 Socket spanner, square drive, size 36...
Page 378 P 24 05 1 MAN Diesel & Turbo Name Sketch Supply per ship Drawing Remarks Working Spare Item no Torque spanner, 20-120 Nm - 1/2" Torque spanner, 40-200 Nm - 1/2" Torque spanner, 30-320 Nm - 1/2" Hexagon key 7 mm...
Page 379 MAN Diesel & Turbo B 50 Alternator B 50 Alternator Page 1 (1) 2018-04-13 - en...
Page 381 MAN Diesel & Turbo 1699895-2.1 Alternators for GenSets B 50 00 0 Page 1 (2) L27/38S, L21/31S, L16/24S, L16/24, L21/31, L27/38 GenSet Figure 1: GenSet A GenSet is a joined unit with a diesel engine, an In both cases the alternator stator housing is con- alternator and a common base frame.
Page 382 MAN Diesel & Turbo 1699895-2.1 Alternators for GenSets B 50 00 0 Page 2 (2) L27/38S, L21/31S, L16/24S, L16/24, L21/31, L27/38 The air-cooled alternator takes air in through filters; leads the air through the alternator by means of a built-in ventilator and out of the alternator again.
Page 383 MAN Diesel & Turbo 1699865-3.4 Alternator cable installation BG 50 00 0 Page 1 (3) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Description Figure 1: Connection of cables (example) The following can be used as a guideline: The fix point of the alternator cables must be as close as possible to the centre line of the rotor.
Page 384 1699865-3.4 Alternator cable installation BG 50 00 0 Page 2 (3) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Figure 2: Marine operation (example) Binding radius has to be observed, and furthermore binding radius for cables used for resilient installed engines must be observed.
Page 385 MAN Diesel & Turbo 1699865-3.4 Alternator cable installation BG 50 00 0 Page 3 (3) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Figure 3: Stationary operation (example) 2014.04.07...
Page 387 Combinations of engine- and alternator layout BG 50 00 0 Page 1 (2) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H Engine and alternator combinations For a GenSet the engine and alternator are fixed on Comments to possible combinations: a common base frame, which is flexibly installed.
Page 388 MAN Diesel & Turbo 3700084-3.10 Combinations of engine- and alternator layout BG 50 00 0 Page 2 (2) L28/32S, L27/38S, L23/30S, L21/31S, L16/24S, L23/30DF, L28/32DF, V28/32S, L16/24, L21/31, L23/30H, L27/38, L28/32H 2017.04.26...
Page 389 MAN Diesel & Turbo B 98 Preservation B 98 Preservation and packing and packing Page 1 (1) 2018-04-13 - en...
Page 391 5L27/38 3 cyl. 5 cyl. 6L27/38 4 cyl. 6 cyl. 7L27/38 5 cyl. 7 cyl. 8L27/38 5 cyl. 7 cyl. 9L27/38 6 cyl. 8 cyl. Note: Based on MAN Diesel & Turbo standard alter- nator Figure 1: Lifting tools 2015.02.04...

This manual is also suitable for:

L16/24s L23/30s L21/31s L28/32s L28/32s-df L28/32df ... Show all

Man L23/30DF Project Manual

Table of Contents

I 00 Introduction

D 10 General Information

B 10 Basic Diesel Engine

B 11 Fuel Oil System

B 12 Lubricating Oil System

B 13 Cooling Water System

B 14 Compressed Air System

B 15 Combustion Air System

B 16 Exhaust Gas System

B 17 Speed Control System

B 19 Safety and Control System

Table of Contents

1 General Information

2 System Description

3 Interfaces to External Systems

Man Diesel & Turbo

1 Data Bus Interface (Machinery Alarm System)

2 Modbus RTU Protocol

3 Modbus ASCII Protocol

4 Extended Operating Hour Counters Via MODBUS

5 Modbus List

Quick Links

Chapters

Summary of Contents for Man L23/30DF

This manual is also suitable for:

Table of Contents
