System Overview

THE POWERTAP SYSTEM

The PowerTap system includes a power-measuring hub which measures torque and wheel
speed. This information is transmitted to a computer mounted on the handlebar or stem. Heart
rate data is transferred via a coded
then integrated to display current, average, and maximum biometric information.

PREPARING FOR INSTALLATION

The PowerTap hub comes either alone or in a pre-built wheel. If purchased alone, the hub must
be built into a complete wheel prior to use. Other items necessary for installation and not provid-
ed include a cassette, spoke protector, reflectors, skewer, rim, tire, and tube (clincher rim) or glue
and tubular tire (tubular rim). See TABLE 1 to verify package contents.
TABLE 1
Package Contents
Qty Item
1 PowerTap hub (or built wheel)
1 PowerTap computer
1 Chest strap (SLC+, SL+, and Pro+ only)
12 Cable ties
1 Training With Power guide
1 PowerAgent Software
1 USB Cable
1 Handlebar/Stem Computer Shoe
1 Instructional DVD
1 Hub Battery Cover Removal Tool
ADDITIONAL ITEMS FOR MTB DISC ONLY
1 PowerTap Disc Rotor
8 M5 x 12mm bolts
16 M5 x .2mm shims
1 T25 Torx Wrench
telemetry signal from the chest strap monitor. The data is
