Quick Start Guide
GV-VR360 IR Virtual Reality IP Camera
Before attempting to connect or operate this product,
VR360V10-QG-A
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-VR360 and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-VR360

Summary of Contents for GeoVision GV-VR360

  • Page 1 Quick Start Guide GV-VR360 IR Virtual Reality IP Camera Before attempting to connect or operate this product, VR360V10-QG-A please read these instructions carefully and save this manual for future use.
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Table Of Contents

    Contents Note for Connecting to GV-VMS..........ii  Note for Installing Camera Outdoor .......... iii  1. Introduction................1 1.1 Packing List ..................... 1  1.2 Optional Accessories................2  1.3 System Requirements................3  1.4 Software Supported ................. 3  1.5 Overview....................4  2. Installation................5 3.

  • Page 4: Note For Connecting To Gv-Vms

    Note for Connecting to GV-VMS The camera is designed to work with and record on GV-VMS, a video management system. Once the camera is connected to the GV-VMS, the resolution set on the GV-VMS will override the resolution set on the camera’s Web interface. You can only change the resolution settings through the Web interface when the connection to the GV-VMS is interrupted.

  • Page 5: Note For Installing Camera Outdoor

    Note for Installing Camera Outdoor When installing the camera, be sure that: The camera is set up above the junction box to prevent water from entering the camera along the cables. Any PoE, power, audio and I/O cables are waterproofed using waterproof silicon rubber or the like.

  • Page 6: Introduction

    1. Introduction Welcome to the GV-VR360 IR Virtual Reality IP Camera Quick Start Guide. In the following sections, you will learn the basic installations and configurations. For a detailed user manual, see the GV-VR360 IR Virtual Reality IP Camera User’s Manual: http://www.geovision.com.tw/download/product/.

  • Page 7: Optional Accessories

    1.2 Optional Accessories Optional devices can expand your camera’s capabilities and versatility. Contact our sales representatives for more information. Device Description GV-PoE Switch is designed to provide power along with network connection for IP devices. GV-PoE Switch is GV-PoE Switch available in various models with different numbers and types of ports.

  • Page 8: System Requirements

    Introduction 1.3 System Requirements Intel® 6 generation Core Memory 4 GB or above On Board Graphics Intel® HD Graphics 500 series or above Windows 7 Service Pack 1 / Windows 10 or above Web Browser Internet Explorer 10 / 11 or above 1.4 Software Supported GV-VMS V18.1...

  • Page 9: Overview

    1.5 Overview Description Description Built-in microphone Earth ground (M3 terminal) IR LED RJ45 waterproof Fisheye lens DC 12V jack (black) Socket set screw Digital input (white cable) Audio in (pink jack) Digital output (green cable) Audio out (green jack, currently not Ground wire (black cable) functional)

  • Page 10: Installation

    2. Installation The camera is designed for outdoors. With the standard package, you can install the camera on the ceiling. Adjoin the base with the straight tube by turning it clockwise. Thread the cables of the camera to the base end through the opposite end of the straight tube and rotate the straight tube clockwise to attach it to the camera.
  • Page 11 Connect a network cable to the camera. Optionally waterproof the network cable by disassembling the cap of the network connector and thread the network cable as illustrated below. Rotate the camera to adjust for the desired angle and tighten the screws to fixate its position.

  • Page 12: Accessing The Camera

    3. Accessing the Camera 3.1 Looking Up the Dynamic IP Address By default, GV-VR360 is assigned with a dynamic IP address when the camera is connected to a network with DHCP server. This IP address remains unchanged unless you unplug or disconnect your camera from the network.
  • Page 13 The login page appears. Type the default ID and password admin and click Apply.

  • Page 14: Setting Up Youtube Live Streaming

    4. Setting up YouTube Live Streaming GV-VR360 can be streamed online, through YouTube, for a 360° live VR video that can be viewed by the user and/or viewers with granted access. 4.1 Getting YouTube Live Stream After logging in to your YouTube account, click your Account icon and select...
  • Page 15 Under Creator Studio, click LIVE STREAMING, Events and click New live event. Type the information of your live stream as needed.  Name the live stream.  Set the start time of your live stream and Add end time if necessary. ...
  • Page 16 Setting up YouTube Live Streaming Click Save Changes. The Stream Name and Server URL are now available for use.

  • Page 17: Configuring Live Stream Settings

    Only AAC audio codec is supported for YouTube streaming. To modify the audio settings, see 3.1.2 Audio Settings, GV-VR360 User’s Manual. Click Apply to save the settings. For additional settings of GV-VR360, see Chapter 3 Administrator Mode, GV-VR360 User’s Manual.

  • Page 18: Starting Live Stream

    Setting up YouTube Live Streaming 4.3 Starting Live Stream After the required settings are set, go back to the YouTube website and select Live control room. Click Preview and click Start Streaming. The live video stream of GV-VR360 is now viewable on YouTube.

  • Page 19: Smart Device Connection

    5. Smart Device Connection You can access the live video stream of GV-VR360 and view it in VR mode through mobile devices using the mobile application GV-Eye. YouTube mobile app is also supported. Download GV-Eye from Google Play or Apple Store.

  • Page 20: Upgrading System Firmware

    6. Upgrading System Firmware GeoVision periodically updates the latest firmware to the company website. You can update the camera’s firmware through the Web interface or GV-IP Device Utility. 1. Go to System Settings, click Tools Under Management and select Firmware Upgrade.

  • Page 21: Restoring To Factory Default

    7. Restoring to Factory Default If for any reason the camera is not responding correctly, you can reset it to its factory default setting by using its Web interface or pressing the Default button on the camera. 7.1 Using the Web Interface After logging on to the Web interface, go to System Settings.

  • Page 22: Directly On The Camera

    Restoring to Factory Default 7.2 Directly on the Camera Loosen the 3 screws at the rear end of the camera with the supplied torx wrench to reveal the camera cover. Then loosen the 3 screws on the camera cover to access the default button.
