Hardware Installation Guide
GV-Vandal Proof IP Dome
GV-VD1530 / 1540 / 2430 / 2440 / 2530 / 2540
GV-VD2540-E / 3430 / 3440 / 5340 / 5340-E
Thank you for purchasing GV-Vandal Proof IP Dome. For advanced information
2014/11
on how to use the GV-Vandal Proof IP Dome, please refer to GV-IPCam H.264
English
User's Manual and Quick Start Guide online.
VDV3-QG-A
© 2014 GeoVision Inc. All rights reserved.
61-DMVDV3Q-0001

Advertisement

loading
Need help?

Need help?

Do you have a question about the GV-VD1530 and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-VD1530

Summary of Contents for GeoVision GV-VD1530

  • Page 1 Hardware Installation Guide GV-Vandal Proof IP Dome GV-VD1530 / 1540 / 2430 / 2440 / 2530 / 2540 GV-VD2540-E / 3430 / 3440 / 5340 / 5340-E Thank you for purchasing GV-Vandal Proof IP Dome. For advanced information 2014/11 on how to use the GV-Vandal Proof IP Dome, please refer to GV-IPCam H.264 English User's Manual and Quick Start Guide online.
  • Page 2 Important Note for Connecting to GV-System / GV-VMS The GV-IPCAM H.264 is designed to work with GV-System / GV-VMS, a video management system. Note the following when GV-IPCAM H.264 is connected to GV-System / GV-VMS: 1. By default, the images are recorded to the memory card inserted to the GV-IP Camera H.264.
  • Page 3 3. It is recommended to use memory cards of the following setting and specifications: ● Apply a battery backup (UPS) to avoid power outage. ● Use Micro SD card of MLC NAND flash, Class 10 for better performance. Note for Installing Camera Outdoor 1.

  • Page 4: Packing List

    ● TV out wire out wi ● Power Adapter ● Torx Wrench ● Focus Adjustment Cap (for GV-VD1530 / 2430 / 2530 / 3430 only) ● Back Plate ● RJ-45 Connector x 2 ● Screw Anchor x 4 ● Installation sticker ●...
  • Page 5 ● Short Screw x 2 ● Flat Screw ● PG21 Conduit Connector ● Conduit Converter ● Silica Gel Bag ● Sticker (for Silica Gel Bag) ● Ruler Note: 1. Power adapter can be purchased upon request. 2. You can choose to run the wires through a conduit pipe. After you have threaded all the wires, install the supplied conduit converter and plastic PG21 conduit connector with a self-prepared 1/2’’...
  • Page 6 Overview Default Button Video Out LED Indicator Memory Card Slot Audio In Audio Out LAN / PoE DC12V / AC24V IO Terminal Block Rotational Screw Cable Seal Tilt Screw Conduit Connector Silica Gel Bag...

  • Page 7: Installation

    Installation The Vandal Proof IP Dome is designed for outdoors. With the standard package, you can install the camera on the ceiling. Wiring the Camera Rotate to remove the indicated cap and the plug inside. Thread an Ethernet cable (the end with no RJ-45 connector) from the back panel through the cable seal and re-install the cap.
  • Page 8 Thread wires into the camera. A. Unscrew the conduit connector from the back. Conduit Connector B. Unplug the conduit connector inside the housing and disassemble the connector composed of 4 parts. C. Remove the terminal block from the power adapter. D.
  • Page 9 For part 2, there are 8 holes each labeled with its diameter. Remove the plugs and push the wires to the corresponding holes listed below: plug 2.6mm 2.6mm 1.8mm 2.6 mm: Audio, BNC 1.8mm 2.6mm 2 mm: DC12V / AC24V 1.8 mm: DIDO 1.8mm Use the supplied ruler and leave about 10 cm of power and I/O...
  • Page 10 IMPORTANT: 1. Keep the unused holes plugged to waterproof the camera and save the removed plugs. 2. Only thread the wires through their designated holes on the conduit connector to make sure the wires are properly sealed. Tip: 1. To make the threading easier, it is advised to thread the wires in the order described here.
  • Page 11 Sort out the wires at the back. You can have the wires come out from position A, B or both. The instructions here describe sorting wires for position A. From the back of the camera housing, unscrew and rotate the plate to one side, sort out the wires and secure the plate back.
  • Page 12 B. Drill 3 holes for screws. The recommended ones are indicated as ‘1’. C. Insert the screw anchors to the 3 holes. D. Depending on how you want to run the wires (see step 7). Drill the right hole (on the installation sticker) for position A and the left for position B or both if required.
  • Page 13 Adjusting Camera's Angle Access the live view. For details, see Accessing the Camera, Chapter 16, GV-IPCAM H.264 Quick Start Guide online. Adjust the camera’s angle, focus and zoom of the camera. Pan Adjustment Tilt Adjustment Rotational Adjustment Replace the silica gel bag and secure the camera cover using the torx wrench.
  • Page 14 IMPORTANT: 1. The gel bag loses its effectiveness when the dry camera is opened. To prevent the lens from fogging up, replace the silica gel bag every time you open the camera and conceal the silica gel bag within 2 minutes of exposing to open air. 2.

  • Page 15: Connecting The Camera

    Connecting the Camera Connect the camera to power, network and other wires needed. Connecting the Power Cable There are two ways to supply power to the camera: ● Use a Power over Ethernet (PoE) adapter to connect the camera to the network, and the power will be provided at the same time.
  • Page 16 9F, No. 246, Sec. 1, Neihu Rd., Neihu District, Taipei, Taiwan Tel: +886-2-8797-8376 Fax: +886-2-8797-8335 support@geovision.com.tw http://www.geovision.com.tw...
