Appendix A - Technical Specifications
Appendix A
Magnetic stripe: ISO Type B, AAMVA
Encryption: TDEA (3DES)-CBC using DUKPT
PCI PTS v3.x
EMV ICC Specifications for Payment Systems Version 4.3
Dimensions (L x W x H)
Weight (with Bluetooth LE)
Display Type
Display Size (viewable area)
Display Resolution
Keypad
Card Reader
Acceptable Swipe Speeds
Data Connections
Battery Capacity
Battery Capacity, Airplane
Mode
Battery Capacity, Standby
Battery Capacity, Active
Power Input
Maximum current draw
Voltage Requirement
Battery Type
Flash Memory
DynaPro Mini| PIN Encryption Device | Installation and Operation Manual
Technical Specifications
DynaPro Mini Technical Specifications
Reference Standards and Certifications
Physical Characteristics
3.82 in. (97.0 mm) x 2.46 in. (62.5 mm) x 1.05 in. (26.6 mm)
10.9 oz. (309 g)
User Interface Characteristics
Dot Matrix LCD
1.42 in. (36.1 mm) x 0.392 in. (9.95 mm)
128 x 32 pixels
4 lines of up to 21 characters
Rubber dome switches:
10 digits, 3 data entry keys, up/down arrows
3 track encrypting IntelliHead reader with MagnePrint
10 to 50 inches per second
Electrical Characteristics
Bluetooth Low Energy wireless (select models)
Micro-USB, compatible with USB 1.1 and USB 2.0
1000 mAh nominal (rated)
6 months minimum
2 weeks minimum (new device)
200 transactions per day minimum (new device)
USB powered via Micro-USB cable
500 mA
5VDC
Rechargeable Battery: Lithium-ion ("LiPo" / "Li-ion") for main power
Tamper Backup Battery: Lithium coin cell
256 MBit
Page 27 of 28 (D99875642-13)
