DOUBLE DISHDRAWER™ DISHWASHER
DD60DDF models
INSTALLATION GUIDE
NZ AU GB IE SG
591384C
05.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DOUBLE DISHDRAWER DD60DDF Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher & Paykel DOUBLE DISHDRAWER DD60DDF Series

  • Page 1 DOUBLE DISHDRAWER™ DISHWASHER DD60DDF models INSTALLATION GUIDE NZ AU GB IE SG 591384C 05.19...
  • Page 2: Safety And Warnings

    SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS WARNING! Installation of this dishwasher requires basic Electrical shock hazard mechanical and electrical skills. Before installing the dishwasher, remove the Be sure to leave these Instructions with the Customer. house fuse or open the circuit breaker. Installation must comply with your local building and This appliance must be earthed.
  • Page 3: Parts Supplied

    PARTS SUPPLIED Drain hose Drain hose Wire clip (2) Clamp (1) Side mounting support (1) joiner (1) (for securing (for securing bracket kit mounting Drain hose joiner) Drain hose joiner) (A and B) (2) brackets (2) OPTIONAL OPTIONAL Phillips Rubber washer for Moisture protection Hexagonal Prefinished toekick (1)
  • Page 4: Product Dimensions

    PRODUCT DIMENSIONS FRONT PROFILE DD60DDF PRODUCT DIMENSIONS Overall height of product 820-880 Overall width of product Overall depth of product Depth of chassis (to back of front drawer panel) Depth of drawer front panel Height of chassis Height of drawer front panels Height of upper drawer front panel Height of lower drawer front panel Height from top of drawer front panel to top of chassis...
  • Page 5: Cabinetry Dimensions

    CABINETRY DIMENSIONS Bracket slots PLAN PROFILE DD60DDF CABINETRY DIMENSIONS Minimum clearances from adjacent cabinetry Inside height of cavity* min. 820 Inside width of cavity Inside depth of cavity min. 560 Recommended height of adjacent cabinet space Height of toekick space* 100-160 * depending on adjustment of levelling feet min.
  • Page 6: Cavity Preparation

    CAVITY PREPARATION COUNTERTOP Water Connection Recommended COLD (Maximum 60°C). Moisture 10 mm protection tape 3/4“ BSP (GB20) to must be applied. suit flat washer. Water Pressure Water softener models Max. 1 MPa (145 psi) These marks indicate formed Min. 0.1 MPa (14.5 psi) bracket screw locations, if securing by drawer removal.
  • Page 7 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE LEFT HAND SIDE RIGHT HAND SIDE Drain hoses — 2000mm Drain hoses — 1800mm Inlet hose — 1650mm Inlet hose — 1250mm Power cord (excl.plug) — 1650mm Power cord (excl.plug) — 1650mm...
  • Page 8 NOW CHOOSE WHICH INSTALLATION METHOD (A) OR (B) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (A) — SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) ATTACH SIDE MOUNTING BRACKETS PULL THROUGH HOSES & PUSH INTO THE CAVITY Clip all four side mounting brackets Optionally attach the When fitting brackets, into their slots using a flat-bladed...
  • Page 9 SECURE TO THE CABINETRY ON THE SIDES OPTIONALLY SECURE TO THE CABINETRY ABOVE The top mounting brackets will only bend upwards a (x2) Open the drawer maximum of 10 mm. halfway. Using a flat bladed screwdriver, prise Replace the grey the grey rubber rubber plug back into plug out of the...
  • Page 10 ALTERNATIVE METHOD (B) — SECURE BY DRAWER REMOVAL PULL THROUGH HOSES & PUSH INTO THE CAVITY REMOVE THE LOWER DRAWER To prevent kinked hoses optionally attach the Either sit the drawer down on the left hand two top mounting When fitting brackets, side (recommended) or rotate the drawer brackets ensure the ends are...
  • Page 11 SECURE TO THE CABINETRY ON THE SIDES OPTIONALLY SECURE TO THE CABINETRY ABOVE The top mounting brackets will only bend upwards a (x2) maximum of 10 mm. For further adjustment, using the most appropriate length Hexagonal socket supplied, fully extend levelling feet up to required distance by hand.
  • Page 12 FIT THE SUPPLIED TOEKICK PANEL Where the toekick Mounting rail meets the bottom of the tub is the cut-off point Lay the toekick face down on Turn the toekick over and Smooth the edges with a file. a chopping board or similiar score along the same line Be careful of sharp edges.
  • Page 13 THERE ARE TWO DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. DRAINAGE OPTION 1 DRAINAGE OPTION 2 Dishwasher and 38 mm Standpipe Dishwasher using drain hose joiner onto sink trap/waste tee Supplied drain hose joiner to suit Screw Drain hose Screw Drain hose 19 mm waste tee support to back wall...
  • Page 14: Troubleshooting

    CONNECT INLET HOSE TO COLD WATER PLUG PRODUCT IN min. 10mm 3/4” BSP connector No leaks! Ensure the supplied rubber washer is Tighten coupling with spanner. fitted inside the coupling. TROUBLESHOOTING Excessive water remaining above the filter plate, after the rinse cycle. (This is displayed as an A3 fault. See user guide ‘How to attend to a fault’) Check for a kinked drain hose, blocked or incorrectly drilled out waste connection, highloop not properly installed, drain hose not routed correctly or spray arms not in place.
  • Page 15: Final Checklist

    FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Turn on the power and water supplies, then open the drawers. You should hear a Check all parts are installed. beep and see a program indicator light up on the control panel. Ensure that all panels and parts thereof are secure and final electrical tests have Check the spray arms are in place, mounted correctly and free to rotate, by been conducted in accordance with local electrical regulations.
  • Page 16 SINGLE DISHDRAWER™ DISHWASHER DD60SDF models INSTALLATION GUIDE NZ AU GB IE SG 591384C 05.19...
  • Page 17 SAFETY AND WARNINGS IMPORTANT SAFETY INSTRUCTIONS WARNING! Electrical shock hazard Installation of this dishwasher requires basic Before installing the dishwasher, remove the mechanical and electrical skills. house fuse or open the circuit breaker. Be sure to leave these Instructions with the Customer. This appliance must be earthed.
  • Page 18 PARTS SUPPLIED Drain hose Drain hose Wire clip (1) Clamp (1) Side mounting support (1) joiner (1) (for securing (for securing bracket kit mounting Drain hose joiner) Drain hose joiner) (A and B) (2) brackets (2) OPTIONAL OPTIONAL Phillips 38 mm Rubber washer Moisture protection Cavity Bracket Kit (1)
  • Page 19 PRODUCT DIMENSIONS FRONT PROFILE STANDARD TALL HEIGHT HEIGHT DD60SDF DD60SDFT PRODUCT DIMENSIONS Overall height of product Overall width of product Overall depth of product Depth of chassis (to back of front drawer panel) Depth of drawer front panel Height of drawer front panel Height of chassis Height from top of drawer front panel to top of chassis Ventilation gap below drawer front panel...
  • Page 20 CABINETRY DIMENSIONS Bracket slots PLAN STANDARD TALL PROFILE HEIGHT HEIGHT DD60SDF DD60SDFT CABINETRY DIMENSIONS Inside height of cavity min. 412 Inside width of cavity Minimum clearances from adjacent cabinetry Inside depth of cavity min. 560 min. 560 Cavity height options allow you to match dishwasher with your cabinetry or companion products DD60SDF DD60SDFT (Standard height models)
  • Page 21 CAVITY PREPARATION COUNTERTOP Moisture 10 mm protection tape must be applied. Water Connection Recommended COLD (Maximum 60°C). These marks indicate formed bracket screw locations, if 3/4“ BSP (GB20) to securing by drawer removal. suit flat washer. If there is no side partition, you Ø...
  • Page 22 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE LEFT HAND SIDE RIGHT HAND SIDE Drain hoses — 1800mm Drain hose — 2000mm Inlet hose — 1250 mm Inlet hose — 1650mm Power cord (excl.plug) — 2000mm Power cord (excl.plug) — 2000mm TALL HEIGHT DESIGNER MODELS FOR 480 MM CAVITY ONLY —...
  • Page 23 NOW CHOOSE WHICH INSTALLATION METHOD (A) OR (B) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (A) — SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) ATTACH SIDE MOUNTING BRACKETS PULL THROUGH HOSES & PUSH INTO THE CAVITY Clip all four side mounting brackets into their slots using a flat-bladed screwdriver.
  • Page 24 SECURE TO THE CABINETRY ON THE SIDES Open the drawer halfway. Using a flat bladed screwdriver, prise the grey rubber plug out of the trim moulding. Replace the grey rubber plug back Using a small Philips screwdriver, screw into the trim moulding and ensure through the trim moulding, securing the the trim seal is facing forward.
  • Page 25 ALTERNATIVE METHOD (B) — SECURE BY DRAWER REMOVAL PULL THROUGH HOSES & PUSH INTO THE CAVITY REMOVE THE LOWER DRAWER To prevent kinked hoses Either sit the drawer down on the left hand side (recommended) or rotate the drawer clockwise, resting it on its side after removal.
  • Page 26 SECURE TO THE CABINETRY ON THE SIDES The product has three pairs of fixing points: Ensure the sound insulation is repositioned correctly. a pair of fixing two pairs of formed holes either side brackets on either side on the bottom of the chassis (use 38 mm fixing (use 16 mm screws)
  • Page 27 THERE ARE TWO DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. DRAINAGE OPTION 2 DRAINAGE OPTION 1 Dishwasher and Ø 38 mm Standpipe Dishwasher using drain hose joiner onto sink trap/waste tee Supplied drain Screw Drain hose hose joiner to suit Screw Drain hose support to back wall 19 mm waste tee...
  • Page 28 CONNECT INLET HOSE TO COLD WATER PLUG PRODUCT IN min. 10mm 3/4” BSP connector No leaks! Ensure the supplied rubber washer is fitted inside the coupling. Tighten coupling with spanner.
  • Page 29 TROUBLESHOOTING Excessive water remaining above the filter plate, after the rinse cycle. (This is displayed as an A3 fault. See user guide ‘How to attend to a fault’) Check for a kinked drain hose, blocked or incorrectly drilled out waste connection, highloop not properly installed, drain hose not routed correctly or spray arm not in place. No water supply.
  • Page 30 FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER Turn on the power and water supplies, then open the drawer. You should hear a Check all parts are installed. beep and see a program indicator light up on the control panel. Ensure that all panels and parts thereof are secure and final electrical tests have Check the spray arms are in place, mounted correctly and free to rotate, by been conducted in accordance with local electrical regulations.
