- Page 1 INSTALLATION INSTRUCTIONS DishDrawer dishwasher DD60D 7 models NZ AU GB IE 590200D 04.13...
- Page 2 FOLLOW THE INSTALLATION SEQUENCE RELEVANT TO YOUR MODEL ONLY AVAILABLE IN NZ AU ONLY AVAILABLE IN GB IE Designer Classic Integrated with remote control Integrated with badge controls DD60DC(H)X7 DD60DC(H)W7 DD60DDF(H)X7 DD60DI7 DD60DHI7 DD60DC(H)B7 DD60DDFM7 DD60DCM7 PARTS SUPPLIED PARTS SUPPLIED PARTS SUPPLIED PARTS SUPPLIED PRODUCT &...
-
Page 3: Important Safety Instructions
SAFETY AND WARNINGS - ALL MODELS IMPORTANT SAFETY INSTRUCTIONS! WARNING! Installation of this dishwasher requires basic mechanical and electrical skills. Electrical shock hazard Be sure to leave these Instructions with the Customer. Before installing the dishwasher, remove the house fuse or open the circuit Installation must comply with your local building and electricity regulations. - Page 4 PARTS SUPPLIED - ALL MODELS Drain hose Drain hose Wire clip (2) Clamp (1) Side mounting support (1) joiner (1) bracket kit mounting (for securing (for securing (A and B) (2) brackets (2) Drain hose joiner) Drain hose joiner) OPTIONAL OPTIONAL Phillips Rubber...
- Page 5 ADDITIONAL PARTS SUPPLIED WITH INTEGRATED MODELS Integrated rectangular Panel bracket (2) Panel mounting Toekick mounting bracket (1) Toekick badge (2) (attached to product) screws (12) mounting (Satin chrome supplied) (A custom toekick panel of any screws (5) material with thickness supplied with Integrated 9 - 19 mm can be screwed to the plastic toekick mounting bracket)
-
Page 6: Product Dimensions
PRODUCT DIMENSIONS Plan Side Product dimensions (mm) overall height of product 820-880 820-880 820-880 820-880 overall width of product overall depth of product (excl. handle) depth of chassis (to back of front panel) maximum extension of drawer (excl. handle) depth of front panel 16 -20 16 -20 (excl. -
Page 7: Cabinetry Dimensions
CABINETRY DIMENSIONS Plan Side Cabinetry dimensions (mm) Minimum clearances from adjacent cabinetry min. 13 mm clearance min. 2 mm from a corner clearance cupboard to adjacent inside height of cavity* min. 820 min. 820 min. 820 min. 820 cupboard door inside width of cavity inside depth of cavity min. - Page 8 INTEGRATED MODELS ONLY - CUSTOM PANEL CALCULATIONS FRONT PANEL SPECIFICATIONS The following calculations assume the top of the upper panel is aligned with the top of the adjacent cabinetry. The fi nal 16 -20 mm panel thickness panel/cabinetry alignment is achieved by adjusting the feet: min.
-
Page 9: Cavity Preparation
CAVITY PREPARATION Important! BENCHTOP The power outlet must be located in a cabinet adjacent to the dishwasher cavity. Moisture 220-240 VAC min. 9.5 A 10 mm protection tape must be applied. Water Connection Recommended COLD (Maximum 60°C). ¾ “ BSP (GB20) to suit flat washer. - Page 10 MAXIMUM DISTANCE OF HOSES & CORD FROM CHASSIS EDGE Right hand side Left hand side Drain hoses - 2000 mm Drain hoses - 1800 mm Inlet hose - 1250 mm Inlet hose - 1650 mm Power cord - 1650 mm Power cord - 1650 mm (excl.
- Page 11 NOW CHOOSE WHICH INSTALLATION METHOD (a) or (b) IS MORE SUITABLE FOR YOUR CABINETRY... RECOMMENDED METHOD (a) - SECURE WITHOUT DRAWER REMOVAL (FRAMELESS CABINETRY ONLY) PULL THROUGH HOSES & PUSH INTO THE CAVITY ATTACH SIDE MOUNTING BRACKETS optionally attach the Clip all four side mounting brackets into two top mounting brackets their slots using a flat-bladed screwdriver.
- Page 12 SECURE TO THE CABINETRY ON THE SIDES OPTIONALLY SECURE TO THE CABINETRY ABOVE The top mounting brackets will only (x2) Open the bend upwards a drawer halfway. maximum of 10 mm. Using a flat-bladed screwdriver, prise the grey Replace the grey rubber plug out rubber plug back into of the trim moulding.
- Page 13 ALTERNATIVE METHOD (b) - SECURE BY DRAWER REMOVAL PULL THROUGH HOSES & PUSH INTO THE CAVITY REMOVE THE LOWER DRAWER To prevent kinked hoses, we recommend rotating the drawer anti-clockwise and resting it on its side after removal. optionally attach the two top mounting brackets (x2) You can initially level the product...
- Page 14 SECURE TO THE CABINETRY ON THE SIDES OPTIONALLY SECURE TO THE CABINETRY ABOVE To access the side brackets, The top mounting you might have to push aside brackets will only (x2) the insulation. After securing, bend upwards a ensure the sound insulation is maximum of 10 mm.
- Page 15 FIT THE SUPPLIED TOEKICK PANEL (OPTIONAL FOR INTEGRATED MODELS) Where the toekick meets the bottom of the tub is the Mounting rail cut-off point Lay the toekick face down on Turn the toekick over and Smooth the edge with a file. a chopping board or similiar score along the same line Be careful of sharp edges.
- Page 16 INTEGRATED MODELS WITH REMOTE (NZ AU) ONLY - INSTALLING THE FRONT PANELS ATTACH PANELS TO PANEL BRACKETS REMOVE BRACKETS FROM PRODUCT WARNING! Electrical Shock Hazard There must be at least 16 mm x6 3 screws used each side Before continuing, ensure that the product is disconnected from the power supply.
- Page 17 INTEGRATED MODELS WITH REMOTE (NZ AU) ONLY - INSTALLING THE FRONT PANELS ADJUST PANEL HEIGHT TO ALIGN THE CABINETRY GAPS FITTING A CUSTOM TOEKICK PANEL 16 mm x5 + or - 2 mm With the front panels fitted, insert an appropriately sized Philips screwdriver into the hole above the door pin and rotate the panels up or down to align the gaps You can optionally glue your...
- Page 18 INTEGRATED MODELS WITH BADGE (GB IE) ONLY - INSTALLING THE FRONT PANELS & BADGE CONTROLS DETERMINE BADGE CUTOUT LOCATIONS REMOVE BRACKETS & DISCONNECT BADGES WARNING! Electrical Shock Hazard Before continuing, ensure that the product is disconnected from the power supply. Failure to follow this warning may result in electrical shock, injury or fire.
- Page 19 INTEGRATED MODELS WITH BADGE (GB IE) ONLY - INSTALLING THE FRONT PANELS & BADGE CONTROLS REATTACH BADGES & EARTH THE PANELS ATTACH PANELS TO PRODUCT Important! WARNING! Ensure the rubber seal Electrical Shock Hazard between the drawer Connect the integrated badge and panels is kept in earth wire to one of the two tabs provided on the panel bracket.
- Page 20 THERE ARE TWO DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. Dishwasher and Standpipe Ø 38 mm Dishwasher using sink trap with drain hose joiner Supplied drain hose joiner If space is limited 19 mm for fixing, push If space is limited waste tee hose through drain...
-
Page 21: Final Checklist
FINAL CHECKLIST TROUBLESHOOTING Check all parts are installed. Excessive water remaining above the filter plate, after the rinse cycle Ensure that all panels and parts thereof are secure and final electrical tests have Check for a kinked drain hose, blocked waste connection, highloop not properly installed, drain hose not routed correctly or spray arms not in place.
