Bartscher MultiTherm Instruction Manual

Mulled wine pot
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
„MultiTherm"
A200050
Bedienungsanleitung
Glühweintopf
D/A/CH
Seite 1 bis 14
Instruction manual
Mulled wine pot
GB/UK
from page 15 to 28
Mode d'emploi
Marmite à vin chaud
F/B/CH
de page 29 à page 42
Gebruiksaanwijzing
Glühwein ketel
NL/B
blz. 43 t/m 56
Instrukcja obsługi
Warnik do grzanego wina
PL
strony od 57 do 70
V6/0814

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MultiTherm and is the answer not in the manual?

Questions and answers

Related Manuals for Bartscher MultiTherm

Summary of Contents for Bartscher MultiTherm

  • Page 1 „MultiTherm“ A200050 Bedienungsanleitung Glühweintopf D/A/CH Seite 1 bis 14 Instruction manual Mulled wine pot GB/UK from page 15 to 28 Mode d’emploi Marmite à vin chaud F/B/CH de page 29 à page 42 Gebruiksaanwijzing Glühwein ketel NL/B blz. 43 t/m 56 Instrukcja obsługi...

  • Page 2: Table Of Contents

    6. Cleaning and maintenance ..................26 6.1 Safety advice ....................... 26 6.2 Cleaning ......................26 6.3 Safety instructions for maintenance ..............27 7. Possible Malfunctions .................... 27 8. Waste disposal ......................28 Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax:...

  • Page 3: General Information

    1. General information 1.1 Information about the instruction manual This instruction manual contains information about the installation, operation and maintenance of the device and should be consulted as an important source of information and reference guide. Awareness of the safety instructions and instructions for use in this manual will ensure the safe and correct use of the device.

  • Page 4: Liability And Warrantees

    1.3 Liability and Warrantees All the information and instructions in this manual take into account standard safety regulations, current levels of technical engineering as well as the expertise and experience we have developed over the years. The instruction manual was translated with all due care and attention. However, we do not accept liability for any translation errors.

  • Page 5: Safety

    2.Safety This section provides an overview of all important safety aspects. In addition every chapter provides precise safety advice for the prevention of dangers which are highlighted by the use of the above mentioned symbols. Furthermore, attention should be paid to all pictograms, markers and labels on the device, which must be kept in a permanent state of legibility.

  • Page 6: Intended Use

    Bed & Breakfasts. Mulled wine pot „MultiTherm“ is meant only for heating up and keeping the heat of liquids suitable for drinking, such as e.g. heated wine, tea and for preparing hot water.

  • Page 7: Transport, Packaging And Storage

    3. Transport, packaging and storage 3.1 Delivery check Please check the delivery upon completeness and transport damage immediately after receipt. In case of visible damage do not accept or accept the delivery with reservation only. Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint. Hidden damages should be reclaimed immediately after notice, as claims for damages can only be asserted within the effective period for complaints.

  • Page 8: Technical Data

    4. Technical data 4.1 Overview of parts ② ① ③ ④ ⑩ ⑤ ⑨ ⑥ ⑧ ⑦ ① ② Handle of lid ③ Container handle ④ Container ⑤ Temperature control ⑥ Green keeping warm control lamp ⑦ Orange heating up control lamp ⑧...

  • Page 9: Technical Specification

    4.2 Technical specification Mulled wine pot „MultiTherm“ Description: A200050 Code-No.: Material: Body and lid: stainless steel Connection: 2000 W / 220-240 V 50/60 Hz ° ° Temperature control: stepless, 30 C - 90 Capacity: 20 litres Dimensions: Ø 270 mm, height 610 mm Weight: 4.8 kg...

  • Page 10: Installation And Operation

    5. Installation and operation 5.1 Safety instructions • Never allow the power cable to come into contact with heat sources or sharp edges. The power cable should not hang over the side of the working surface. Ensure that no one can step on or trip over the cable. •...

  • Page 11: Operation

    WARNING! Hazard via electrical current! The device can cause injuries due to improper installation! Before installation the local power grid specification should be compared with that of the device (see type label). Connect the device only in case of compliance! The device must only be connected to a properly installed single socket with protective contact.
  • Page 12 NOTE! The heat is created via a heating coil in the bottom part of the mulled wine pot. The electric temperature control with the temperature sensor are placed here as well. The adjustment of temperature is done via the thermostat switch. •...

  • Page 13: Cleaning And Maintenance

    6. Cleaning and maintenance 6.1 Safety advice o Before beginning with repair or cleaning works make sure the device has been disconnected from power supply and has cooled down. o Do not use any acid agents and make sure no water ingresses the device. o To protect yourself from electric shock, never immerse the device, its cables and the plug in water or other liquids.

  • Page 14: Safety Instructions For Maintenance

    o After removing lime rinse the container with clean water. o After cleaning you should apply a soft, dry cloth in order to wipe dry and polish the surface. CAUTION! Complaints will not be accepted if the device is not decalcified regularly as described in the instruction manual.

  • Page 15: Waste Disposal

    NOTE! For the disposal of the device please consider and act according to the national and local rules and regulations. Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax:...
