56F8300
Demonstration Board
User Manual
56F800
16-bit Digital Signal Controllers
MC56F8300DBUM
Rev. 4
08/2005
freescale.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 56F8300 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NXP Semiconductors 56F8300 Series

  • Page 1 56F8300 Demonstration Board User Manual 56F800 16-bit Digital Signal Controllers MC56F8300DBUM Rev. 4 08/2005 freescale.com...
  • Page 3: Table Of Contents

    Table of Contents Preface ix Audience ............ix Organization .
  • Page 4 Table of Contents USER FEATURES ..........2-5 2.3.1 Microphone .
  • Page 5 LIST OF TABLES CUT_AWAY Options ........2-2 Connections .
  • Page 6 56F8300 Demonstration Board User Manual, Rev. 4 Freescale Semiconductor Preliminary...
  • Page 7 LIST OF FIGURES 56F8300 Demonstration Board ....... . . 1-2 Power Port .
  • Page 8 56F8300 Demonstration Board User Manual, Rev. 4 viii Freescale Semiconductor Preliminary...
  • Page 9: Audience

    Preface This reference manual describes in detail the hardware on the 56F8300 Demonstration Board. Audience This document is intended for application developers who are creating software for devices using the 56F8300 Demonstration Board. Organization This manual is organized into two chapters and one appendix. •...
  • Page 10: Notation Conventions

    Notation Conventions This manual uses the following notational conventions: Typeface, Symbol or Typeface, Symbol Meaning Examples Term or Term Code examples Courier //Process command for Courier Monospaced Type line flash Monospaced Type Italic Directory names, ...and contains these core Italic project names, directories: calls,...
  • Page 11: Cautionary Notes

    Cautionary Notes 1. Electrostatic Discharge (ESD) prevention measures should be applied whenever handling this product. ESD damage is not a warranty repair item. 2. Axiom Manufacturing reserves the right to make changes without further notice to any products to improve reliability, function or design. Axiom Manufacturing does not assume any liability arising out of the application or use of any product or circuit described herein;...
  • Page 12: Definitions, Acronyms, And Abbreviations

    Definitions, Acronyms, and Abbreviations Definitions, acronyms and abbreviations for terms used in this document are defined below for reference. Analog-to-Digital Converter Controller Area Network Clear To Send Electrostatic Discharge GPIO General Purpose Input and Output Port JTAG Joint Test Action Group. A bus protocol/interface used for test and debug.
  • Page 13: 56F8300 Demonstration Board Features

    Chapter 1 Introduction The 56F8300 Demonstration Board is used to demonstrate the abilities of the 56F8300 series of devices and to provide a hardware tool allowing the development of applications that use the 56F8300 devices. Applications developed for this demonstration board were not designed for the 56F8100 devices.
  • Page 14: Specifications

    The 56F8300 Demonstration Board is detailed in Figure 1-1. Figure 1-1. 56F8300 Demonstration Board 1.2 SPECIFICATIONS • +9V DC input voltage typical, 300ma • Input voltage range: +7 to +15V DC • On-board regulated +5V DC and +3.3V DC supplies •...
  • Page 15: Options

    Chapter 2 Technical Summary This chapter describes the 56F8300 Demonstration Board’s available options. 2.1 OPTIONS 2.1.1 HOST_ENABLE The HOST_ENABLE option jumper enables the Host JTAG interface on the board. With the option jumper installed, the 56F8323 device will reset into Debug mode and await Host commands on the Host JTAG port (P1).
  • Page 16: Ports And Connectors

    Table 2-1. CUT_AWAY Options CUT_AWAY # Description 56F801 Signal Connection Signal ADC reference supply 56F800E On-chip Regulator OCR_DIS Ground (enabled) control connection Temperature Sensor TEMP_SENSE / 56F800E TEMP SENSE output to connection ANA7 ANA7 input Microphone to ADC ANA0 U7 pin 4 (Microphone output) SCI1 serial port SS0 / TXD1 U8 pin 11 (SCI1 TXD)
  • Page 17: Adc Port

    PORTS AND CONNECTORS +9V DC +5V DC +3.3V DC Figure 2-1. Power Port 2.2.3 ADC PORT ANA6 ANA7 Analog inputs. ANA0 provides MIC input. ANA4 provides E-Sensor input. ANA7 ANA4 ANA5 provides TEMP_SENSE input. ANA2 ANA3 ANA0 ANA1 2.2.4 GPIO / SERIAL IRQA MISO01 / RXD1 / PB1 Note: Most signals on this port have...
  • Page 18: Sci1

    2.2.6 SCI1 The SCI1 port has a femaleDB9 connector that interfaces to the 56F8323 internal SCI1 serial port via TXD0 the U8 RS-232 transceiver. It uses a simple 2-wire RXD0 asynchronous serial interface and is translated to 4ANA0 RS-232 signaling levels. 1, 4, 6 connected (host null) RTS and CTS flow control connection pads are provided on the 56F8300 Demonstration Board to apply unassigned 56F800E I/O to support flow control on the SCI1 port.
  • Page 19: P1 - Host Jtag

    USER FEATURES JTAG / EOnCE BDM connection. (key) RESET in +3.3V DC TRST in Note: This connector is only active if the HOST_ENABLE jumper is open or idle. 2.2.9 P1 - HOST JTAG The P1 - Host JTAG connector provides development port interface to a hosting Personal Computer’s LPT or Printer port.
  • Page 20: Audio Output, Headset / Speaker

    2.3.2 Audio Output, Headset / Speaker Timer output channels TC0 and TC1 provide input to 4th order 4KHz low-pass filters with audio amplifier output to the headset jack or speaker. Channel TC1 is the speaker input channel. Amplifier gain is fixed by resistors R48 and R54 for channels TC0 and TC1, respectively. When using a headset, be careful to keep volume low.
  • Page 21: Indicators

    Indicators 2.4 Indicators The active user indicators provided have a high level on the associated 56F800E device’s I/O port. Table 2-3 details the indicators. Table 2-3. Indicators Indicator 56F800E Signal Color PWMA1 / PA1 Green SS0 / PB0 Green PWMA2 / PA2 Green MISO0 / PB1 Green...
  • Page 22 56F8300 Demonstration Board User Manual, Rev. 4 Freescale Semiconductor Preliminary...
  • Page 23: Appendix A 56F8300 Demonstration Board Schematics

    Appendix A 56F8300 Demonstration Board Schematics 56F8300 Demonstration Board Schematics, Rev. 4 Freescale Semiconductor Preliminary...
  • Page 24 DSP56F801EVM Hardware User’s Manual, Rev. 4 Freescale Semiconductor Preliminary...
  • Page 25 56F8300 Demonstration Board Schematics, Rev. 4 Freescale Semiconductor Preliminary...
  • Page 26 POWER LAMP_MON LAMP_SNS LAMPCTRL POWER PORT ISO_OUT ISO_IN ISO-9141 LAMP_OUT D_SHIELD MC33794 SIGNAL PWR_ON SP3232 VDDMON MICRO PHONE SHIELD SCI1 FOR E-FIELD SENSOR VDDA DEMONSTRATION APPROACH WITH YOUR HAND HERE RESET IRQA (NOTE: WAIT 10 SECONDS AFTER POWER APPLIED FOR CALIBRATION) 74LCX125 MC56F8323 HOST...
  • Page 27 INDEX Numerics 56F8300 Peripheral User Manual General Purpose Input/Output Port GPIO GPIO GPIO / Serial Port Analog-to-Digital Converter Audio Output connection Host JTAG Port Host JTAG port (P1) HOST_ENABLE CAN Port CAN port input connection Joint Test Action Group JTAG Clear To Send JTAG JTAG / EOnCE...
  • Page 28 Request To Send RS-232 SCI1 serial port Serial Communications Interface Stereo Audio Output Technical Data / Product Preview, Electric Field Imaging Device, 33794 Technical Data 56F8323 16-bit Hybrid Controller Temperature Sensor connection termination resistor (RC1) TIMER / PWM Port 56F8300 Demonstration Board User Manual, Rev. 4 Index-2 Freescale Semiconductor Preliminary...
  • Page 32 How to Reach Us: Home Page: www.freescale.com E-mail: support@freescale.com USA/Europe or Locations Not Listed: Freescale Semiconductor Technical Information Center, CH370 1300 N. Alma School Road Chandler, Arizona 85224 +1-800-521-6274 or +1-480-768-2130 support@freescale.com Europe, Middle East, and Africa: Freescale Halbleiter Deutschland GmbH Technical Information Center Schatzbogen 7 81829 Muenchen, Germany...
