UM10936
PN7150 User Manual
Rev. 1.1 — 24 May 2016
348111
Document information
Info
Content
PN7150, NFC, NFCC, NCI 1.0
Keywords
This is a user manual for the PN7150 NFC Controller.
Abstract
The aim of this document is to describe the PN7150 interfaces, modes of
operation and possible configurations.
User manual
COMPANY PUBLIC
