Freescale Semiconductor
Design Guide
Hardware Design Guide
MPC560xP devices
1 Introduction
The MPC560xP microcontrollers are members of the 32-bit
Qorivva microcontroller family built on the Power
Architecture® technology. The devices are targeted at the
chassis and safety market segment, especially the Electrical
Hydraulic Power Steering, low end Electrical Power Steering
and Airbag applications.
The purpose of this document is to describe hardware design
considerations when developing hardware for the MPC560xP
family of microcontrollers: 5604P, 5603P, 5602P, 5601P. It
will cover topics such as clock generation, decoupling,
Voltage regulator and power considerations. Detailed
reference design schematics and descriptions of the main
components are also contained within this document. Some
general hardware recommendations are also provided.
2 Power Supply
The MPC5604P has a single main/input voltage supply which
can be either 5 V or 3.3 V with a specified tolerance of ±10%
this is converted using the internal VREG to 1.2V ±10% for
the core logic. The user is not permitted to supply the core
logic via an external 1.2 V supply, they must always use the
on-chip voltage regulator (VREG).
© 2012 Freescale Semiconductor, Inc.
Document Number: MPC560xPQRUG
Contents
1
Introduction................................................................1
2
Power Supply............................................................1
3
Clock Circuity...........................................................7
4
5
connector pin out definitions..................................11
6
connector.................................................................12
7
Minimum external circuitry....................................14
8
connections..............................................................15
9
Pin Overview...........................................................21
Rev. 0, 2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the MPC560xP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for NXP Semiconductors MPC560xP

  • Page 1: Table Of Contents

    MPC560xP devices Contents 1 Introduction Introduction..............1 Power Supply............1 The MPC560xP microcontrollers are members of the 32-bit Qorivva microcontroller family built on the Power Clock Circuity............7 Architecture® technology. The devices are targeted at the Analogue to Digital Convertor (ADC)......9 chassis and safety market segment, especially the Electrical...
  • Page 2: Power Supply

    2.1 Voltage Regulator The voltage regulator on the MPC560xP converts the main input supply 3.3 V or 5.0 V ±10% to 1.2 V core logic level. The internal voltage regulator requires an external capacitance to be connected to the device in order to provide a stable 1.2 V low voltage digital supply to the device.
  • Page 3 Power Supply Table 2. Recommended Ballast Transistors Part Manufacturer Recommended derivative BCP68 ON semi BCP68 Infineon BCP68-10 BCP68-10; BCP68-25 Fairchild BCP68-10; BCP68-25 BCX68 Infineon BCX68-10;BCX68-16; BCX68-25 Fairchild BCX68 BC817 Infineon BC817-16; BC817-25; BC817SU BC817-16; BC817-25 Fairchild BC817-16;BC817-25; BC817-40 BCP56 ON semi BCP56-10 Infineon BCP56-10;...
  • Page 4 Power Supply VDD_HV_REG MPC5604P DEC3 BCP56, BCP68, BCTRL BCX68, BC817 VDD_LV_COR DEC2 DEC1 Figure 1. Configuration without base resistor BCTRL - (Voltage Regulator external NPN Ballast base control pin) controls the current on the base of the transistor. The current is increased to raise the voltage on the VDD and decreases to lower the voltage. The gain of the transistor controls the maximum current available on the supply pin.
  • Page 5 Power Supply External 4 capacitances DEC2 decoupling/ of 100 nF each stability ceramic capacitor External µF DEC3 decoupling/ stability ceramic capacitor on DD_HV_REG 2.3 Capacitors The ballast transistor requires capacitors to be added for decoupling and stability. The number of capacitors is not important —...
  • Page 6 Power Supply VDD_HV_REG MPC5604P DEC3 BCP68, BCX68, BCTRL BC817SU VDD_LV_COR DEC2 DEC1 Figure 2. Configuration with base resistor Note: For 5601P and 5602P the 20k base resistor has been integrated into the MCU and additional component is not required. Symbol Parameter Conditions Unit...
  • Page 7: Clock Circuity

    Clock Circuity Symbol Parameter Conditions Unit External Four 1200 1760 ˉ DEC2 decoupling/ capacitances of stability ceramic 440 nF each capacitor External 2 x 10µF ˉ ˉ µF DEC3 decoupling/ capacitances of stability ceramic 10 μF each capacitor on DD_HV_REG 3 Clock Circuity The MPC5604P has 4 clock sources.
  • Page 8 Clock Circuity Figure 3. External crystal circuit The load capacitors are dependent on the specifications of the crystal and on the board capacitance. It is recommended to have the crystal manufacturer evaluate the crystal on the evaluation board / PCB. 3.1 Frequency Modulated PLL (FMPLL) The FMPLL allows the user to generate high speed system clocks from a 4MHz to 40MHz input clock.
  • Page 9: Analogue To Digital Convertor (Adc)

    3.90 25.3 10.0 3.00 40.0 NX5032GA 6.18 2.56 3.49 the CERALOCK resonators listed below have also been approved for use on all MPC560xP devices based on the e200z0 core. Table 6. Approved resonators Part vibratio Fr[kHz[ Fa[kHz] Fa- Ra[ohm R1[ohm...
  • Page 10 The filter at the input pins must be designed taking into account the dynamic characteristics of the input signal (bandwidth) and the equivalent input impedance of the ADC itself. For more information read MPC560xP datasheet. Figure 5. Input equivalent circuit Hardware Design Guide, Rev.
  • Page 11: Recommended Debug Connectors And Connector Pin Out Definitions

    Recommended debug connectors and connector pin out definitions 5 Recommended debug connectors and connector pin out definitions The table below shows the recommended connectors for different applications for the MPC560xP. Table 8. Recommended connectors Connector style Target system part number...
  • Page 12: Mpc56Xx High-Speed Parallel Trace Connector

    MPC56xx high-speed parallel trace connector NOTE Freescale recommends that a full Nexus connector be used for all tool debug connections, regardless of whether Nexus trace information is needed. Adapters for a JTAG class 1 14-pin connector (tool side) to the full Nexus MICTOR connectors (board side) are available from P&E Microcomputer Systems (http://www.pemicro.com ), part number...
  • Page 13 MPC56xx high-speed parallel trace connector Table 11 shows the recommended pinout for the Samtec connector. Table 11. MPC56xx high-speed parallel trace connector Position Signal Signal IEEE-5001-2011 GEN_IO Direction Direction number number signal name MSEO0 VREF MSEO1 MDO0 MDO1 JCOMP MDO2 MDO3 EVTI EVTO...
  • Page 14: Minimum External Circuitry

    Minimum external circuitry 7 Minimum external circuitry In general, other than the connector, no additional circuitry is required for the Nexus/JTAG debug circuitry. The MPC5600 devices include internal pull devices that ensure the pins remain in a safe state; however, if there is additional circuitry connected to the Nexus/JTAG pins, or long traces that could be affected by other signals (due to crosstalk from high-current or high-speed signals), a minimum number of external pull resistors can be added to insure proper operation under all conditions.
  • Page 15: Example Communication Peripheral Connections

    Example communication peripheral connections 8 Example communication peripheral connections There are a wide range of peripheral pins available on the MCU. Many of these have fairly standard definitions for their use. This section provides example connections for some of the most commonly used communications peripherals, such as LIN, CAN, Ethernet, and RS-232 communication interfaces.
  • Page 16 Example communication peripheral connections Figure 8 shows the typical connections between the serial port of an MCU and the MAX3232-EP RS-232D transceiver from Texas Instruments (http://www.ti.com/ ). The transceiver operates from either a 3.3-V or a 5-V supply and includes two charge pumps to generate the required output voltages.
  • Page 17 Example communication peripheral connections 8.2 CAN interface circuitry Controller Area Network (CAN) is commonly used in almost all automotive applications to allow communication between various microchips in the car. The number of CAN modules on-chip vary from device to device. A separate CAN transceiver is required for each CAN module, although some CAN transceivers may have more than one on a single chip.
  • Page 18 Example communication peripheral connections NOTE Decoupling shown as an example only. TXD/RXD pullup/pulldown may be required, depending on device implementation. Table 16. TJA1050 pin definitions and example system connections Pin name Full pin MCU or system Description number direction name connection Input Transmit...
  • Page 19 Example communication peripheral connections Vbatt 10 uF 10 uF 4700 pF 4700 pF CANH CANH WAKE 511 Ω 120 Ω MCU_CAN_TXD MCU_CAN_RXD CANL MCU_GPIO CANL MCU_GPIO 511 Ω MCU_GPIO TJA1054 10K Ω 10K Ω Isolation and protection circuitry is not shown in this drawing,only a termination resistor is shown.
  • Page 20 Example communication peripheral connections Table 17. TJA1054 pin definitions and example system connections (continued) Pin name Full pin MCU or system Description number direction name connection Input Enable MCU GPIO Enable input for the device. It is also used in conjunction with the STB pin to determine the mode of the transceiver.
  • Page 21: Pin Overview

    Pin Overview Male Female Figure 11. DB9 Connector Types Table 18. DB9 connector mapping Pin number Signal name CAN_L CAN_SHIELD (OPTIONAL) CAN_H CAN_V+ (OPTIONAL) NOTE The metal shell of the connector should be connected through a ferrite bead to the chassis ground.
  • Page 22 Pin Overview NOTE This document uses the terms pins, balls, and pads interchangeably when referencing the external signals of the device. Table 19. Pad Types Pad type Abbreviation Description Slow Speed pads Slow Most of the peripheral signals are slow (or medium if available depending on the device definition) speed pads.
  • Page 23 Pin Overview Table 20. Slew Rate settings (continued) Pad type Load drive (pF) Frequency of Operation Slope at rising/falling edge (MHz) (max) (ns) (min/max) Fast Speed Pad 1.5/7 3/12 5/18 9.2 Injection Current All pins implement protection diodes that protect against electrostatic discharge (ESD). In many cases, both digital and analog pins need to be connected to voltages that are higher than the operating voltage of the device pin.
  • Page 24 Pin Overview Table 22. ADC conversion characteristics Symbol Parameter Conditions Value Unit Input current Current injection injection on one ADC input, different from the converted one. Remains within TUE specification Total -2.5 unadjusted error without current injection Total unadjusted error with current injection NOTE In case overload condition can not be avoided, injection current specification (I...
