Important information

This document includes an overview of the product and detailed instructions
explaining how to install your Advisor Advanced system and program it.
To use this document effectively, you should have the following minimum
qualifications:
• Basic knowledge of alarm systems and components
• Basic knowledge of electrical wiring and low-voltage electrical connections
Read these instructions and all ancillary documentation entirely before installing
or operating this product.
Important note
This manual provides information for all Advisor Advanced and Advisor
Advanced-IP control panels in all variations. "Advisor Advanced control panel"
refers to any variant of the Advisor Advanced control panels, unless specifically
stated otherwise.
List of panel variants
Table 1: List of ATSx500A(-IP) panel variants
Model
ATS1500A-MM
ATS1500A-IP-MM
ATS1500A-SM
ATS1500A-IP-SM
ATS1500A-LP
ATS1500A-IP-LP
ATS3500A-MM
ATS3500A-IP-MM
ATS3500A-LP
ATS3500A-IP-LP
ATS4500A-IP-MM
ATS4500A-IP-LM
Notes
• Not all variants may be available.
• Weight does not include batteries.
Advisor Advanced ATSx500A(-IP) Installation and Programming Manual
Enclosure
Metal
Metal
Metal
Metal
Plastic
Plastic
Metal
Metal
Plastic
Plastic
Metal
Metal
Dimensions (mm)
MM, 315 x 388 x 85
MM, 315 x 388 x 85
SM, 250 x 250 x 86
SM, 250 x 250 x 86
LP, 257 x 400 x 112
LP, 257 x 400 x 112
MM, 315 x 388 x 85
MM, 315 x 388 x 85
LP, 257 x 400 x 112
LP, 257 x 400 x 112
MM+, 315 x 445 x 88
LM, 475 x 460 x 160
Weight (kg)
5.2
5.2
2.8
2.8
2.6
2.6
5.2
5.2
2.6
2.6
5.4
10.9
