American Standard BELFORD 8473502.075 General Description

More Function.
Better Shower Experience.
MULTI-FUNCTION
Reliable For Life
Thermal Shock Protection
REACTS TO SUDDEN PRESSURE CHANGES YET
MAINTAINS CONSISTENT SHOWER TEMPERATURE
Reliable For Life
SUGGESTED SPECIFICATION:
Bath/shower fitting shall feature 3-function showerhead with Max. 2.5 gpm (9.5 L/min) Max flow rate. Fitting shall be American Standard
Model # 8473502.275, SKU# 673-3558 and Model #8473502.278, SKU# 673-3559
© 2016 AS America Inc.
1-HANDLE TUB/SHOWER WITH 3-FUNCTION SHOWERHEAD
MODEL NUMBER:
❑ 8473502.075 Brushed Nickel finish.
SKU# 673-3558
❑ 8473502.278 Legacy Bronze finish.
SKU# 673-3559
Effortless elegance, leading-edge style and thoughtful
innovation combine to make American Standard faucets the
perfect choice for those who are unwilling to sacrifice style
for performance.
GENERAL DESCRIPTION:
Cast brass valve body. Washerless 47 mm ceramic disc
valve cartridge with temperature control. Hot limit safety stop.
Pressure balancing cartridge maintains constant output
temperature in response to changes in relative hot and cold
supply pressures. 1/2" female I.P.S. inlets/outlets. Easy clean
showerhead has 2.5 gpm/ 9.5 L/min flow restrictor. Metal lever
handle. Rough-in plaster guard designed for use as thin-wall
mounting adaptor. I.P.S.
PRODUCT FEATURES:
• Solid Brass Valve Construction:
– Durable, ideal material for prolonged contact
with water.
• Ceramic Disc Valve Cartridge:
– Assures a lifetime of smooth handle operation and
drip-free performance.
• Pressure Balancing Valve:
– Maintains output temperature in response to changes
in relative hot and cold supply pressure.
– Diaphragm system engineered to eliminate cross flow
and spool "thumping".
– Avoids failure due to mineral deposits - ideal for use
with hard water.
• Adjustable Hot Limit Safety Stop:
– Limits the amount of hot water allowed to mix with cold.
– Reduces the risk of accidental scalding.
• Integral Plaster Guard and Mounting Plate:
– Plaster guard designed to protect valve during
installation and to serve as a mounting plate for
thin wall installations.
ROUGH-IN DIAGRAM
SHOWN ON NEXT PAGE
BELFORD
diverter tub spout.
™
6/16
