AVAILABLE DEBUG WINDOWS

The following table lists the debug windows that are available using ZDS.
T 3-1. D
ABLE EBUG WINDOWS
Window
Watch
Z8 Standard
Registers
Code Memory
Disassembly
Z8 Register File
Z8 Expanded
Register
Working Registers
UM005100-IRR0400
Function (Updated values will display in red)
•
Shows the symbols and the contents of the registers (see the
ZDS user manual for more information)
•
Shows the contents of the Z8 standard registers
•
Allows the user to monitor, edit, and download a
into the Code Memory from generated assembly
file.hex
source code
•
Tracks a specific address entered in the Code Address edit box
•
Shows code memory along with the corresponding
disassembled code
•
Allows the user to edit, and download a file.ld or file.hex into
the Code memory
•
Follows the program counter
•
Provides a complete scroll down with this window, however
the scroll up is limited
•
Accesses the disassembly of code at the address specified in
the Code Address field
•
The Disassembly window is automatically displayed when
debugging hex code or whenever there is no corresponding
source file available at the address specified by the program
counter
•
Shows all Z8 internal and external registers, all RAM pointer
and data registers, status registers and status flags, and stacks
•
Monitor and edit write-able registers in this window
•
Displays the Z8 Expanded Register banks that are specified in
the configuration
•
Monitor and edit write-able registers directly in this window by
selecting a specific bank tab
•
Modify and view working registers in this window
