Set-Up and Installation
T
2-1. J
ABLE
UMPER SETTINGS
Jumper Pin
Position
J1
N/A
Out (Default)
JP5
1-2
In
JP5
2-3
In * (Default)
The user can not run the emulator's oscillator if the target oscillator or XTAL is connected. At
N
:
OTE
this time use one of the following methods to set the ICE-chip's clock:
•
To use the emulators oscillator remove the target's oscillator and connect pin 2 to pin 3 on
the J5 jumper
•
To use the target's oscillator and connect pin 1 to pin 2 on the J5 jumper
Setting Jumpers for Targets
For all targets ensure that JP2 and JP4 are always connected. For 40 pin targets also connect
JP3.
UM005100-IRR0400
(C
)
ONTINUED
Description
OTP programming adapter pins
ICE chip uses target oscillator/clock
bottom of the table)
ICE chip uses emulator oscillator/clock
the bottom of the table)
Emulator Operation
(see Note at the
(see Note at
2–11
