Emulator Operation
D S
IP ETTINGS
DIP switch banks S1 and S3 are used to disable digital functions for ports 1 and 3. DIP
switch banks S2, S4, S5 and S6 are used to emulate port pin pull-up transistors for the Ice
Chip. See Figure 2-3 for the location of the DIP switches. The following tables list DIP set-
tings that are easily configured by the user.
T 2-2. DIP
ABLE SETTINGS TO DISABLE DIGITAL FUNCTIONS
DIP bank Switch Description
S1 1
S1 2
S1 3
S1 4
S1 5
S1 6
S1 7
S1 8
T 2-3. DIP
ABLE SETTINGS TO SET PULL
DIP bank Switch Description
S2 1
S2 2
S2 3
S2 4
S2 5
S2 6
S2 7
S2 8
S4 1
S4 2
S4 3
S4 4
S4 5
2–12
Turn off to disable digital functions for Port 5 Pin 0
Turn off to disable digital functions for Port 5 Pin 1
Turn off to disable digital functions for Port 5 Pin 2
Turn off to disable digital functions for Port 5 Pin 3
Turn off to disable digital functions for Port 4 Pin 4
Turn off to disable digital functions for Port 4 Pin 5
Turn off to disable digital functions for Port 4 Pin 6
Turn off to disable digital functions for Port 4 Pin 7
- R
UP ESISTORS
Turn on to set a pull-up resistor for Port 2 Pin 0
Turn on to set a pull-up resistor for Port 2 Pin 1
Turn on to set a pull-up resistor for Port 2 Pin 2
Turn on to set a pull-up resistor for Port 2 Pin 3
Turn on to set a pull-up resistor for Port 2 Pin 4
Turn on to set a pull-up resistor for Port 2 Pin 5
Turn on to set a pull-up resistor for Port 2 Pin 6
Turn on to set a pull-up resistor for Port 2 Pin 7
Turn on to set a pull-up resistor for Port 5 Pin 0
Turn on to set a pull-up resistor for Port 5 Pin 1
Turn on to set a pull-up resistor for Port 5 Pin 2
Turn on to set a pull-up resistor for Port 5 Pin 3
Turn on to set a pull-up resistor for Port 5 Pin 4
