OVERVIEW
Congratulations for selecting a fine development tool! The Z86L9900100ZEM ICEBOX is
ZiLOG's in-circuit emulator providing emulation for the Z8 family of IR controllers. The
emulator is also capable of OTP programming for the family being emulated. The emulator
consists of an emulation daughter board that is plugged into a 64K motherboard via P1 and
P2 headers. The Z86D99 ICE chip is used as the emulation processor on the daughter board.
The motherboard provides host communication interface, control processor, I/O space
decoding and LED indicators. The emulator is designed to be used with ZiLOG Developers
Studio, giving the user a total package to write, edit and debug their applications.
UM005100-IRR0400
Z86L99 ICEBOX U
C
1
HAPTER
I
NTRODUCTION
'
M
SER
S
ANUAL
1–1
