Set-Up and Installation
LED O
PERATION
ZiLOG emulators use LEDs to communicate the different hardware states. The following
table gives a description of the LEDs. The Z86L9900100ZEM LED's are located on the right
front of the emulator.
F 2-4. F LED A
IGURE RONT
LED Indication
READY On
Off
RUN On
Off
OTP On
Off
PWR On
Off
Blink
UM005100-IRR0400
SSIGNMENTS
Description
Communicating in Bisync Mode and waiting for command
Communicating in ASCII Mode or executing Bisync command
Running user code
Not running user code
The Emulator is performing OTP programing
The Emulator is not performing OTP programming
Emulator is powered up and Self Test is completed
Power is off
Emulator is self-testing
