3.5 Additional Inputs and Outputs

3.5.1 Wiring Schematic

When wired and properly programmed, the control terminals provide:
•
Feedback, reference, and other input signals to the frequency converter.
•
Output status and fault conditions from the frequency converter.
•
Relays to operate auxiliary equipment.
•
A serial communication interface.
•
24 V common.
Control terminals are programmable for various functions by selecting parameter options through the local control panel
(LCP) on the front of the unit or external sources. Most control wiring is customer-supplied, unless specified in the factory
order.
3-phase
power
input
DC bus
+10 V DC
0/-10 V DC-
+10 V DC
0/4-20 mA
0/-10 V DC -
+10 V DC
0/4-20 mA
Illustration 3.20 Basic Wiring Schematic
A=Analog, D=Digital
*Terminal 37 (optional) is used for STO. For STO installation instructions, refer to the VLT
Instructions.
**Do not connect cable screen.
MG20N602
Design Guide
91 (L1)
92 (L2)
93 (L3)
95
PE
Switch Mode
88 (-)
Power Supply
89 (+)
10 V DC
15 mA
50 (+10 V OUT)
+ -
A53
53 (A IN)
ON=0/4-20 mA
A54
OFF=0/-10 V DC -
+10 V DC
54 (A IN)
55 (COM A IN)
12 (+24 V OUT)
13 (+24 V OUT)
P 5-00
24 V (NPN)
18 (D IN)
0 V (PNP)
24 V (NPN)
19 (D IN)
0 V (PNP)
20 (COM D IN)
24 V (NPN)
27 (D IN/OUT)
0 V (PNP)
24 V
0 V
24 V (NPN)
29 (D IN/OUT)
0 V (PNP)
24 V
0 V
24 V (NPN)
32 (D IN)
0 V (PNP)
24 V (NPN)
33 (D IN)
0 V (PNP)
*
37 (D IN)
Danfoss A/S © 09/2014 All rights reserved.
(U) 96
(V) 97
(W) 98
(PE) 99
24 V DC
(R+) 82
200 mA
+ -
(R-) 81
relay1
03
02
01
relay2
06
05
04
(COM A OUT) 39
(A OUT) 42
S801
ON=Terminated
OFF=Open
5V
0 V
S801
RS-485
(N RS-485) 69
Interface
(P RS-485) 68
(COM RS-485) 61
®
Motor
Brake
resistor
240 V AC, 2 A
240 V AC, 2 A
400 V AC, 2 A
Analog Output
0/4-20 mA
RS-485
: Chassis
: Ground
**
: PE
: Ground 1
: Ground 2
Safe Torque Off Operating
3 3
61
