Preparation For Use; T-Tool; Sitting And Transferring From The Combi Frame - R82 combi frame User Manual

A
G
B
The Combi Frame is shipped folded so that it
takes up as little room as possible during trans-
port.
To use the Combi Frame, please follow the in-
structions below.
1) Pull out the handle (A).
2) Mount the gas spring in the fitting and let go
A
The T-tool (A) helps to maintain the square pla-
tes in the slot, when mounting or adjusting eg.
side support etc.
Insert tool into slot, twist 90° and tip down to
support the plate.
Before placing the user into the Combi Frame
the wheel locks must be locked in place and
the footplates lifted to the sides or the leg rests
removed.
Place the user into the Combi Frame and adjust
the accessories to achieve the optimal seating
for the user.
It is not necessary to remove the leg rests if the
user is transferred in or out of the Combi Frame
6
using a sling.
PREPARATION FOR
GB
USE
of the handle. Make sure it clicks fully back
into place.

T-TOOL

GB
SITTING AND
GB
TRANSFERRING
FROM THE COMBI
FRAME
