Solinst Levelogger Series User Manual page 7

Levelogger User Guide - Software Version 3.2.3 or Higher
Rainlogger
The Rainlogger is designed for use with most standard tipping-bucket rain
gauges with a reed switch output. It measures rainfall level per sampling period
and a five-minute maximum rainfall. Now users can add precipitation data to
their Levelogger network.
- Compatible with Version 3.2.3 Software using V1.000 firmware or higher
Battery Life:
Clock Accuracy:
Operating Temperature:
Resolution:
Maximum # Readings:
Memory:
Communication:
Sampling Mode:
Sampling Rate:
Size:
Weight:
Materials:
Rainlogger Technical Specifications
10 years (logging two parameters/10 minutes)
± 1 minute/year
-20˚C to 80˚C
0.004 to 0.008" (100 to 200 mm) (dependent on rain gauge type)
40,000 sets of readings
Non-volatile EEPROM / FRAM back-up
Optical infra-red to RS232 or USB
Linear
5 minutes to 99 hours
7/8" x 7" (22 mm x 175 mm)
4.8 oz (135 grams)
Stainless Steel
Page 7
