Levelogger User Guide - Software Version 3.2.3 or Higher
Note:
Do not install generic
drivers that Windows
will locate.
Generic drivers are completely
incompatible with Solinst USB
devices.
If 2) Solinst strongly recommends the use of either Keyspan™ or IO Gear™
USB to RS232 Serial Adapters. These adapters have a sufficiently large buffer
to accommodate the size of data bundle and bit transfer rate of the Levelogger.
Follow the manufacturer's USB Driver and Com port setup installations found
on the CD accompanying the adapter.
If you have installed another brand-name adapter, but cannot communicate
with the Levelogger, in most cases the problem is that the adapter does not
have a large enough internal memory buffer. The minimum buffer size should
be 96 bytes.
4.2 Com Port Designation Set Up:
1) Click Start Settings
2) Click Systems to open the System Properties
3) Click the Hardware tab and click 'Device Manager'
4) Double Click the Ports Icon and select the 'USB Serial Port'
5) Right click and select Properties
6) Click the 'Port Settings' tab and click 'Advanced'
7) Select the Com Port Number and click 'OK'

4.3 Data Directory

The program will save data downloaded to the following default directory:
<C:\Program Files\Solinst\Levelogger3.2\Data> unless otherwise specified
in the Default Directory field of the Application Settings Window.
After completing Application Settings, click the OK button to confirm and save
the settings.
Levelogger V3.2.3 or higher Software is based on 3 functional windows:
Levelogger Settings, used to set up, start and stop the Levelogger,
Data Control, used to download, view and compensate data and Real Time
View, used to actively view data as it is being collected by the logger.
Control Panel
Page 17
