Levelogger User Guide - Software Version 3.2.3 or Higher
Note:
This version of software
is not compatible with
older models of the
Levelogger (Silver LT
and LTC, Black LTC and old Rain
To program and use
Loggers).
the old versions, Levelogger
3.1.1 or 2.0.3 Software and
User Guides can still be
accessed at:
www.solinst.com/Downloads/

1 Introduction to Solinst Levelogger Series and Software

Levelogger Gold Software Version 3.2.3 is intuitive and easy-to-use. It is
designed to support the Levelogger Gold Series of products.
Levelogger Gold
The Levelogger Gold is an absolute (non-vented) data logger, which measures
groundwater and surface water levels and temperature.
displayed as temperature compensated pressure readings, and can be
barometrically compensated with the aid of a Barologger Gold.
- Solinst recommends customers use Version 3.2.3 Software using with
V2.000 firmware or higher
Levelogger Gold Technical Specifications
Level Sensor:
Accuracy (Typical):
Stability of Readings:
Resolution:
Normalization:
Temperature Sensor:
Temp. Sensor Accuracy:
Temp. Sensor Resolution:
Temp. Comp. Range:
Response Time:
Battery Life:
Clock Accuracy:
Operating Temperature:
Maximum # Readings:
Memory:
Communication:
Size:
Weight:
Backwards Compatibility:
Corrosion Resistance:
Other Wetted Materials:
Sampling Modes:
Measurement Rates:
Barometric Compensation:
Full Scale
LT Models
(FS)
F15, M5 16.4 ft., 5 m
F30, M10 32.8 ft., 10 m
F60, M20 65.6 ft., 20 m
F100, M30 98.4 ft., 30 m
F300, M100 328.1 ft., 100 m
Piezoresistive Silicon in 316L Stainless Steel
0.05% FS
Superior, low noise, 6 times better than previously
0.002 to 0.0006% FS
Automatic Temp Compensation
Platinum Resistance Temperature Detector
± 0.05°C
0.003°C
-10 to +40°C
< 1 minute
10 Years - based on one reading/min
± 1 minute /year
-20°C to 80°C
40,000 of level and temperature
Superior reliability EEPROM Slate, rollover
and redundant backup of last 1200 readings
Optical Infra-Red Interface, Serial at 9600 Baud,
Conversion to RS232 or USB Computer Connection
7/8" x 6" (22 mm x 154 mm)
6.3 oz (179 grams)
Full
Zirconium Nitride (ZrN) Coating
316-L Stainless Steel, Delrin, Viton
Linear, Event and User-Selectable with
30 separate line items
0.5 sec to 99 hrs
Software Wizard and one Barologger in local area
(approx. 20 miles/30 km) radius
Water Fluctuation Accuracy
Range (typical)
13.1 ft., 4 m ± 0.010 ft., 0.3 cm
29.5 ft., 9 m ± 0.016 ft., 0.5 cm
62.3 ft., 19 m ± 0.032 ft., 1 cm
95.1 ft., 29 m ± 0.064 ft., 1.5 cm
325 ft., 99 m ± 0.164 ft., 5 cm
Water levels are
Resolution
0.001% FS
0.0006% FS
0.0006% FS
0.0006% FS
0.0006% FS
Page 4
