Symbols

Manufacturer's declaration that the product meets the applicable EC directives.
Suitable for mounting on all surfaces and suitable to cover with insulating material.
F
Passed glow wire test at 850 degrees Celsius. Global European regulations specify 650 degrees Celsius by default.
GLOW WIRE
850 °C
Restriction of Hazardous Substances (RoHS): product complies with the RoHS directive and each homogeneous material does not exceed
the limits for the materials mentioned under the RoHS directive (Pb, Hg, Cd, Cr6+, PBB and PBDE).
RoHS
Dust-tight, no ingress of dust. Protected against the effects of continuous immersion in water
IP68 + (immersion in water at a maximum depth of 50 metres). Only in combination with the liniLED® Mirror Welded Connector.
Dust- tight, no ingress of dust. Protected against close-range high pressure, high temperature spray downs.
Only in combination with the liniLED® Mirror welded connector.
IP69K
CRI
The CRI value of this product is 80 or higher.
80
+
3
MAC
The binning tolerance of this product is 3 MacAdam.
ADAM
S D C M
Protected against impact energy of 5 joules.
IK08
R
Bending of the LED strip is possible with a radius of ≥ 150 millimetres in the speci ed direction.
150 mm
BEND RADIUS
24
Operating voltage of 24 V DC.
V DC
Electrical appliance class III: this product is designed to be supplied from an extra-low voltage (≤ 60.0 V DC or ≤ 42.4 V AC).
Product is resistant against ultraviolet (UV) light or sunlight. Non-UV resistant products can degrade or discolour fast when exposed to UV light.
UV
Product can be cleaned with normal cleaning agents as speci ed in the datasheet under 'chemical compliances'.
CLEANING
This product can be stored and used below 0 degrees Celsius. Verify the minimum storage and operation temperature in the datasheet or manual
for the lowest temperature allowed.
FROST
This product can be applied in seawater and its environment. Elements in seawater will have no harmful e ect on the product.
For chemical speci cations see datasheet. Verify the IP rating for proper use.
SEA
14
