liniLED Diffuse Series Manual page 11

Installation
Step 7 till 10 are optional. Only if provided with IP67 connector.
7
Optional Female connector front and isometric view, notice the white
marker on top (highlighted in orange in the image above).
9
Female
Optional Align the white marker of the Female and Male connector.
11
Turn the power ON.
marker on top (highlighted in orange in the image above).
Male
8
Optional Male connector front and isometric view, notice the white
10
Female
Optional - Snap the connector while keeping the white marker aligned.
Male
11
Manual | liniLED® Diffuse
