1050 W Ac Power Supply - Cisco Secure Network Server 3600 Series Hardware Installation Manual

Server Specifications
AC Input Frequency
Maximum AC Input current
Maximum input volt-amperes
Maximum inrush current
Maximum hold-up time
Maximum output power per PSU
Power supply output voltage
Power supply standby voltage
Efficiency rating
Form factor
Input connector

1050 W AC Power Supply

This section lists the specifications for each 1050 W AC power supply.
Table 7: 1050 W AC Specifications
Description
AC Input Voltage
AC Input Frequency
Maximum AC Input current
Maximum input volt-amperes
Maximum inrush current
Maximum hold-up time
Maximum output power per PSU
Nominal range: 50 to 60Hz
(Range: 47–63 Hz)
9.5 A at 100 VAC
4.5 A at 208 VAC
950 VA at 100 VAC
15 A (sub-cycle duration)
12 ms at 770 W
770 W
12 VDC
12 VDC
Climate Savers Platinum Efficiency (80Plus Platinum certified)
RSP2
IEC320 C14
Specification
Nominal range: 100–120 VAC, 200–240 VAC
(Range: 90–132 VAC, 180–264 VAC)
Nominal range: 50 to 60Hz
(Range: 47–63 Hz)
12.5 A at 100 VAC
6.0 A at 208 VAC
1250 VA at 100 VAC
15 A (sub-cycle duration)
12 ms at 1050 W
800 W at 100–120 VAC
1050 W at 200–240 VAC
Cisco Secure Network Server 3600 Series Appliance Hardware Installation Guide
1050 W AC Power Supply
29
