heat-timer DiGi-SPAN Elite Series Installation And Operation Instructions Manual page 4

Standard
Options: english, metric
: MENU/<System Startup>/Standard
SET
Due to the large variety of inputs available to connect to the TSC Elite, this option helps in narrowing
down the sensor type options.
• I f English is selected, sensor types in ˚F (Fahrenheit), PSI (Pounds/Square inch), Hg (Inches of
Mercury for Vacuum) will be available.
• I f Metric is selected, sensor types in ˚C (Celsius), MPa (Million Pascal), mm (Millimeter of
Mercury for Vacuum) will be available.
• % RH (Relative Humidity) will be available in both options.
Sensor Type
Options: temp.250˚F/121˚C, Pres. 30Psi/0.25mPa, Pres. 100Psi/0.60mPa, Pres. 200Psi/1.0mPa,
Pres. 300Psi/1.6mPa, Vac. 30Hg/760mm, and Humidity %rH
: MENU/<System Startup>/Standard/Sensor Type
SET
The Sensor Type available options depend on the Standard Option selected from the previous menu.
Control Mode
Options: Heat-Breakonrise, Cool-makeonrise, Change-over
SET Button: MENU/<System Startup>/Standard/Sensor Type/Control Mode
• I n Heat-Break-On-Rise mode each relay will energize when the sensor value is below the
corresponding set point.
• I n Cool-Make-On-Rise mode each relay will energize when the sensor value is above the
corresponding set point.
• I n Change-Over mode (Heat/Cool), the first output relay will energize when sensor value is above
SP1. However, when the sensor value falls below SP2, the 2nd output relay will energize.
Operating Mode
(Available in Heat and Cool Modes Only)
Options: independent, Consecutive
: MENU/<System Startup>/..../Operating Mode
SET
• I f the Operating mode is set to Heating and Consecutive, Output2 relay (Blue wires) will operate
from the lowest sensor temperature to the SP2 Setting. However, Output1 relay (White wires) will
operate from SP2 setting to the SP1 Setting.
• I n Consecutive mode, a maximum of one output will be on at any point.
• I n Consecutive mode, no rotation will be available.
• C onsecutive mode, is great for applications where the outputs are not equal in capacity.
• I n Independent mode, both outputs could be on when below the lowest Set Point in Heating or
when above the highest Set Point in Cooling.
Sensor Fault
(Not Available in Change-Over Mode)
Options: all off, all on
v: MENU/<System Startup>/..../Sensor Fault
• T he Sensor Fault will determine the operating status of the relay when a sensor reads Short or
Open. On sensor fault the Set Point will indicate FAULT TGT=ON or OFF to indicate the
condition of the output and the Sensor will read SYSTEM=OPEN or SHORT to indicate the
condition of the sensor.
Manually Resetting the Control to Defaults
To Reset the TSC Elite control to its original factory defaults, power down the control. Hold down
the SET and DOWN buttons while powering the control back up until the Loading Default Values
screen appears. The Display will direct you to the Startup menu after the defaults are loaded to program the control.
When resetting the control to original factory defaults all control settings will be over written and will no longer exist.
4
default: english
default: temp.250˚F/121˚C
default: Heat-Breakonrise
default: independent
default: all on
ALERT
STANDARD:
English
Metric
SENSOR TYPE:
Temp. 250 F
Pres. 30psi
Pres. 100psi
Pres. 200psi
Pres. 300psi
Vacuum 30in
Humidity %RH
SENSOR TYPE:
Temp. 121 C
Pres. 0.250MPapsi
Pres. 0.600MPapsi
Pres. 1.000MPapsi
Pres. 1.600MPapsi
Vacuum 760mm
Humidity %RH
CONTROL MODE:
Heat-BreakOnRise
Cool-MakeOnRise
Change-Over
OPERATING MODE:
Independent
Consecutive
SENSOR FAULT:
Output On
Output Off
SYSTEM= OPEN
FAULT TGT= ON
Loading Default
Values...
