Procedure 2 Installing The Product - Pivot 3 drive BLP User Manual

[Reference 1] How to use the Voltage Detector (supplied with product)
1
Loosen an earthed screw, insert
and fasten the wire tip (coiled wire).
Metal part Metal part Metal part
Wire tip Wire tip Wire tip
2
Connect the tip of the LED to the place you wish to test voltage.
Earth
(Screw,
etc...)
[Reference 2] How to use the Cut Connectors
1
10 mm
Peel off of the vinyl
cover at connection.
[Reference 3] How to use the Male Connectors
1
Male sleeve
Wire
Pull the cable through the
male sleeve.
6
2
procedure
Installing The Controller
(Example of Installation)
Cable processing of the Unit
Fasten the cables not to disconnect connectors Fasten the cables not to disconnect connectors
by getting caught on cables. by getting caught on cables.
To Power
Label
To Specialized
Harness
Zip Tie
(Small)
Specialized
6
Harness
Note: As an ear thing screw, only use a
s c r ew t h at i s fa s te n e d to a m et a l p ar t .
Painted screws and screws connected to
plastic parts become insulated and cannot
carry electricity.
Lamp on : 12V
Voltage Detector
(supplied
Lamp off : 0V
with product)
2 3
10 mm
Peel off of the vinyl
W r a p a r o u n d b o t h
cover at the end of the
wire coils.
product's wire.
2
10
mm
Remove about 10 mm of the
cable casing.
Note: After connecting the male and female
Affix the male sleeve to
the places as mentioned connectors, make sure to firmly twist the
above. male sleeve inside the female sleeve.
Installing The Product
Install the Controller to a position which is easy to see.
Fastening to a Flat Place
Double-sided
tape (Included)
Power Cable
Sorce
Zip Tie
(Small)
Plastic part Plastic part Plastic part
LED lamp
4
Close tightly with cut
connector.
3 4
Turn back the tip of the Connect the male connector
wires. to the end of the cable.
Using the L-shaped Fastener
B y u s i n g t h e
Clean to remove
L-shaped Fastener
oil and dust.
t h a t c o m e s w i t h
this produc t, it is
possible to install
t h e u n i t o n t h e
dashboard even if
it is cur ved or on
an angle.
Note: It is possible to install the
L-shaped Fastener in the reverse
direction.
Controller
Installing The Unit
As shown in the diagram below, fasten the unit into positions not usually affected by water.
(Example of Installation) (Example of Installation)
Under the On the
steering back side of inside of the
column cover the under cover
Do not install into low positions
In some car models, voltage
detector which is supplied
with product doesn't work
b e c a u s e o f t h e c u r r e n t
Painted
screw
capacity shortage. Please
use analog multimeter and
others in this case.
LED
lamp
5
When crimping, please
u s e c r i m p e r s o r u s e
pliers to bend and then
I n s u l a t e w i t h v i n y l
solder together.
tape.
5
Male Connector Crimp these places
Crimp down with crimpers to make sure
that the inner wires are firmly connect-
ed to the inner part of the connector
and that the cable section is connected
to the outer part of the connector.
Double-sided tape
(Included)
Controller
Fastening to a Flat Place
On the
kick panel
Unit
Double-sided
Tape (Square)
Clean
to remove
oil and dust.
L-shaped Fastener
Double-sided tape
(Included)
Adjustable
a n g l e fo r
e a s i e r
viewing
