Pivot 3 drive BLP User Manual page 12

Concerning the Throttle Controller
Trouble
Even if the Mode is changed, the
changes cannot be felt.
The Mode and/or the setting of
change ratios can not be saved.
With the ignition in ON position,
Ec S P
o r i n d i s p l a y a n d
nor
change to .
Concerning Auto-Blipping
Trouble
Auto-Blipping will not operate.
Note
How to Turn Off the Check Engine Light
If the Check Engine Light comes on due to some operational mistake,
please follow the directions below to turn it off.
1. Under normal conditions, start and
stop the engine several times.
2. If that does not turn off the lamp,
disconnect the cable from minus
terminal of the battery for about 10
minutes.
3. If that does not turn off the lamp,
please consult your local car dealer
and have them turn it off.
(Note) • Our products have already been recognized as our Industrial Property or are in the process of receiving Industrial Property status.
• We plan in the near future to take all possible legal measures to protect against unfair competition from look-alike products using
similar designs, regulating characteristics, circuitry and circuitry layout.
• We strictly prohibit the unlicensed use of the PIVOT trademark and the unauthorized use of PIVOT User's Manual.
12
Possible Causes
The "Initial Settings" have not been properly carried out.
The ignition has been tur ned to the OFF position
immediately after having finished the setting of change
ratios or changing the Mode.
The "Initial Settings" have not been properly carried out.
Possible Causes
The Gray Pink and Orange
improperly wired or there is a poor connection.
The clutch adapter may have been improperly wired.
"Speed Pulse Settings" have not been properly carried out.
The "Initial Settings" have not been properly carried out.
"Auto-Blipping" have not been turned on.
"Auto-Blipping Settings" have not been properly carried out.
The speed is lower than the setting value.
Clutch canceller is installed.
Have not pressed brake pedal from starting engine before
operating Auto-Blipping.
Not enough to press the Clutch pedal.
The brake lamp bulbs have been changed to LED lamp bulbs.
Check Engine
Light is ON
PIVOT CORPORATION
Make the "Initial Settings" (See page 7 of this
manual).
After having made settings of change ratios or
changing the Mode, wait for at least 5 seconds
before turning the ignition to the OFF position.
Make the "Initial Settings" (See page 7 of this
manual).
wires may have been Please reconfirm whether wiring and connections
are correct or not (See page 4 to 5 of this manual).
Please reconfirm whether wiring and connections
are correct or not (See page 4 of this manual).
Make the "Speed Pulse Settings" (See page 8 of
this manual).
Make the "Initial Settings" (See page 7 of this
manual).
Please reconfirm how to operate Auto-Blipping (See
page 8 to 9 of this manual).
Please reconfirm "Auto-Blipping Settings" (See page
8 to 9 of this manual).
Please reconfirm "Auto-Blipping Settings" (See page
8 to 9 of this manual).
May need to remove it.
Press the brake pedal before operating Auto-
Blipping.
Depress the clutch pedal deeper.
Replace with standard brake lamp bulbs.
87-3, Shimookada Okada, Matsumoto-shi, Nagano, 390-0313 Japan
Possible Solutions
Possible Solutions
