Operating the Throttle Controller

Switching Response Levels
Switch the Mode
1
Engine Start.
2
The Mode will change
with each pressing of
the MODE switch.
SPORTS Mode
NORMAL Mode
ECO Mode
Note: For safety, when changing modes always go
nor
through
Saving Settings
[Reference 1] Examples of changes in fuel consumption and
response depending on change ratios
MODE
Good
RESPONSE
Good
FUEL
EFFICIENCY
Note: In ECO Mode, because response is less than the standard fuel efficiency
can be improved. However, if rapid acceleration is purposefully carried
out fuel efficiency will be reduced.
The changes in response will be greater as the vehicle's power is greater.
Degree of Acceleration Monitor
Degree of Acceleration Monitor shows the rate of acceleration output to the ECU where 0 represents the pedal not being pressed in and 100
equals when the pedal is fully pressed down.
Note: Depending on characteristics of the accelerator or on how the accel-
erator is stepped on the display may read up to 95%.
1
Check acceleration during ECO driving
USE
To e n s u r e r e d u c e d f u e l
consumption during accelera-
tion the degree of acceleration
should be between 15% and
25%. To further improve results
use ECO Mode when wishing
to save fuel.
2
Check acceleration during regular driving
USE
Please use to check the degree of acceleration for any type of
driving, not just ECO Mode.
10
START
Press
Higher
Response
Normal
Conditions
Lower
Response
(NORMAL) one time.
All settings are saved even after the ignition has been turned to the OFF position. However, if the ignition is
turned OFF in 5 seconds or less after the last setting operation was carried out, the settings will not be saved.
SPORTS NORMAL
7 6 5 4 3 2 1
Bad
Bad
-
＝
0 0
% %
10 100 100
% %
ECO
Make settings for response in each Mode.
Adjust the Change Ratio for each Mode
When making adjustments to the change ratios, begin at the lowest
setting and slowly make changes while continually checking acceleration.
• Switch the Change Ratio for SPORTS Mode
is displayed, the ratio will
change with each pressing of the
UP / DOWN switch.
Smallest
Change Ratio
(+10%) (+20%)
• Switch the Change Ratio for ECO Mode
is displayed, the ratio will
change with each pressing of the
UP / DOWN switch.
Greatest
Change Ratio
(−50%) (−40%)
ECO
1 2 3 4 5
Displays the amount of pressure placed on the accelerator pedal.
(output signal) [15–100%, 5% unit]
Degree of Acceleration
3
Check control status
USE
With the ignition in the ON position
( e n g i n e n o t r u n n i n g ) a n d u n d e r
NORMAL Mode press in the pedal
A 4 0
until it reaches 40% ( ), if the
SP7
Mode is changed to the display
A65
should read 65% ( ) and if placed
Ec5
in the display should change to
A25
25% ( ).
[S e e t h e a b ove G r a p h of " B a s i c
Control Features"] Note: The actual
display may differ slightly.
(+30%) (+60%)
(−30%) (−20%)
[Reference 2] Basic Control Features
T h e c h a n g e s t h r o u g h o u t e a c h M o d e w i l l b e
controlled smoothly without perceptible steps.
Acceleration output signal based on amount of
pressure placed on accelerator pedal
100
SP 7
50
Ec 5
0
50
Amount of pressure placed on
the accelerator pedal (%)
(output) 20%
Press down on pedal.
40
%
SP7
Switch Mode to
Greatest
Change Ratio
SP7
( side)
Lowest
Change Ratio
SP1
( side)
Greatest
Change Ratio
(+70%)
Lowest
Change Ratio
Ec1
( side)
Greatest
Change Ratio
Ec5
( side)
Smallest
Change Ratio
(−10%)
100
In NORMAL Mode
Ec5
Switch Mode to
