I319EI01.fm Page 1 Wednesday, September 29, 1999 10:56 AM
DGP-319
Installer's Guide
Wireless Bus Module V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Digiplex Liberator DGP-319 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paradox Digiplex Liberator DGP-319

Summary of Contents for Paradox Digiplex Liberator DGP-319

  • Page 1 I319EI01.fm Page 1 Wednesday, September 29, 1999 10:56 AM DGP-319 Installer’s Guide Wireless Bus Module V1.0...

  • Page 2: Table Of Contents

    I319EI01.fm Page 3 Wednesday, September 29, 1999 10:56 AM 1.0 TABLE OF CONTENTS INTRODUCTION ................5 1.1 Technical Specifications ..............5 1.2 System Features ................. 5 INSTALLATION ................6 2.1 Location ....................6 2.2 Connections and Mounting ..............6 PROGRAMMING ................8 3.1 Entering Module Programming Mode ..........
  • Page 3 I319EI01.fm Page 4 Wednesday, September 29, 1999 10:56 AM REMOTE CONTROLS ..............19 5.1 Assigning Remote Controls to Receiver Module ....... 20 5.2 Assigning Remote Controls to User Access Codes ......21 5.3 Programming Remote Control Buttons ..........21 5.4 Replacing the Remote Control’s Battery ..........26 PROGRAMMING GUIDE .............

  • Page 4: Introduction

    I319EI01.fm Page 5 Wednesday, September 29, 1999 10:56 AM 1.0 INTRODUCTION 1.1 T ECHNICAL PECIFICATIONS Manchester Decoding Diversity Antenna Error Detection & Correction Frequency Hopping: @ 902 MHz - 928 MHz or 868MHz Range: Detectors & Contact Switches: 1000 m (3280’) or 300 m (984’) for 868 MHz Remote Controls: 30 m (100‘) Data Rate: 10 KB/s...

  • Page 5: Installation

    I319EI01.fm Page 6 Wednesday, September 29, 1999 10:56 AM 2.0 INSTALLATION 2.1 L OCATION Mount the Liberator Wireless Bus Module on a wall allowing at least 5 cm (2") around the module to permit adequate ventilation and heat dissipation. Select a site that is not susceptible to drastic temperature changes.
  • Page 6 I319EI01.fm Page 7 Wednesday, September 29, 1999 10:56 AM Figure 2-1: Connections for Receiver Module to Control Panel Digiplex Liberator 7...

  • Page 7: Programming

    I319EI01.fm Page 8 Wednesday, September 29, 1999 10:56 AM 3.0 PROGRAMMING 3.1 E NTERING ODULE ROGRAMMING All programming is done through Module Programming Mode in the Digiplex Control Panel from any keypad as shown in Figure 3-1. The sections referred to in Step 5 and the data referred to in Step 6 from Figure 3-1 are explored in the following sections of the manual.

  • Page 8: Feature Select Programming

    I319EI01.fm Page 9 Wednesday, September 29, 1999 10:56 AM 3.1.1 Feature Select Programming Feature Select Programming is accomplished by enabling and/or disabling options. Feature Select Programming is used to program sections [001] and [002] and is also used in PGM Programming. Within the sections, numbers from 1 to 8 represent a specific option to enable or disable.

  • Page 9: Check-In Supervision

    I319EI01.fm Page 10 Wednesday, September 29, 1999 10:56 AM 3.3 C HECK UPERVISION [001]: SECTION OPTIONS The Liberator Wireless Bus Module waits for each of its assigned detectors and/or contact switches to send a status signal within a specified time period to confirm their presence and functionality.

  • Page 10: Pgm Deactivation Mode

    I319EI01.fm Page 11 Wednesday, September 29, 1999 10:56 AM 3.5 PGM D EACTIVATION [002]: SECTION OPTION The Liberator Wireless Bus Module has one or two on-board PGMs. Each PGM can be in Follow Mode or in Timed Mode. If the PGM is in Follow Mode, it will deactivate according to its PGM Deactivation Event.

  • Page 11: Pgm Timers

    I319EI01.fm Page 12 Wednesday, September 29, 1999 10:56 AM 3.7 PGM T IMERS [003] [004] SECTIONS When PGM(s) are in Timed Mode, the value programmed for PGM 1 in section [003] and for PGM 2 in section [004] are multiplied by the PGM Base Time. This value can be any decimal from 001 to 255.

  • Page 12: Pgm Deactivation Event

    I319EI01.fm Page 13 Wednesday, September 29, 1999 10:56 AM Use the PGM Programming Table to program a PGM Activation Event by following these steps: 1) In the selected section, enter the first digit where each digit is a hexadecimal value from 8 to F that represents a specific event (0 = PGM Disabled). 2) Then enter the second digit, which can be any hexadecimal value from 0 to F depending on the first digit chosen.

  • Page 13: Pgm Override

    I319EI01.fm Page 14 Wednesday, September 29, 1999 10:56 AM 3.10 PGM O VERRIDE [002]: [7], [4] SECTION OPTIONS When the PGM Override is enabled in options [3] and/or [7], the Liberator Wireless Bus Module will ignore the PGM Mode, PGM Activation Events, PGM Deactivation Events, and PGM Timers of the corresponding PGM(s).

  • Page 14: Viewing Unknown Serial Numbers

    I319EI01.fm Page 15 Wednesday, September 29, 1999 10:56 AM To perform the system reset: 1) Disconnect the DIGI-BUS from the Receiver Module 2) Place the reset jumper on both reset pins on the Receiver Module. 3) Reconnect the DIGI-BUS to the Receiver Module 4) Wait until the "Locate"...

  • Page 15: Detectors And Contact Switches

    I319EI01.fm Page 16 Wednesday, September 29, 1999 10:56 AM 4.0 DETECTORS AND CONTACT SWITCHES Programming for the wireless detectors and the contact switches is accomplished in three steps: 1) Detectors and contact switches must be assigned to the Liberator Wireless Bus Module.
  • Page 16 I319EI01.fm Page 17 Wednesday, September 29, 1999 10:56 AM [101] [116] SECTIONS Enter the serial numbers of the detectors and contact switches in the sections [101] to [116]. The serial numbers can be found inside the devices. Inputs 001 to 016 are automatically assigned when the serial number is entered.

  • Page 17: Assigning Detectors & Contact Switches To Zones

    I319EI01.fm Page 18 Wednesday, September 29, 1999 10:56 AM 4.2 A & C SSIGNING ETECTORS ONTACT WITCHES TO ONES Once the detectors and the contact switches have been assigned to the Liberator Wireless Bus Module, they must be assigned to zones in the control panel. For instructions how to assign the devices to the zones and then program the zones, refer to the Digiplex Control Panel's Reference &...

  • Page 18: Remote Controls

    I319EI01.fm Page 19 Wednesday, September 29, 1999 10:56 AM 5.0 REMOTE CONTROLS To program the remote controls: 1) Remote controls must be assigned to the Liberator Wireless Bus Module 2) The remote controls from the Liberator Wireless Bus Module must be assigned to User Access Codes in the Digiplex Control Panel.

  • Page 19: Assigning Remote Controls To Receiver Module

    I319EI01.fm Page 20 Wednesday, September 29, 1999 10:56 AM 5.1 A SSIGNING EMOTE ONTROLS TO ECEIVER ODULE In these sections you will assign the remote controls to the Receiver Module. Up to 16 remote controls can be assigned to each Receiver Module. [301] [316] SECTION...

  • Page 20: Assigning Remote Controls To User Access Codes

    I319EI01.fm Page 21 Wednesday, September 29, 1999 10:56 AM 5.2 A SSIGNING EMOTE ONTROLS TO CCESS ODES [401] [416] SECTIONS Each remote control must be assigned to a User Access Code. All User Access Codes are given a User Number from 01 to 64 (01 is the System Master Code). Each section from [401] to [416] represents the remote control assigned to sections [301] to [316] (see section 5.1 of this manual).
  • Page 21 I319EI01.fm Page 22 Wednesday, September 29, 1999 10:56 AM Figure 5-1: Remote Controls with button identification When you enter each section from [501] to [516], each digit represents a button or a combination of buttons pressed simultaneously. Table A: Button choices: [0] = Not used [8] = Panic 2 [1] = Regular Arm...
  • Page 22 I319EI01.fm Page 23 Wednesday, September 29, 1999 10:56 AM These keys represent the hexadecimal values from A to F: [STAY] [DISARM] = D [FORCE] = B [BYP] [ARM] [MEM] For installations using the LED Keypads, the hexadecimal values will illuminate the following LEDs: ] LED = [A4] LED STAY...
  • Page 23 I319EI01.fm Page 24 Wednesday, September 29, 1999 10:56 AM Figure 5-2: Button programming shown on LCD screen *Four-button remote control not currently available. Therefore, C, D, C+D, A+C, and B+D are for future use. In Figure 5-3 button A is programmed to Regular Arm, button B is programmed to Disarm, and the combination of buttons A+B is programmed to activate the PGM(s) according to PGM Table, First Digit 8, Second Digit 0, Feature 4.
  • Page 24 I319EI01.fm Page 25 Wednesday, September 29, 1999 10:56 AM For installations using LED Keypads: Completing the Programming Guide (see section 6.0 of this manual) before beginning Button Programming is suggested. From Step 5 in Figure 3-1, page 8: 1) Enter a section from [501] to [516] depending on the remote control you want to program.

  • Page 25: Replacing The Remote Control's Battery

    I319EI01.fm Page 26 Wednesday, September 29, 1999 10:56 AM 3) Press [ ] once the remote control is programmed. The keypad will ENTER automatically switch to the next section for the next remote control. Once you have programmed section [501], the keypad will emit a Confirmation Beep.

  • Page 26: Programming Guide

    I319EI01.fm Page 27 Wednesday, September 29, 1999 10:56 AM 6.0 PROGRAMMING GUIDE Enter Module Programming Mode (see section 3.1 of this manual): Bold = default [0] + [ ] + [953] + [ #] + [ INSTALLER CODE SERIAL SECTION SECTION [001]: Supervision Option l Disabled...
  • Page 27 I319EI01.fm Page 28 Wednesday, September 29, 1999 10:56 AM Section: [003] ___/___/___ (default 005) PGM 1 Timer (001 to 255) [004] ___/___/___ (default 005) PGM 2 Timer (001 to 255) [005] PGM 1 Activation Event ___/___ (1 2 3 4 5 6 7 8 ) PGM Table (Select Feature) [006] PGM 1 Deactivation Event ___/___ (1 2 3 4 5 6 7 8 ) PGM Table...
  • Page 28 I319EI01.fm Page 29 Wednesday, September 29, 1999 10:56 AM Table 1: Motion Detectors and Contact Switches Motion Contact Section: Input: Serial Number: Detector Switch [101] ___/___/___/___/___/___ [102] ___/___/___/___/___/___ [103] ___/___/___/___/___/___ [104] ___/___/___/___/___/___ [105] ___/___/___/___/___/___ [106] ___/___/___/___/___/___ [107] ___/___/___/___/___/___ [108] ___/___/___/___/___/___ [109] ___/___/___/___/___/___ [110]...
  • Page 29 I319EI01.fm Page 30 Wednesday, September 29, 1999 10:56 AM Complete Table 2: Remote Controls [301] to [316] (see Table 2) Assignment of the Remote Controls to the Receiver Module [401] to [416] (see Table 2) Assignment of Remote Controls to User Acces Codes [501] to [516] (see Table 2) Programming the button functions for the Remote Controls [025] To view the serial number of an unlabeled device...
  • Page 30 I319EI01.fm Page 31 Wednesday, September 29, 1999 10:56 AM Table 2: Remote Controls User Button Programming Section and Name: Serial Number: Number (A B) (C D) (A+B C+D) (A+C B+D) __________ __/__/__/__/__/__ __/__/__ ( _/_ ) ( _/_ ) ( _/_ ) ( _/_ ) 301: __________ __/__/__/__/__/__...

  • Page 31: Pgm Programming Table

    I319EI01.fm Page 32 Wednesday, September 29, 1999 10:56 AM 7.0 PGM PROGRAMMING TABLE...
  • Page 32 I319EI01.fm Page 33 Wednesday, September 29, 1999 10:56 AM...
  • Page 33 I319EI01.fm Page 34 Wednesday, September 29, 1999 10:56 AM...
  • Page 34 I319EI01.fm Page 35 Wednesday, September 29, 1999 10:56 AM...
  • Page 35 I319EI01.fm Page 36 Wednesday, September 29, 1999 10:56 AM...
  • Page 36 I319EI01.fm Page 37 Wednesday, September 29, 1999 10:56 AM Warranty The Seller warrants its products to be free from defects in materials and workmanship under normal use for a period of one year. Except as specifically stated herein, all express or implied warranties whatsoever, statutory or otherwise, including without limitation, any implied warranty of merchantability and fitness for a particular purpose, are expressly excluded.
  • Page 37 I319EI01.fm Page 38 Wednesday, September 29, 1999 10:56 AM...
