Paradox DGP2-ZX4 Instructions

4-Zone Hardwire Expansion Module (DGP2-ZX4)
I
NTRODUCTION
The DGP2-ZX4 is a 4-zone expansion module that connects
directly to the Digiplex/DigiplexNE control panel. The DGP2-ZX4
provides four additional hardwired input terminals.
I
NSTALLATION
The DGP2-ZX4 is linked directly to the control panel:
If connecting to a Digiplex (DGP-48)
Connect the DGP2-ZX4's Expander Connector cable to the
Expansion connector on the control panel as shown in Figure 1.
If connecting to a DigiplexNE (DGP-NE96)
Connect the DGP2-ZX4's Expander Connector cable to the Zone
Expander Connector on the control panel as shown in Figure 1.
Z P
ONE ROGRAMMING
The control panel recognizes the DGP2-ZX4's inputs as follows:
NO ATZ:
DGP2-ZX4 Input 1 =
DGP2-ZX4 Input 2 =
DGP2-ZX4 Input 3 =
DGP2-ZX4 Input 4 =
ATZ ENABLED:
DGP2-ZX4 Input 1 =
DGP2-ZX4 Input 2 =
DGP2-ZX4 Input 3 =
DGP2-ZX4 Input 4 =
Instructions
DGP2ZX4-EI01
Digiplex
Input 009
Input 010
Input 011
Input 012
Digiplex
Input 009 & 013
Input 010 & 014
Input 011 & 015
Input 012 & 016
DigiplexNE
Input 009
Input 010
Input 011
Input 012
DigiplexNE
Input 009 & 021
Input 010 & 022
Input 011 & 023
Input 012 & 024
