6) Lower the engine onto front crossmember.
7) Tighten the nuts which install front cushion rub-
ber onto front crossmember.
Tightening torque:
⋅
85 N m (8.7 kgf-m, 62.7 ft-lb)
8) Install the front and center exhaust pipe. <Ref. to
EX(H4SO 2.0)-7, INSTALLATION, Front Exhaust
Pipe.> <Ref. to EX(H4SO 2.0)-9, INSTALLATION,
Center Exhaust Pipe.>
9) Install the under cover.
10) Lower the vehicle.
CAUTION:
When lowering the vehicle, lower the lift-up de-
vice and wire ropes at the same time.
11) Remove the lifting device and wire ropes.
12) Install the pitching stopper.
Tightening torque:
⋅
T1: 50 N m (5.1 kgf-m, 36.9 ft-lb)
⋅
T2: 58 N m (5.9 kgf-m, 42.8 ft-lb)
T2
Oil Pan and Strainer
LU-00223
LU-00222
T1
LU-00233
LU(H4SO 2.0)-17
13) Install the hood stay holder (A) and radiator up-
per brackets (B).
(B)
14) Install the air intake chamber.
<Ref. to IN(H4SO 2.0)-7, INSTALLATION, Air In-
take Chamber.>
15) Install the air intake duct and air cleaner case.
<Ref. to IN(H4SO 2.0)-8, INSTALLATION, Air In-
take Duct.> <Ref. to IN(H4SO 2.0)-5, INSTALLA-
TION, Air Cleaner Case.>
16) Install the front wheels.
17) Connect the ground cable to battery.
18) Fill the engine oil. <Ref. to LU(H4SO 2.0)-9, IN-
SPECTION, Engine Oil.>
C: INSPECTION
Visually check that the oil pan, oil strainer, oil
strainer stay and baffle plate are not damaged.
LUBRICATION
(B)
(A)
LU-00232
IN-00203
