- Page 1 Operation Manual Professional Power Amplifier DSA 500Q/2000Q...
- Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
Important safety Instructions......................2 Features ............................3 Contents and Accessories ......................3 Front Panel ............................4 Rear Panel ............................6 Installation Precautions .......................10 OLED Operating Instructions ......................11 Applications ..........................23 Block Diagram ..........................27 Specifications ..........................28 Service Procedures............................30 schematic.............................30 Parts list ............................30 Variations and Options .......................30 Warranty ............................30 DsA-500Q/2000Q... -
Page 4: Unpacking
ProfessIonAl PoWer AMPlIfIer Unpacking Unpacking Although your DsA-500Q/2000Q is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. -
Page 5: Features
- HIGH-POWERED, HIGH-CAPACITY 4-CHANNEL CLASS-D POWER AMPLIFIER features a high-powered, high-capacity Class-D Power Amplifier capable of producing up to 3200W (800WX4CH)/8000W (2000WX4CH). * DsA-500Q-4Ω: 500W-4CH, 2Ω: 800W-4CH * DsA-2000Q-4Ω: 2000W-4CH, 2Ω: 2000W-4CH - DANTE AUDIO NETWORK TRANSMISSION SOLUTION The device features the DAnTe Audio network Transmission solution from Audinate which enables audio transmissions via a TCP/IP ethernet network. -
Page 6: Front Panel
When the indicator comes on, remove all cables connected to the device, wait until the fAn stops moving (approximately 15 seconds), then restart the device in accordance with standard booting protocols. If the device operates normally when power is connected, it is highly likely that an issue has occurred DsA-500Q/2000Q... - Page 7 PrT, it may mean the device is broken. In such case, inspect your device at the Inter-M branch you purchased your device or visit our customer service center.
-
Page 8: Rear Panel
1. AC INPUT TERMINAL Terminal that connects the power cord that comes with the device. The power source is AC 220-240V, ※ for DsA-500Q, the fAn will begin operating quickly when the AC Powercon that comes with the device 50/60Hz. - Page 9 Connecting a speaker to CH 1, 2 using the 4 Pole speaker socket for CH 1, 2 only (sTereo MoDe) CH 2 CH 1 Connecting a speaker to CH 1 using the 4 Pole speaker socket for CH 1 only (sTereo MoDe) CH 2 CH 1 DsA-500Q/2000Q...
- Page 10 Therefore, use unbalanced jacks only when devices are grouped closely together. If using a balanced jack in an unbalanced manner, please refer to the following image to connect. DsA-500Q/2000Q...
- Page 11 Therefore, use unbalanced jacks only when devices are grouped closely together. If using a balanced jack in an unbalanced manner, please refer to the following image to connect. The Xlr link Terminal is positioned alongside the Xlr Input Terminal. Xlr JACK DsA-500Q/2000Q...
-
Page 12: Installation Precautions
Fully Open AC INPUT 1000 1600 2. When using power amplifier, please install the unit where there is no airflow block to the heat sink. (Front) 10cm or less(away more than 10cm) (Front) ( X ) ( X ) DsA-500Q/2000Q... -
Page 13: Oled Operating Instructions
If you turn the switch on when the system is displaying this screen, power will be supplied and the oleD control screen will appear. 3. Initial OLED Control Screen ❷ ❸ LOCK OFF PC OFF DSP [ IN <-> OUT ] ❹ IP : 192. 168. 1. 99 ❶ DsA-500Q/2000Q... - Page 14 (check speaker impedance), and the speakon cable connection (whether or not a short has occurred). Unlike TeMP lIMIT, the device manages its oUTPUT sHorT status separately for each CH. DsA-500Q/2000Q...
- Page 15 If you press the CH/MUTe button again after selecting a channel, you can use the MUTe function for the corresponding channel. If you press the button again in MUTe, you can return the system to its original <-> sound level. You will be redirected to the previous screen when you press the esC button. DsA-500Q/2000Q...
- Page 16 PreseT and UTIlITY. PreseT, UTIlITY items are also available in the oUT MenU. ● oUT MenU [ OUT MENU ] 1:2 [ OUT MENU ] > OUT FILTER/X-OVER > UTILITY OUT PEQ OUT LIMITER OUT POLARITY OUT DELAY PRESET DsA-500Q/2000Q...
- Page 17 DAnTe Digital Audio PorT to the output channel (speaker connection terminal) you want to use. Initial configuration: AnAloG[1]->CH1, AnAloG[2]- >CH2, AnAloG[3]->CH3, AnAloG[4]->CH4. You can select from 8 soUrCes, including AnAloG [1]~[4], DAnTe [rX0]~[rX3], etc. DsA-500Q/2000Q...
- Page 18 When TYPe is configured to PeQ, Q fACTor can be set between 0.1 and 12.0 in 0.1 step increments. When TYPe is configured to Hsf or lsf, it can be set between 0.1 and 1.0 in 0.1 step increments. 20.0HZ DsA-500Q/2000Q 20.0HZ...
- Page 19 As for fIlTer, you can choose between HPf and lPf. freQUenCY can be set between 20Hz and 20kHz in 0.1Hz step increments. for TYPe, you can select between off, BUTTerWorTH, Bessel, and lInKWITZ-rIleY. sloPe can be configured between 12dB/oct, 18dB/oct, and 24dB/oct. DsA-500Q/2000Q...
- Page 20 ATTACK, and THresHolD. releAse can be set between 20msec and 4000msec in 1msec step increments. ATTACK can be set between 1msec and 50msec in 1msec step increments. THresHolD can be set between 0.0dBfs and 25dBfs in 0.1dBfs step increments. DsA-500Q/2000Q...
- Page 21 PreseT settings offers load preset, save preset, and View Preset functions. Instructions for PreseT settings are identical to the instructions for PreseT settings from the In MenU. for more detailed setting instructions, please refer to section 4. 5 PreseT seTTInG on page 17 of this manual. DsA-500Q/2000Q...
- Page 22 CHAnGe allows you to modify configuration values. once you have changed the neTWorK seTUP configuration, set the selector to CHAnGe and press down the seleCT/enTer (enCoDer) dial at the front to save your new settings. 6. 2 LOCK PANEL [ LOCK STATE SET ] > LOCK UNLOCK DsA-500Q/2000Q...
- Page 23 DeVICe nAMe displays the name of the device. You can change the DeVICe nAMe from the PC program. Please refer to the PC program manual for detailed instructions. You can download the PC program manual from our company’s official website (www.inter-m.net). 6. 4 FACTORY RESET [ FACTORY RESET ] >...
- Page 24 ※ If you cannot remember your password, you can reset the device to factory settings using the fACTorY seleCT/enTer (enCoDer) dial at the front to save your new password. reseT option. Please be aware that fACTorY reseT will initialize all settings. DsA-500Q/2000Q...
-
Page 25: Applications
● How to connect your PC with 2 or more devices Connect the eTHerneT PorT on the back of the device and the eTHerneT PorT on your PC using a HUB. AC INPUT 1000 1600 AC INPUT 1000 1600 AC INPUT 1000 1600 DsA-500Q/2000Q... - Page 26 ● How to connect a Pe15 with BrIDGeD MoDe (DsA-500Q) MIXER WR-S92L WH-S91L CDR-01 WB-S91L DSA-500Q BRIDGE MODE BRIDGE MODE PE15 PE15 ● How to connect an He10 and He15 with BrIDGeD MoDe (DsA-500Q) MIXER WR-S92L WH-S91L CDR-01 WB-S91L DSA-500Q BRIDGE MODE HE15 HE10 HE10...
- Page 27 ● How to connect an nlA-5/15s with BrIDGeD MoDe (DsA-2000Q) MIXER WR-S92L WH-S91L CDR-01 WB-S91L DSA-2000Q BRIDGE MODE BRIDGE MODE NLA-5/15S NLA-5/15S ● How to connect a Pe12 and nlA-5/15s with BrIDGeD MoDe MIXER WR-S92L WH-S91L CDR-01 WB-S91L DSA-2000Q BRIDGE MODE NLA-5/15S PE12 PE12 DsA-500Q/2000Q...
- Page 28 3. How to connect with speaker/network audio input ● How to connect a Pe15 with BrIDGeD MoDe MIXER WR-S92L WH-S91L CDR-01 WB-S91L DASR-288 (DANTE AUDIO CONTROLLER) DSA-500Q BRIDGE MODE PE15 PE15 PE15 ● How to connect an He10 and He15 with BrIDGeD MoDe MIXER WR-S92L...
-
Page 29: Block Diagram
ProfessIonAl PoWer AMPlIfIer Block Diagram Block Diagram DsA-500Q/2000Q... -
Page 30: Specifications
ProfessIonAl PoWer AMPlIfIer Specifications Specifications DSA-500Q DSA-2000Q 8Ω, sTereo MoDe 300W 1200W 4Ω, sTereo MoDe 500W 2000W(900W) rated output power - 2Ω, sTereo MoDe 800W(400W) 2000W(450W) 20ms burst(static) 8Ω, BrIDGeD Mono MoDe 1000W 4000W(1800W) 4Ω, BrIDGeD Mono MoDe 1600W(800W) 4000W(900W) - Page 31 ProfessIonAl PoWer AMPlIfIer ※ DIMENSIONS DsA-500Q/2000Q...
-
Page 32: Service
To obtain specific warranty information and available service locations contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 33 noTe...
- Page 34 noTe...
- Page 36 Inter-M, ltd. (Korea) began operations in 1983. since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (oeM).
