Summary of Contents for Inter-m Dante DAC-288
- Page 1 Operation anual Dante mplifier Controller D C-288...
- Page 2 D NTE MPLIFIER CONTROLLER Welcome Welcome personal welcome to you from the management and employees of Inter-M ll of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products. We sincerely trust this product will provide years of satisfactory service, but if anything is not to your complete satisfaction, we will endeavor to make things right.
-
Page 3: Table Of Contents
D NTE MPLIFIER CONTROLLER Contents Contents Unpacking ............................2 Installation Environment............................2 Important Safety Instructions......................2 Features ............................3 Component and ccessory.......................3 Consideration for network set-up ......................3 Front Panel ............................4 Rear Panel ............................5 System Connections ........................7 pplications ............................8 Block Diagram ..........................10 Specifications ..........................11 Service Procedures............................13 Schematic .............................13 Parts List ............................13... -
Page 4: Unpacking
D NTE MPLIFIER CONTROLLER Unpacking Unpacking lthough your D C-288 is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. s with most electronic devices, we strongly recommend you retain the original packaging. -
Page 5: Features
D NTE MPLIFIER CONTROLLER Features Features The D C-288 is a digital audio transport system utilizing udinate’s Dante network audio solution. The D C-288 connects to your network with a single Ethernet cable. It offers eight channels (2 mic/line selectable) of line-level analogue in and out, using precision 24-bit -D and D- conversion for superb audio... -
Page 6: Front Panel
D NTE MPLIFIER CONTROLLER Front Panel Front Panel 1. UDIO IN/OUT LED LED displaying audio signal input and output of each channel. 2. NETWORK ST TUS LED (PRIM RY/SECOND RY) LED displaying network data transmission and network access condition of equipment. GREEN LED : 10 Base-T/100 Base-Tx Network RED LED : 1000 Base-T Network 3. -
Page 7: Rear Panel
D NTE MPLIFIER CONTROLLER Rear Panel Rear Panel LINE INPUT (0dBu / 10kΩ) LINE / MIC LEVEL LEVEL CH 8 CH 7 CH 6 CH 5 CH 4 CH 3 CH 2 CH 1 PHANTOM PHANTOM AC INPUT CONTACT OUTPUT H C G H C G H C G... - Page 8 D NTE MPLIFIER CONTROLLER 5. RS-232C COMMUNIC TION TERMIN L If inputting a signal into RS-232C terminal of transmitter, the signal is outputted via RS-232C of receiver. For example, the same signal from receiver is outputted when inputting ' , B, C, D' into transmitter. MAIN POINT DATA...
-
Page 9: System Connections
D NTE MPLIFIER CONTROLLER System Connections System Connections D C-288... -
Page 10: Pplications
D NTE MPLIFIER CONTROLLER pplications pplications TUNER DRY CONTACT DECK IN/OUT DEVICES LINE / MIC LINE INPUT (0dBu / 10kΩ) LEVEL LEVEL CH 2 CH 1 CH 8 CH 7 CH 6 CH 5 CH 4 CH 3 PHANTOM PHANTOM AC INPUT CONTACT OUTPUT H C G... - Page 11 College of Engineering D NTE MPLIFIER CONTROLLER College of Humanities Headquarter College of Arts *LAN: Local Area Network Disaster Prevention Center D C-288...
-
Page 12: Block Diagram
D NTE MPLIFIER CONTROLLER Block Diagram Block Diagram D C-288... -
Page 13: Specifications
D NTE MPLIFIER CONTROLLER Specifications Specifications D C-288 UDIO Max Input Level LINE : + 20dBu, MIC : -30dBu Max Output Level + 20dBu Frequency Response 30Hz ~ 20kHz T.H.D Less than 0.1% Sampling Frequency 48kHz Quantization Bit 24bit Data Communication Dry Contact, RS-232C Communication... - Page 14 D NTE MPLIFIER CONTROLLER ※ DIMENSIONS D C-288...
-
Page 15: Service
D NTE MPLIFIER CONTROLLER Service Service Procedures Take steps to insure the problem is not related to operator error or other products within the system. Information provided in the troubleshooting portion of this manual may help with this process. Once it is certain that the problem is related to the product contact your warranty provider as described in the warranty section of this manual. - Page 16 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
