- Page 1 Operation anual DIGIT L MULTI MPLIFIER DP -5075M...
- Page 2 Welcome personal welcome to you from the management and employees of Inter-M ll of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
DIGIT L MULTI MPLIFIER Contents Contents Unpacking ............................2 Installation Environment............................2 Important Safety Instructions......................2 Features ............................3 Cautions for the installation of Rack ...................4 Front Panel ............................5 Rear Panel ............................7 Volume Range Setting ........................9 Signal Mapping Function ......................10 Output Bridge Function .......................11 Connecting Speakers ........................12 Communication Between DP -5075M, nd DP -5075M and PC... -
Page 4: Unpacking
DIGIT L MULTI MPLIFIER Unpacking Unpacking lthough your DP -5075M is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. s with most electronic devices, we strongly recommend you to retain the original packaging. -
Page 5: Features
DIGIT L MULTI MPLIFIER Features Features Features - Module type mplifier - 4+1 channel, Spare- mplifier switch function - Low power consumption and low heat generation with Digital mplifier and SMPS (Switching Mode Power Spply) - Independent power (SMPS) design for each module. C 120V, 220~240V 50/60 Hz and DC 24V - HPF (High Pass Filter) : 65Hz / 400Hz (-3dB) - Signal mapping function. -
Page 6: Cautions For The Installation Of Rack
DIGIT L MULTI MPLIFIER Cautions for the installation of Rack Cautions for the installation of Rack Following cautions should be kept when installing this device into the rack. 1. Proper ventilation inside of rack is required. Open the rear panel of rack or install the fan. 2. -
Page 7: Front Panel
DIGIT L MULTI MPLIFIER Front Panel Front Panel 1. POWER SWITCH When turning on the switch, blue light on power LED will be on, and this device is ready to operate. However, Main power switch on the rear panel should be on. ※... - Page 8 DIGIT L MULTI MPLIFIER 6. SP RE MODULE In case of error in the module being used, it will be switched to the spare module automatically so that broadcasting can be continued. EX1) Normal Motion (Normal) (Normal) (Normal) (Normal) (Stand-by) EX2) Switch to Spare in case of No.1 mplifier Error (Failed) (Normal)
-
Page 9: Rear Panel
DIGIT L MULTI MPLIFIER Rear Panel Rear Panel 133.3Ω 133.3Ω 133.3Ω 133.3Ω (100V) (100V) (100V) (100V) 1. SPE KER TERMIN L It is the speaker output terminal. ※ C UTION : Total impedances of speaker connected per one channel should be higher than rated impedance(100V : 133.3Ω, 70V : 65.3Ω). - Page 10 DIGIT L MULTI MPLIFIER 7. M IN POWER SWITCH It is the M IN SET power ON /OFF switch. 8. DC TERMIN L It is the spare battery (24VDC) connecting terminal. In case of blackout of C power, back-up battery will supply the power.
-
Page 11: Volume Range Setting
DIGIT L MULTI MPLIFIER Volume Range Setting Volume Range Setting Volume can be adjusted to 0dB~-12dB or 0dB~Minimum ranges using volume adjustment level jumper in the device. 1. Volume djustment Range: 0dB~-12dB (Factory Setting) When you want to change the volume adjustment range to 0dB~-12dB, connect the jumper connector of CN351, CN352, CN353, and CN354 to No.2~3. -
Page 12: Signal Mapping Function
DIGIT L MULTI MPLIFIER Signal Mapping Function Signal Mapping Function You can change the input signal to desire outputs. Please select the desire input to corresponding output. EX1) No. 1 input->No. 1 output, No. 2 input->No. 2 output, No. 3 input-> No.3 output, No. 4 input-> No. 4 output (Factory Setting) EX2) No. -
Page 13: Output Bridge Function
DIGIT L MULTI MPLIFIER Output Bridge Function Output Bridge Function Maximum 300W can be used as the bridge by using output bridge function. When using the bridge, please unify the input of amp to be bridged into one input. EX1) Setup for using input No. 1/ 300W output fter setting up the signal mapping switch to No.1input in all channel, bridge all channel. -
Page 14: Connecting Speakers
DIGIT L MULTI MPLIFIER Connecting Speakers Connecting Speakers - Installation of Speaker When you connect the speaker, after separating the power code from the socket, connect the speakers according to speaker type and connecting method to the rear panel. Installation of High Impedance Speaker - If High Impedance speaker is connected to each zone in parallel, up to 75W of speaker output for each channel can be used. -
Page 15: Communication Between Dp -5075M, Nd Dp -5075M And Pc
DIGIT L MULTI MPLIFIER Communication Between DP -5075M, nd DP -5075M and PC Communication Between DP -5075M, nd DP -5075M and PC DP -5075M can link communicate up to 200 devices by using RS-422 DIRECT C BLE. 1) Setup the device ID ID can be setup by using 8-pin address setting located on the rear panel as follows. -
Page 16: Pplications
DIGIT L MULTI MPLIFIER pplications pplications DP -5075M... -
Page 17: Block Diagram
DIGIT L MULTI MPLIFIER Block Diagram Block Diagram DP -5075M... -
Page 18: Specifications
DIGIT L MULTI MPLIFIER Specifications Specifications DP -5075M Rated Output 75W x 4 Chnnel (1KHz, THD 1% ( ES17)) 70V / 65.3 Ω, 100V / 133.3 Ω Speak Out / Impedance Input Seneitivity 1V / 10KΩ Balance THD ( ES17) Rated Output (75W, 1kHz) Less than 1 % 1/3 Rated Output (25W, 1kHz) -
Page 19: Dimensions
DIGIT L MULTI MPLIFIER ※ DIMENSIONS DP -5075M... -
Page 20: Service
To obtain specific warranty information and available service locations, contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 21 NOTE DP -430H M -106...
