- Page 1 Operation anual Digital SR mplifier DS -600Q * Rack mount products in the Western Hemisphere(North America, South America, and the Caribbean) do not have handles installed due to customer preference.
- Page 2 A personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
Contents Unpacking ............................2 Installation environment............................2 Important Safety Instructions......................2 Features ............................3 Front Panel ............................4 Rear Panel ............................5 Installation Precautions .........................7 Applications ............................8 Block Diagram ..........................9 Specifications ..........................10 Service procedures............................12 Schematic .............................12 parts list ............................12 Variations and Options .......................12 Warranty ............................12 DSA-600Q... -
Page 4: Unpacking
DIgItAl SR AMplIfIeR Unpacking Unpacking Although your DSA-600Q is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. -
Page 5: Features
Ideal for emergency message broadcasting applications. Accessories - Ac power Cord×1 - 2p terminal Block (Ac Remote power)×1 - 8p terminal Block×1 - Screws for Rack mount Bracket×4 - Washer x 4 - Operation Manual×1 DSA-600Q... -
Page 6: Front Panel
5. POWER SWITCH this button controls power status pOWeR leD turns on when this switch is pressed. DSA-600Q... -
Page 7: Rear Panel
If unbalanced cable us used, use only in a short distance between the devices as unbalanced cables are prone to noise in the line. And if balance jack is used as unbalanced jack connection, please refer to the diagram below. XLR JACK DSA-600Q... - Page 8 When connecting speakers to ine 4 pole speaker sokets of CH 1 CH 2 CH 1 When connecting speakers to ine 4 pole speaker sokets of CH 3 CH 3 AMP OUT CH 4 AMP OUT CH 4 CH 3 DSA-600Q...
-
Page 9: Installation Precautions
CH 3 CH 2 CH 1 CH 4 CH 3 AC POWER REMOTE 2. When using power amplifier, please install the unit where there is no airflow block to the heat sink. (Front) 10cm or less(away more than 10cm) (Front) DSA-600Q... -
Page 10: Applications
CASSETTE DECK Sources Devices Contact Closure Devices MIXER CH 2 CH 1 PRIORITY PRIORITY VOLUME INPUT INPUT AC INPUT OUTPUT CH 4 CH 3 CH 2 CH 1 CH 4 CH 3 AC POWER REMOTE External Power Remote Switch SPEAKER DSA-600Q... -
Page 11: Block Diagram
DIgItAl SR AMplIfIeR Block Diagram Block Diagram DSA-600Q... -
Page 12: Specifications
DIgItAl SR AMplIfIeR Specifications Specifications DSA-600Q 8Ω per channel, stereo 300W Rated Output (SteReO) 4Ω per channel, stereo 600W Voltage gain (rated output power@8Ω) 32dB Input Sensitivity (rated output power@8Ω) 1.23Vrms frequency Response 20Hz ~ 20kHz, 0dB±3dB tHD (1/3 rated output power@8Ω) less than 0.1%... - Page 13 DIgItAl SR AMplIfIeR ※ DIMENSIONS DSA-600Q...
-
Page 14: Service
Inter-M directly or the authorized Inter-M Distributor for your specific country or region.
