Summary of Contents for Inter-m DPA-430L
- Page 1 Operation anual Multi Channel Power mplifier DP -430L...
- Page 2 Welcome personal welcome to you from the management and employees of Inter-M ll of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
MULTI CH NNEL POWER MPLIFIER Contents Contents Unpacking ............................2 Installation Environment............................2 Important Safety Instructions......................2 Features ............................3 ccessories.............................3 Precautions ............................4 Installation Precautions .........................4 Front Panel ............................5 Rear Panel ............................7 Connecting Speakers ........................8 pplications ............................9 Block Diagram ..........................10 Specifications ..........................11 Dimensions ...........................12 Service ............................13 Variations and Options... -
Page 4: Unpacking
MULTI CH NNEL POWER MPLIFIER Unpacking Unpacking lthough your DP -430L is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. -
Page 5: Features
MULTI CH NNEL POWER MPLIFIER Features Features Features - 1U Rack Size - Multi channel power amplifier 170W/8 x 4 channels, 300W/4 x 4 channels, 600W/8 x 2 channels(Bridge Mode) - Independent SMPS power supply for each channel - Low power consumption, low heat dissipation and light weight - High pass filter switch (–3dB at 50Hz) - Protection circuitry (over heat, over current, speaker short, DC output) - Balanced input... -
Page 6: Precautions
MULTI CH NNEL POWER MPLIFIER Precautions Precautions 1. Do not connect outputs of two or more channels in parallel. 2. Do not connect speakers with a smaller impedance than specified to avoid the damage of the unit. 3. Keep the input cable away from the output cable. Installation Precautions Installation Precautions 1. -
Page 7: Front Panel
MULTI CH NNEL POWER MPLIFIER Front Panel Front Panel DPA-430L MULTI CHANNEL POWER AMPLIFIER PROT CLIP -10dB -30dB PROT CLIP -10dB -30dB PROT CLIP -10dB -30dB PROT CLIP -10dB -30dB 50Hz 50Hz 50Hz 50Hz CH 1 CH 2 CH 3... - Page 8 MULTI CH NNEL POWER MPLIFIER 6. HIGH P SS FILTER SWITCH Pressing the switch turns on the high pass filter. The corner frequency (-3dB) is 20Hz when the high pass filter switch is off or 50Hz when the high pass filter switch is on.
-
Page 9: Rear Panel
MULTI CH NNEL POWER MPLIFIER Rear Panel Rear Panel BRIDGE OUTPUT (4 ) (4 ) (4 ) (4 ) CH 4 CH 3 CH 2 CH 1 FAN 2 FAN 1 BRIDGE CH 2 CH 1 CH 4 CH 3 AC INPUT INPUT BRIDGE 3/4... -
Page 10: Connecting Speakers
MULTI CH NNEL POWER MPLIFIER Connecting Speakers Connecting Speakers Before connecting speakers, disconnect the C power cable. Note the proper connecting terminals as below. Normal Mode Bridge Mode (4 ) (4 ) (4 ) (4 ) (4 ) (4 ) (4 ) (4 ) CH 4... -
Page 11: Pplications
(4 ) CH 4 CH 3 CH 2 CH 1 FAN 2 FAN 1 BRIDGE CH 2 CH 1 CH 4 CH 3 AC INPUT INPUT BRIDGE 3/4 (8 ) BRIDGE 1/2 (8 ) DPA-430L SE-15 SE-15 SE-15 SE-15 DP -430L... -
Page 12: Block Diagram
MULTI CH NNEL POWER MPLIFIER Block Diagram Block Diagram DP -430L... -
Page 13: Specifications
MULTI CH NNEL POWER MPLIFIER Specifications Specifications D P-430L Rated Output Power 170W/8 x 4 channels 300W/4 x 4 channels 600W/8 x 2 channels(Bridge Mode) T.H.D ( ES17) Prated (300W, 1kHz) Less than 0.1% Prated (100W, 1kHz) Less than 0.03% High Frequency Response (+1, -3dB) Over than 20kHz Low Frequency Response... -
Page 14: Dimensions
MULTI CH NNEL POWER MPLIFIER ※ DIMENSIONS DP -430L... -
Page 15: Service
To obtain specific warranty information and available service locations, contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 16 NOTE DP -430L...
- Page 17 NOTE D P-430L M -106...
- Page 18 NOTE D P-430L...
- Page 19 D P-430L...
- Page 20 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
