- Page 1 Operation anual Multi Channel Power mplifier DP -4300M *Rack mount products in the Western Hemisphere (North America, South America, and the Caribbean) do not have handles installed due to customer preference.
- Page 2 Welcome personal welcome to you from the management and employees of Inter-M All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
HPF OFF Setting method .......................9 Rear Panel .............................10 I/O Contact Point Terminal for Remote Control ..............12 How to Connect Speaker ......................13 Communication Method between devices and PCs ..............14 pplications ..........................16 Block Diagram ..........................17 Specifications ..........................18 Service ............................20 Warranty ............................20 DPA-4300M... -
Page 4: Unpacking
MULTI CHANNEL POWER AMPLIFIER Unpacking Unpacking Although your DPA-4300M is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. -
Page 5: Caution When Installing Rack
1. Make air circulation in the rack proper. Open the rear panel of the rack or install the fan. 2. Install blank panels between every 5 amps when installing several amps to provide proper air circulation. 3. Blank panel included in the DPA-4300M should be installed in the channel which is not used among the sets. DPA-4300M... -
Page 6: Features
2. DM- 300 module x 1 3. AC power cable x 1 4. 4P terminal block x 2 5. 5P terminal block x 4 6. 6P terminal block x 8 7. Screw x 4 for rack installation 8. DPA-4300M module Blank Panel x 3 DPA-4300M... -
Page 7: Front Panel
It displays the information about the operation and control of the module. 4. VOLUME SWITCH - DPA-4300M supports two inputs; normal (PGM) and priority (PRI) inputs. - If volume up switch or volume down switch is pushed, PGM volume can be adjusted. Volume value will be displayed on LCD. - Page 8 5. PRI VOLUME SELECTION SWITCH (CHECK IP) - DPA-4300M supports two inputs; normal (PGM) and emergency (PRI). If volume up or down switch is pushed while PRI switch is pushed, PRI volume can be adjusted. Volume value will be displayed on LCD.
-
Page 9: Lcd Panel
It displays CC when amplifiers are in CASCADE mode. 8. ID It will be on when checking out the set IP in the front panel. 9. PGM VOLUME LEVEL It indicates the volume value of PGM input. It displays BR when amplifiers are in BRIDGE mode. DPA-4300M... - Page 10 15. RUN (NORM L OPER TION CHECK) This indicates that the amplifier is operated normally. 16. RUN (NORM L OPER TION CHECK) It indicates whether AC or DC power is being used. Input power operation display. Input Operation Status AC, DC AC, DC DPA-4300M...
-
Page 11: Hpf Off Setting Method
HPF OFF Setting method When turning off the rear panel HPF switch, frequency can be set 65Hz or OFF in the device. (Channel 1 : CN14A1, Channel 2 : CN14A2, Channel3 : CN14A3, Channel 4 : CN14A4, factory setting is 65Hz) 65Hz DPA-4300M... -
Page 12: Rear Panel
Input and volume of CH1 is distributed to CH2, 3, 4. 5. HPF SELECT SWITCH Three available modes: OFF, 200Hz and 400Hz with HPF select switch. ※ Selection of HPF is only available in PGM input. PRI input is fixed to 400Hz. DPA-4300M... - Page 13 It is a switch which can select the output speaker line voltage of amp output. When it is on, it is 70V, and 100V for OFF. 15. TEMPER TURE DISPL Y METHOD SELECT SWITCH Select the Celsius and Fahrenheit temperature display of LCD. On selects Fahrenheit, and Off for Celsius. DPA-4300M...
-
Page 14: I/O Contact Point Terminal For Remote Control
C F ULT CONT CT POINT OUTPUT When contact point is off, PGM input will be output to the speaker, and contact point is on, PRI input will be output to speaker. PRI input can be selected only by contact point. DPA-4300M... -
Page 15: How To Connect Speaker
When connecting the speaker, remove the power code from the condenser, and connect it to the speaker depending on types and connecting methods of the speaker. ※ Not to connect the speaker less than rated impedance stated in below table. RATED IMPEDANCE MODE 100V 33.33 Ω 16.33 Ω NORMAL 16.67 Ω 8.17 Ω BRIDGE DPA-4300M... -
Page 16: Communication Method Between Devices And Pcs
3) Caution - when connecting one or more amps, caution not to overlap the IP address values. When IP address are overlapped, monitoring and volume controls will not available from PC. However, volume control with amp volume is possible. DPA-4300M... - Page 17 - Connect ETHERNET terminal of PC to ETHERNET terminal in the rear panel of DPA-4300M. 5) Connect PC with two or more DPA-4300Ms - Connect ETHERNET terminal of PC to ETHERNET terminal in the rear panel of DPA-4300M throughout HUB.
-
Page 18: Pplications
MULTI CHANNEL POWER AMPLIFIER pplications pplications DPA-4300M... -
Page 19: Block Diagram
MULTI CHANNEL POWER AMPLIFIER Block Diagram Block Diagram DPA-4300M... -
Page 20: Specifications
-3dB ± 2dB 400Hz -3dB ± 2dB Operating Temperature -10°C ~ +40°C Power Source 120VAC, 60Hz, 220-240VAC, 50/60Hz DC 24V Power Consumption (1/8 Pmax, DPA-4300M + DM-300 3EA) 260W DPA-4300M 11 kg/24.3 Ib 2.7 kg/6 Ib Weight(set) DM-300 DPA-4300M+DM-300 3EA 18.5 kg/41 Ib... - Page 21 MULTI CHANNEL POWER AMPLIFIER ※ DIMENSIONS DPA-4300M...
-
Page 22: Service
To obtain specific warranty information and available service locations, contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 23 NOTE...
- Page 24 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
