Introduction

1 Introduction
This document describes the Intel® Edison Breakout Board.
The Intel® Edison Breakout Board is designed to expose the native 1.8 V I/O of the Intel® Edison module. The board
consists of power supply, battery recharger, USB OTG power switch, UART to USB bridge, USB OTG port, and I/O
header.
1.1

References

Table 1 Product-specific documents
Reference Name
331188 Intel® Edison Board Support Package User Guide
331189 Intel® Edison Compute Module Hardware Guide
331190 Intel® Edison Breakout Board Hardware Guide
331191 Intel® Edison Kit for Arduino* Hardware Guide
329686 Intel® Galileo and Intel® Edison Release Notes
[GSG] Intel® Edison Getting Started Guide
331438 Intel® Edison Wi-Fi Guide
H49905 Intel® Edison Breakout Board Schematic
January 2015
Document Number: 331190-006
Number/location
(This document)
W: http://www.intel.com/support/edison/sb/CS-035336.htm
M: http://www.intel.com/support/edison/sb/CS-035344.htm
L: http://www.intel.com/support/edison/sb/CS-035335.htm
https://communities.intel.com/docs/DOC-23323
§
Intel® Edison Breakout Board
Hardware Guide
