High-Level Functional Description

Figure 1 provides the block diagram for the Intel® Edison Breakout Board.
Figure 1 Intel® Edison breakout board block diagram
Intel® Edison
USB 0TG
Client
USB
Micro
Type-AB
Intel® Edison Breakout Board
Hardware Guide
6
7 to 15 V
power supply
4.4 V power supply
and battery
recharger
UART 1
UART –
USB FTDI
Client
USB
Micro
Type-B
High-Level Functional Description
GPIO
I2C
SD
4
UART 0
