- Page 1 HARDWARE GUIDE I/O Guide Specifications and Operational Guide www.proloncontrols.com | info@proloncontrols.com 17 510, rue Charles, Suite 100, Mirabel, QC, J7J 1X9 REV. 6.1.7 PL-HRDW-I/O-EN...
-
Page 2: Table Of Contents
Table of Contents PL-VC2000(-PI) ..........................3 (VAV) PL-C1000-VAV ............................4 PL-T1100 ..........................5 (Thermostat) PL-T1000 ........................6 (Digital Wall Sensor) PL-T500 / PL-T200 ......................6 (Digital Wall Sensor) PL-M2000-RTU/RTUS ........7 (Zoning Rooftop Controller & Single-Zone Rooftop Controller) PL-C1000-RTU/RTUS ............8 (Zoning Rooftop Controller & Single-Zone Controller) PL-M2000-HP/HPS ........9... -
Page 3: Pl-Vc2000(-Pi) (Vav)
PL-VC2000(-PI) (VAV) VC2000 Network communication General Purpose Analog Input (0-5 VDC, 4-20mA, 10K thermistor) Supply, Radiant, Zone, Occupancy, Discharge Digital Sensor (T1000, T500 or T200) / Remote computer with Focus Analog Output (0-10 VDC) (Max Current: 40 mA) Digital Output - Isolated Triac... -
Page 4: Pl-C1000-Vav
PL-C1000-VAV INT Port: Incoming Modbus RS485 communication from digital sensor or remote computer with ProLon Focus software NET Port: Incoming Modbus RS485 communication - OR - BACnet MS/TP - OR - Lon FFT-10 Free Topology Twisted Pair Digital Input for Night Setback / Standby Mode... -
Page 5: Pl-T1100 (Thermostat)
PL-T1100 (Thermostat) NET A Network communication NET B 24 VAC Power source of the controller 24 VAC Digital Output - Sink, TRIAC 24 VAC (Max current: 300mA) Analog Output (0-10VDC) (Max current: 40mA) AUX IN Auxiliary / Radiant Floor temperature sensor (10K thermistor) RJ45 DO/AO override based on... -
Page 6: Pl-T1000 (Digital Wall Sensor)
PL-T1000 (Digital Wall Sensor) INT A Interface communication INT B 24 VAC Power source of the controller 24 VAC AUX IN Auxiliary / Radiant Floor temperature sensor (10K thermistor) RJ45 PL-T500 / PL-T200 (Digital Wall Sensor) INT A Interface communication INT B 24 VAC Power source of the controller... -
Page 7: Pl-M2000-Rtu/Rtus (Zoning Rooftop Controller & Single-Zone Rooftop Controller)
Bottom Row: RTUS Static pressure (0-5 / 1-5V) (1 / 1.5 / 2 / 2.5 in) Common for all inputs Incoming communication INT Port: ProLon Digital CO2 sensor (4-20 mA) from remote computer Temperature Sensor RTUS External dry contact for proof of fan... -
Page 8: Pl-C1000-Rtu/Rtus (Zoning Rooftop Controller & Single-Zone Controller)
PL-C1000-RTU/RTUS (Zoning Rooftop Controller & Single-Zone Controller) RTUS INT Port: Incoming RS485 INT Port: ProLon Digital Network communication Temperature Sensor (Modbus) - OR - Incoming RS485 Network Communication (Modbus) RTUS Net Port: Outgoing RS485 Net Port: ProLon Digital Network communication... -
Page 9: Pl-M2000-Hp/Hps (Zoning Heatpump Controller & Single-Zone Heatpump Controller)
Bottom Row: Common for all inputs Static pressure (0-5 / 1-5V) (1 / 1.5 / 2 / 2.5 in) Incoming communication INT Port: ProLon Digital Ext dry contact for alarm / CO sensor (4-20 mA) Temperature Sensor from remote computer Static pressure (0-5 / 1-5V) (1 / 1.5 / 2 / 2.5 in) -
Page 10: Pl-C1000-Hp/Hps (Zoning Heatpump Controller & Single-Zone Heatpump Controller)
PL-C1000-HP/HPS (Zoning Heatpump Controller & Single-Zone Heatpump Controller) INT Port: Incoming RS485 INT Port: ProLon Digital Temperature Sensor - OR - Network communication (Modbus) Incoming RS485 Network Communication (Modbus) Net Port: Outgoing RS485 Net Port: ProLon Digital Temperature Sensor Network communication... -
Page 11: Pl-M2000-Blr (Boiler)
PL-M2000-BLR (Boiler) Bottom Row: Common for all inputs INT Port: Incoming RS485 Network communication Disable Boiler Call (Dry Contact) (Modbus) Use Max Heat Setpoint (Dry Contact) AO3 Valve (0-10 / 2-20 / 0-5 VDC) Proof of Pump 2 (AO1) (Dry Contact) or Backup Modulating Boiler Proof of Pump 1 (DO5) (Dry Contact) AO2 Modulating Boiler... -
Page 12: Pl-C1000-Blr (Boiler)
PL-C1000-BLR (Boiler) INT Port: Incoming RS485 Network communication (Modbus) NET Port: Incoming RS485 Network communication (Modbus) External dry contact for proof of pump Supply water temperature sensor (10K thermistor) Common for all the inputs Return water temperature sensor (10K thermistor) Outside air temperature sensor (10K thermistor) Output 5 - Valve / Modulating Boiler (Analog 0-10 / 2-10 / 0-5 DVC) -
Page 13: Pl-M2000-Mua (Air Make-Up)
PL-M2000-MUA (Air Make-Up) Bottom Row: Common for all inputs CO2 (4-20mA) / Building Pressure (0-5VDC) INT Port: Incoming RS485 Zone Temperature (10K Thermistor) Network Communication Outside Temperature (10K Thermistor) (Modbus) Supply Temperature (10K Thermistor) Manual Reset Proof of Fan AO 3 - Variable Frequency Drive Proof Outside Air Damper Open AO 2 - Cooling Proof Exhaust 2 / Manual override... -
Page 14: Pl-C1000-Hu (Humidifier)
PL-C1000-HU (Humidifier) INT Port: Incoming RS485 Network communication (Modbus) NET Port: Incoming RS485 Network communication (Modbus) External dry contact for proof of fan SUPPLY Supply humidity sensor (0-5VDC) Common for all the inputs Room / Return humidity sensor (0-5VDC) SETPT Outside temperature sensor (10K thermistor) ROOM Output 5 - Humidi er (Analog 0-10 / 2-10 VDC) -
Page 15: Pl-C1000-Wlc (Water Loop Controller)
PL-C1000-WLC (Water Loop Controller) INT Port: Incoming RS485 Network communication (Modbus) NET Port: Incoming RS485 Network communication (Modbus) Auxiliary Digital Input SUPPLY Supply water temperature sensor (10K thermistor) Common for all the inputs Return water temperature sensor (10K thermistor) SETPT Auxiliary temperature sensor (10K thermistor) ROOM Output 5 - Water Tower Stage 2... -
Page 16: Pl-M2000-Flx (Flexio Controller)
PL-M2000-FLX (FlexIO Controller) Bottom Row: Common for all inputs Analog Input 9 Analog Input 8 RS485 Network Communication (INT Port) Analog Input 7 Analog Input 6 Analog Input 5 Analog Input 4 Analog Output 3 Analog Input 3 Analog Output 2 Analog Input 2 Analog Output 1 Analog Input 1... -
Page 17: Pl-C1000-Flx (Flexio Controller)
No part of this document may be photocopied or reproduced by any means, or translated to another language without prior written consent of ProLon. All specifications are nominal and may change as design improvements are introduced. ProLon shall not be liable for damages resulting from misapplication or misuse of its products.
