Prolon VAV ProPack Booklet

Included in this box:
• PL-VC2000-PI VAV Controller
• PL-T1000-WGL Wall Sensor
• PL-DT-T6 Duct Temperature Sensor
• Quick Installation Instruction
• Wiring diagram
Section 1 - Quick Installation Instructions
The PL‐VC2000‐PI standalone fonctions as a VAV controller & set up from the PL‐T1000 wall module. However it is much easier to
set up the PL‐VC2000‐PI from the smartphone app or Focus software using the PL‐485‐BT Prolon Connection tool.
1) Turn off 24VAC power before connecting any wires to the
PL‐VC2000‐PI.
2) Manually close the VAV damper & verify if it opens clockwise or
counterclockwise.
3) Press and hold the "Clutch" button on the PL‐VC2000‐PI &
turn the actuator fully clockwise or counterclockwise
depending on which way the damper actuates (PL‐VC2000‐PI
factory settings are set to open counterclockwise). (See
section 5 to change the direction of the actuator directly on
controller)
4) Install the PL‐VC2000‐PI actuator on the damper shaft using
the 2 nuts on the actuator clamp, slide the anti‐rotation
bracket up under the actuator so it engages the actuator at
the center cutout, and secure the anti‐rotation bracket to
the VAV box with a self‐tapping screw. It is normal that the
PL‐VC2000‐PI has some wiggle to it. As the actuator opens/
closes, the controller will travel slightly left/right on the anti‐
rotation bracket.
5) Adjust the actuator's mechanical stoppers to match the full
damper movement. This will prevent the controller from
overtravel once the damper is fully opened or closed.
6) For pressure independent applications, connect the airflow
measuring station to the high & low pressure tubes on the
PL‐VC2000‐PI using 1/8" (inner diameter) PVC tubing. The
high side faces the air coming from the RTU/AHU. For pressure
dependent applications, disregard this step.
7) Install the PL‐DT‐T6 Duct Temperature Sensor on the inlet of
the damper (air coming from the RTU/AHU). Connect the
wires to the Analog Input on terminals 13 & 14.
Full Instruction can be be downloaded from these QR Codes.
View PL-VC2000 Installation Video
[ 800-00012-001 ]
Thank you for purchasing the VAV - ProPack
This booklet will help you install your devices properly.
proloncontrols.com
VAV Zone Controller - VC2000 Series
Hardware Guide
Not included in the box:
• 24VAC Transformer
• #18/2 AWG stranded, shielded wire for 24V
• #22/2 AWG stranded, shielded for data
PL-485-BT Connection Tool (optional)
•
For Technical Support Contact
1-877-977-6566
8) Install the PL‐T1000 wall module in the zone & connect it to
the PL‐VC2000‐PI using 4 wires (2 for 24VAC power, and 2 for
data). Respect the polarity (24V to 24V, COM to COM, + to +,
‐ to ‐) See section 2 for wiring details.
9) If you are controlling an on/off device with either dry contact
or 24VAC signals (duct heater, fan powered box, radiant floor,
baseboard heat, or zone valve), connect device to Digital
Output terminals. See Section 2 for more details.
10) If you are controlling a modulating device with 0‐10Vdc or
2‐10Vdc signal (duct heater, fan powered box, radiant floor,
slave damper, occupancy, baseboard heat, or zone valve),
connect device to Analog Output terminals. See Section 2 for
more details.
11) Connect 24VAC power supply to the PL‐VC2000‐PI on terminal
1 (common) and terminal 2 (hot). Power supply transformer
can power a single VAV controller, or can be daisy chained to
power multiple VAV controllers. Provide 5VA per PL‐VC2000‐PI
controller.
12) Upon applying power to the PL‐VC2000‐PI, the PL‐T1000 wall
sensor will power up simultaneously. Follow PL‐T1000 screen
instructions to address PL‐VC2000‐PI (address can be #1
through #127). Note addresses 99 & 101 are reserved for other
devices & it's good practice to avoid using those addesses.
Do not use an address already showing on the system.
Controllers with a duplicate address will not work. You can
always change the address in the Focus software, app, or
PL‐T1000 wall module.
13) To change settings on the VAV controller, all settings are
accessible via the PL‐T1000 Wall Sensor menus (Note: see
section 4)
Rev. 1.0
[PROPACK-VAV]
Digital Sensor - T1000 Series
Hardware Guide
[ 1 ]
