Page 1: Table Of Contents
KERN EC Series Version 1.3 10/01 Operating Instructions Electronic Precision Balances Contents TECHNICAL DATA INTRODUCTION TO KERN EC COUNTING BALANCES UNPACKING AND ACCESSORIES SETTING UP LEVELLING ELECTRICAL SUPPLY DECLARATION OF CONFORMITY EXTERNAL VIEW & NAMES OF PARTS INSTALLATION 10 COUNTING OPERATION... -
Page 2: Technical Data
1 Technical Data KERN EC 600-2 EC 6000-1 EC 12K 1 Readability Limit (d) 0.02 g 0.2 g Weighing Range 600 g 6000 g 12 kg Taring Range 600 g 6000 g 12 kg Reproducibility 0.01 g 0.1 g Linearity ±... -
Page 3: Introduction To Kern Ec Counting Balances
Preparation before counting objects is simply loading 10 or 30 pieces sample on the balance and pressing "10" key or "30" key. Your KERN EC does not require adjusting in long term operation. Adjusting is required only when it is relocated, not before daily operation. -
Page 4: Levelling
5 Levelling Watch if the balance is level. Locate the level in front of the balance and four adjusting legs beneath it. Drive these legs to centre the bubble in the red circle of the level. Watch if all legs are settled on the table securely. See (b 6 Electrical Supply The mains Adapter should only be connected to a 230 V / 50 Hz electrical supply. -
Page 5: Declaration Of Conformity
Version 89/336/EC Electromagnetic Compatibility Applied harmonised norms, in particular EN 50081-1, EN 50082-1 If a change is made to the above mentioned appliances without consulting KERN this declaration will become invalid. Datum: 02. May 1997 Signature: Gottl. KERN & Sohn GmbH Management Gottl. -
Page 6: External View & Names Of Parts
8 External View & Names of Parts Key Functions : ON/OFF key for power. MODE : Key for changing display, pcs, weight or unit weight. Also for calling function, for storing parameters, for setting digits of parameters. : Key for sampling unit weight with 10 samples. : Key for sampling unit weight with 30 samples. -
Page 7: Installation
9 Installation Location KERN EC balances are very robust, still it is an "precision weighing instrument" which requires gentle operation and handling with care. Install the unit in good conditions for optimum results. Locations as follows may cause erroneous results. -
Page 8: Counting Operation
10 Counting Operation 1. Tare the balance by pressing the T key. Display: Exactly 0 p. If otherwise displayed, press MODE key once or twice to read exactly 0 p. 2. Place samples pre-counted, 10 pieces or 30 pieces on the pan. Press 10 key or 30 key corresponding to the sample quantity. -
Page 9: Functions
11 Functions How to access and change various functions Access to Functions (1) Press Mode and release it when "Func" appears showing that the balance is in function mode. Auto Zero (2) The first mode of the balance "1. A.0_" for Auto Zero appears. -
Page 10: Parameter List Of Functions
12 Parameter List of Functions * To change parameters (conditions), see page 23. 1 . A . 0 : Auto zero adjustment is effective. Auto-Zero : No zero adjustment. 2 . A . P . : Automatic power off in use of battery (option) - not effective. Auto-Power : Automatic power off in use of battery (option) - effective. -
Page 11: Span Adjusting
13 Span Adjusting To achieve optimum accuracy from the balance, it should be adjusted in the area it is used and readjusted when it is relocated to other areas. The following adjusting procedure is simple, not subject to operator errors, but does require a reference weight * of the full capacity of the balance **. -
Page 12: Important Information
14 Important Information These electronic balances are precision instruments. It is designed for use in a self- controlled electromagnetic environment. That means that in such an environment radio equipment, such as mobile phones, must not be used in direct vicinity. In case strong electromagnetic fields should arise, deviations of the indication are possible. -
Page 13: Troubleshooting
15 Troubleshooting Display is unstable. Affected by a wind or oscillation. Check location and response speed. The installation base is unstable. Check the base. Weighing pan or tare touches something. Check. Erroneous value reads in display. Wrong taring operation. See page 22. Balance is not level. - Page 14 Error messages b-Err Electronic error by a static electricity or noise. Contact the shipper. L-Err In counting the unit weight of samples is too light for the balance division. Countable unit weight is the readability of the balance or over. o-Err The load exceeds the capacity of the balance.
