- Page 1 HD CAMERA CONTROL UNIT HSCU300RF HSCU300R CCU CONTROL PANEL HKCU-FP2 OPERATION MANUAL [English] 1st Edition...
-
Page 2: Table Of Contents
(HSCU300R, Digital Triax Transmission) ....6 Locations and Functions of Parts ......7 Front Panel ..............7 Rear Panel ..............8 HKCU-FP2 CCU Control Panel (Optional) ....10 Status Display ............12 Displaying the Status Screen ........12 Status Display Screen ..........12 Setup Menu.............. -
Page 3: Overview
• Intercom input/output, 2-system (D-sub 25-pin) • PGM (program audio) input, 2-system (D-sub 25-pin) Other input/outputs • The HSCU300RF Camera Control Unit connects to a Sony HSC300RF or HSC100RF HD color camera via an optical • Tally (R/G) (D-sub 25-pin) fiber cable. - Page 4 RTS/Clear-Com intercom systems. For information on support for RTS/Clear-Com systems, contact a Sony service or sales representative. Microphone volume control The camera’s microphone volume can be controlled via the MIC REMOTE connector.
-
Page 5: System Configuration Example (Hscu300Rf, Optical Digital Transmission)
LAN cable VCT-14 Tripod Adaptor CAC-6 Return Video Selector (mounts on front panel) Tripod for LAN cable AC power portable camera HKCU-FP2 Front Control Panel HDVF-550/C550W/C730W MSU-1000/1500 Master Viewfinder Setup Unit RCP-1000-series Remote Control Panel VF attachment shoe HSC300RF HD Color Camera... -
Page 6: System Configuration Example (Hscu300R, Digital Triax Transmission)
LAN cable VCT-14 Tripod Adaptor CAC-6 Return Video Selector (mounts on front panel) Tripod for LAN cable AC power portable camera HKCU-FP2 Front Control Panel HDVF-550/C550W/C730W MSU-1000/1500 Master Viewfinder Setup Unit RCP-1000-series Remote Control Panel VF attachment shoe HSC300R HSC-300... -
Page 7: Locations And Functions Of Parts
Locations and Functions of Parts Front Panel a Tally light c INTERCOM audio input/output and control block Turns on red to indicate a red tally signal is being received INTERCOM (intercom adjustment) knob (such as when the picture from the camera connected to the CCU is being used). -
Page 8: Rear Panel
d MENU control block f POWER indicator CAM: Turns on when power is supplied to the camera. DISP/MENU (display/menu) lever and indicator MAIN: Turns on when the CCU power supply is turned on. It flashes when there is a problem with the fan. CANCEL/ENTER lever g NETWORK indicator Displays the network system connection status. - Page 9 d Pr/R/R-Y, Y/G/Y, Pb/B/B-Y (component signals) (LAN) jack (RJ-45, 8-pin) connectors (BNC type) Connects to a LAN hub (10BASE-T/100BASE-TX), when Outputs the HD component signals, SD component signals, using a network connection, via a LAN cable (shielded type, HD RGB signals, or SD RGB signals from the corresponding category 5 or higher).
-
Page 10: Hkcu-Fp2 Ccu Control Panel (Optional)
Optional panel controls a PANEL ACTIVE button • Display Activates the optional HKCU-FP2 CCU Control Panel to When the ECS button is lit: Displays the clear scan frequency. control the camera connected to the CCU (panel active state). When the ON button is lit: Displays the shutter speed. - Page 11 i CUSTOM (custom volume) knob See “R/B BLACK” on page 26 on “<FRONT PANEL 1>” and Controls the function assigned to the knob on the <FRONT “R/B BLACK” on page 27 on “<FRONT PANEL 2>”. PANEL 1> page in the CCU CONFIGURATION menu. Turning m IRIS/MASTER BLACK adjustment controls the knob adjusts the assigned function.
-
Page 12: Status Display
Camera settings Status Display Page 1 The CCU system status can be monitored using a picture 1/ 200 0 monitor connected to the PIX output. For information on monitoring and changing settings, see “Setup Menu” on page 16. Displaying the Status Screen The menu screen is controlled using the knob and levers in the ND: 1 F :4. - Page 13 D at a P ow er OK DM: DM board status T on e Det ec t Front Panel: HKCU-FP2 CCU control panel status (displayed R EM OTE C ab le Con ne ct D at a only when HKCU-FP2 is mounted)
- Page 14 Page 3 Page 3 * S y s t e m D i a g 3 /3 * 5 / 13 *Ne two rk Di ag 3/3 * 8/ 13 I n t e r c o m C C U F R O N T EN G IP Add res s PG M...
- Page 15 DM POWER: DM board power supply status Front panel diagnostics This screen is displayed only when the HKCU-FP2 CCU Control Panel is fitted. * F r o n t P a n e l D i a g * 11 /1 3...
-
Page 16: Setup Menu
To change the displayed page Setup Menu Turn the control knob to move the , arrow to the page number, then press the control knob. The , arrow changes to a flashing ? question mark. The CCU system and peripheral settings can be modified Flashing using a picture monitor connected to the PIX output. -
Page 17: Menu Tree
Turn the control knob to move the , arrow to the Turn the control knob to move the cursor to the desired item, then press the control knob. desired character, then press the control knob. The , arrow changes to a flashing * asterisk. The input Repeat steps 1 and 2 to enter other characters. - Page 18 CCU CONFIGURATION menu MENU SETTINGS RESUME (C11) RE DIRECTION COLOR BAR HD-BAR CATEGORY (C01) PAGE MF CB ITEM SLOPE DATA SD BAR DISPLAY MESSAGE BAR CHARA (C12) ALARM JUMP GRAY MASTER GAIN BAR CHARACTER BAR CHARACTER ECS/SHUTTER (C02) ALL CLEAR ND FILTER MONITOR 1 CHARACTER...
-
Page 19: Menu List
Menu List Note The following conventions are used in the menu list table. Settings column values (e.g. ON, OFF, 0): Default settings ENTER to execute: Press the control knob or move the CANCEL/ENTER lever to the ENTER position to execute. SYSTEM OPERATION menu Page name Item... - Page 20 Page name Item Settings Indication Page No. <OUTPUT FORMAT> SLOT NO 1-1&2 When CAMERA FORMAT is SDI OUTPUT 1/2 connector output format selection 1080/59.94i: 1080/59.94i, Sequence of format options: 525/59.94i 1: HD When CAMERA FORMAT is 2: SD 720/59.94P: 720/59.94P, Note 525/59.94i The default setting is different among the sales...
- Page 21 Page name Item Settings Indication Page No. <RETURN SET> RET1 When CAMERA FORMAT is Return signal format, aspect, and letterbox aspect 1080/59.94i: ratio selection RET2 1080/59.94i, 525/59.94i, NTSC Sequence of format options: RET3 (RET3 and RET4 default setting is 1: HD SDI NTSC) 2: SD SDI RET4...
- Page 22 Page name Item Settings Indication Page No. <MONITOR 2> LEVEL GATE ---, 1&2, 1, 2, OFF ---: Displayed when camera not connected, video output not set to CAMERA, or video output is set to CAMERA and GATE MARKER is ON (read only) Y LEVEL1 0 to 108% 49 61 Level gate 1 minimum and maximum detection levels...
- Page 23 Page name Item Settings Indication Page No. <FRONT INCOM> (MIC ON), (OFF), (PGM ON) CCU front panel MIC/PGM switch position (read only) (PRIVATE), (PROD), (ENG) CCU front panel INTERCOM switch position (read only) INCOM MIC CARBON, ECM, DYNAMIC Headset microphone type connected to INTERCOM on the front panel CARBON: Carbon microphone (power supply, 20 dB gain)
- Page 24 Page name Item Settings Indication Page No. <VIDEO ADJUST> VBS output video level adjustment LEVEL –99 to 99 0 CHROMA –99 to 99 0 PIX output video level adjustment LEVEL –99 to 99 0 CHROMA –99 to 99 0 WF output video level adjustment LEVEL –99 to 99 0 CHROMA...
- Page 25 Page name Item Settings Indication Page No. <OTHERS> REAR PREVIEW MOMENTARY, TOGGLE REMOTE device preview operation switching MOMENTARY: Display preview while PREVIEW button on REMOTE device is pressed TOGGLE: Toggle preview on/off when the PREVIEW button on REMOTE device is pressed REAR DSUB I/F MIC REM, WF REM MIC/WF REMOTE/TRUNK connector function...
- Page 26 Settings Indication Page No. <FRONT PANEL 1> ASSIGNABLE/CUSTOM NOT ASSIGN, GAMMA OFF, HD HKCU-FP2 CCU front panel SW1 button function DTL OFF, SD DTL OFF, BLK assignment Displayed only when GAMMA, KNEE OFF, AUTO the HKCU-FP2 CCU NOT ASSIGN: Not assigned (indicator always off)
- Page 27 1/1, 1/2, 1/4 Relative coefficient when the IRIS knob is set to relative value mode Displayed only when the HKCU-FP2 CCU 1/1: Variable range roughly 100% of total variation Control Panel is fitted 1/2: Variable range roughly 50% of total variation...
- Page 28 NETWORK SETTINGS menu Page name Item Settings Indication Page No. <TCP/IP SETTING> IP ADDRESS 0.0.0.0 to 255.255.255.255 IP address setting SUBNET MASK 0.0.0.0 to 255.255.255.255 Subnet mask display DEFAULT GATEWAY 0.0.0.0 to 255.255.255.255 Default gateway display ENTER to execute A “SET OK?” message is displayed. Press ENTER again to confirm the change.
-
Page 29: Appendix
Digital Triax Transmission (HSCU300R) Appendix Digital transmission between camera and CCU with powerful error correction function built-in. However, some errors, for example errors due to external noise in long-distance transmission, may be corrected by partial image interpolation Notes on Use of images in frame store. -
Page 30: Error Messages
Cable (for example) Max. distance Min. distance Specifications Fujikura 14.5-mm dia. 1,200 m (3937 ft) 100 m (328 ft) Belden 9232 13.2 mm dia. 850 m (2789 ft) 75 m (246 ft) HSCU300RF/HSCU300R General Error messages Power supply AC 100 to 240 V, 50/60 Hz Current consumption 4.5 A (max) When an error is detected in the CCU or the camera, the... - Page 31 Pr/Pb (75% color bar): 0.756 Vp-p, 75 Ω 482 mm (19 in) BNC type (2), VBS 1.0 Vp-p, 75 Ω VBS1, VBS2 BNC type (1), VBS/R/G/B HKCU-FP2 CCU Control Panel (Optional) (VBS 1.0 Vp-p, 75 Ω) General SYNC/WF BNC type (1)
- Page 32 DURING THE WARRANTY PERIOD OR AFTER EXPIRATION OF THE WARRANTY, OR FOR ANY OTHER REASON WHATSOEVER. • SONY WILL NOT BE LIABLE FOR CLAIMS OF ANY KIND MADE BY USERS OF THIS UNIT OR MADE BY THIRD PARTIES. • SONY WILL NOT BE LIABLE FOR THE TERMINATION...
- Page 33 The material contained in this manual consists of information that is the property of Sony Corporation and is intended solely for use by the purchasers of the equipment described in this manual. Sony Corporation expressly prohibits the duplication of any...
