Features; Technical Specifications - Axis JS056WK Installation Manual

2. Features

1. TFT LCD monitor with wide angle view and high resolution display.
2. NORMAL, MIRROR, FLIP and MIR-FLIP viewing available.
3. Split mode, auto-scan mode and single-display mode available.
4. Auto pairing: Auto pairing happens when camera is activated.
5. Auto dim function available.
6. Full-function remote control.
7. 4 wireless camera input.
8. Multiple video formats: PAL / NTSC.
9. Wide voltage input: 10 - 32V.
10. On-board speaker.
11. Auto switch to the working channel when trigger is activated
12. With touch buttons.

3. Technical Specifications

LCD size
Resolution
Contrast
Brightness
Viewing Angle
Channel
Operating Frequency
Receiving Sensitivity
Decompression Form
Transmit Output Power
Modulation
Time Delay
Transmitting Distance
System Format
Power Supply
Power Consumption
Loudspeaker
Operating temperature
Storage temperature
All specifications are subject to change without notice.
5.6"
640 x 3 (RGB) x 480
500:1
200 cd/m ²
U: 50 / D: 70, R/L: 70
4 channels
2400 - 2483.5 MHz
-89 dBm
MPEG4
17 dBm
2.4G FSK/GFSK
120ms
120 M
PAL / NTSC
DC 10-32V
Max. 5W
1W/8
-20~+70ºC,RH90%
-30~+80ºC,RH90%
Special Notice
5
7/17
